ULTRA ANCHOR SAIL BOAT POWER BOAT MULTIHULL BOAT BOAT BOAT BOAT BOAT BOAT BOAT BOAT WEIGHT LENGTH WEIGHT LENGTH LENGTH WEIGHT LENGTH LENGTH CAUTION - The ULTRA Anchor is designed to handle extremely heavy loads and caution is advised when handling. - All materials have resistance limits; the use of high-powered engines to free an anchor may deform it and/or cause damage to the vessel. - It is recommended to use a trip line or an ULTRA Anchor Ring to recover an anchor stuck under an obstruction. WARRANTY - Select the largest ULTRA Anchor that will meet both the vessel's weight and length criteria. - Users may select the next smaller size, depending on the anchoring they do and/or cruising area. - ULTRA Anchors are warranted for lifetime based on these recommendations. COMMENTS - When selecting ULTRA Anchors in excess of 100 kg or 220 lbs., please consult Lloyd's or a comparable certification society. The listed values should be used for preliminaryselection only. - ULTRA Anchors work well as bow and stern anchors on horizontal roller assemblies; they are not suitable for vertical or straight hawse holes. - It is recommended to use an ULTRA Flip Swivel or other suitably strong stainless steel connector. THEONE AND ONLY ultra ULTRAProducts Anchoring Equipment MANUFACTURER & HEAD OFFICE OMERLi MAH. ARPA^AY SOK. NO.4/1,34555 iSTANBUL,TURKiYE TEL: +90(212) 481-4161, E-MAIL: [email protected] UL TRA Products Anchoring Equipment

ULTRA ANCHOR Your Strongest Connection to the Sea. TUBULAR CONSTRUCTION Designed and made in Türkiye, the ULTRA Anchor range is the pinnacle of anchoring technology and design. Completely handmade from 316L - 318LN stainless steel and hand polished, every ULTRA Anchor is designed for excellence. The ULTRA Anchor demonstrates why a correct weight distribution and design is so important when setting and recovering your anchor. In fact, invert any ULTRA Anchor, and it will instantly recover itself into attack position. Such performance has been achieved with the innovative patented features this...

Smooth Rotation, Perfect Retrieval. The breaking strength of the swivel is typically higher than th e chain it is connected to and allows 30 degree rotation with complete 360 degree swivel. The ULTRA Flip Swivel is fabricated with a unique flipping nub, assisting in recovering the anchor right-side up into the bow roller. This flipping nub, combined with the rear bridge and ULTRA Flip Swivel's rotation and complete 360-degree swivel ability, ensures setting and recovering your anchor is an easier and safer task. Hexagonal head locking bolts prevent the need for additional grub screws to secure...

Where Every ULTRA Anchor Belongs. BOW ROLLER CAR 318LN polished duplex stainless steel. The best results are achieved especially by ULTRA Anchor. Each ULTRA Anchor has a different size ULTRA Bow Roller. This way, the best harmony is achieved. However, if it is needed, ULTRA Anchors may be used with one size smaller or bigger ULTRA Bow Rollers. The connection holes are left to the user to decide, considering the bow roller's location on the boat. However, if the user gives the locations of those holes with the order, they can be manufactured with those holes. The body material is 316L polished...

HIGH POLISHED 316L STAINLESS STEEL ROPE GUIDES ULTRALINE Flat Rope Reel is designed and made in Turkiye as a solution for bulky mooring lines, towlines, or stern anchor lines, to store a significant length of line in a compact space. The reel housing is constructed from highly polished 316L stainless steel and is available in various lengths of UV-resistant *Dyneema line, ranging from 40m-100m (80- 330 feet). The 316L stainless steel casing does not rotate; line rotates inside on hub and does not interfere with nearby equipment. Scale indicates approximate amount of line in use. ULTRALINE uses...

ULTRA / ADDITIONAL products ULTRA ANCHOR RING ULTRA CHAIN GRAB WHOLE CHAIN LENGTH DIAMETER APPROX. ULTRA Anchor Installations ULTRA FLIP SWIVEL SELECTION TABLE scope (busy anchorage or limited anchorage area), ULTRA Anchor Ring increases safety by adding weight to the anchoring system. By adding extra weight on the chain ULTRA Anchor Ring reduces the vessel swing area. ULTRA Anchor Ring works as a shock absorber improving comfort at the anchor by reducing boat movement. ULTRA Anchor Ring will be an important recovery tool; This is especially relevant in conditions where entering water is not...
