ADVANCED TECHNOLOGY TRIGGER RELEASE SNAP SHACKLES & HARDWARE MARINE HARDWARE www.tylaska.com

From the detailed assembly, finishing and individual testing of each unit, Tylaska shackles provide discriminating sailors with the ultimate in strength, performance and durability. New two piece flanged pin design resists shear and cracking prazisions-geschliffenem Edelstahl 17-4PH nimmt hohe Scherkráfte auf Axe frontal massif, usiné avec précision, résiste au cisaillement Contoured finger trigger hole for easy operation erlaubt enifache Handhabung Anneau passe-doigt profilé, pour une ouverture aisée Reinforced hole adds strength, reduces wear Die Bohrung ist verstárkt und dadurch...

Tylaska T5 Snap Shackles are perfect for small boat applications requiring high strength and low weight. They have a breaking strength of 5,000 lbs and weigh just 2.2 ounces in the standard bail configuration. Ideal for J-24s, Mumm 30s SB - Standard Bails provide ample room for attaching a line while keeping weight and overall shackle length to a minimum. Ideal for halyards and sheets. LB - Large Bails provide room for up to three additional shackles or a combination of shackles and lines. Ideal for spinnaker sheets, guys or other multi-line applications. CB - Clevis Bails do not require...

Tylaska T8 Snap Shackles are perfect for applications requiring high strength and low weight. They have a breaking strength of 8,000 lbs and weigh only 3.5 ounces in the standard bail configuration. Ideal for the 24 to 36 foot sailboat. SB - Standard Bails provide ample room for attaching a line while keeping weight and overall shackle length to a minimum. Ideal for halyards and sheets. LB - Large Bails provide room for up to three additional shackles or a combination of shackles and lines. Ideal for spinnaker sheets, guys or other multi-line applications. CB - Clevis Bails do not require...

Tylaska T12 Snap Shackles are perfect for applications requiring high strength and low weight. They have a breaking strength of 12,000 lbs and weigh only 5.6 ounces in the standard bail configuration. Ideal for 30 to 45 foot boats. T12 SB- Actual Size LB- Actual Size CB- Actual Size SHACKLE A in (mm) TYPE 3⁄4 (19.1) T12 SB 3⁄4 (19.1) T12 LB 3⁄4 (19.1) T12 CB B C D E THICKNESS WEIGHT in (mm) in (mm) in (mm) in (mm) in (mm) oz (gm) 25⁄32 (19.8) 3⁄4 (19.1) 3⁄4 (19.1) 4 (101.6) .45 (11.4) 5.6 (159) 25⁄32 (19.8) 11⁄8 (28.6) 13⁄16 (30.2) 41⁄2 (114.3) .45 (11.4) 7.2 (205) 25⁄32 (19.8) 25⁄32 (19.8)...

I The T20 is a larger shackle designed for mid to large sized boats. They are popular ^ on the America's Cup racing circuit. The T-20 has a breaking strength of 20,000 lbs. Standard bail configurations weigh only 11.9 oz. Ideal for 40 to 70 foot sailboats. Tylaska Marine Hardware, 800 Flanders Road, Mystic, CT 06355 USA I Phone (860) 572-8440 I Fax (860) 572-0534 I www.Tylaska.com WORK LOAD Clevis Bails

Tylaska T30 is designed for large sailboats that need to support strong loads. With a breaking strength of 30,000 pounds, this shackle can handle sail loads on the largest of sailboats. A number of around-the-world racing teams utilize the T30. Every unit is pull tested and released under several different load conditions before shijl Tylaska Marine Hardware, 800 Flanders Road, Mystic, CT 06355 USA I Phone (860) 572-8440 I Fax (860) 572-0534 I www.Tylaska.com

SB - Standard Bails provide ample room for attaching a line while keeping weight and overall shackle length to a minimum. Ideal for halyards and sheets. LB - Large Bails provide room for up to three additional shackles or a combination of shackles and lines. Ideal for spinnaker sheets, guys or other multi-line applications. CB - Clevis Bails do not require splicing and provide moveable attachments to rings, deck fittings, furlers, rolling furlers, etc. Ideal for many uses. Every unit is pull tested and released under several different load conditions before shipping. Tylaska Marine...

SB- Actual Size LB- Actual Size Locking Pin Provides Extra Security From Accidental Release Trip with Lanyard or Trigger CB- Actual Size Tylaska Marine Hardware, 800 Flanders Road, Mystic, CT 06355 USA | Phone (860) 572-8440 | Fax (860) 572-0534 | www.Tylaska.com 9

Tylaska trigger release snap shackles are meticulously designed using both computer software and actual "make and break" laboratory prototyping for real verifications. Our patented mathematical curvature of the release mechanism allows our shackles to be opened easily-even under tremendous loads. This real-life application of vector calculus makes our shackles both unique and superior to others on the market today. Tylaska shackles are machined and constructed in-house in Mystic, CT USA and made to near-military specification. Every single snap shackle is individu- ally tested to half its...

STAN DARD/STAN DARD WORK LOAD Tylaska Marine Hardware, 800 Flanders Road, Mystic, CT 06355 USA I Phone (860) 572-8440 I Fax (860) 572-0534 I www.Tylaska.c

WELDED RING VERSION Tylaska shackles are also available as a stock item joined together at the bails. This arrangement is ideal for temporarily holding the guy during a running spinnaker change or "peel" as it is sometimes called. Using an elaborate molding technique, Tylaska casts the two bails inked together as one unit, eliminating weakness from cutting and welding as is normally done by the competition. Two Tylaska trigger shackles are then fitted to the linked bail to produce a "peeling strop" or "handcuffs" as they are often nicknamed. Other configurations available upon request...

J-LOCK Shackles Easily spliced onto Genoa sheets, outhauls and halyards, the new low-profile Tylaska J-Locks fit through most Genoa blocks for fast sheet changes. Unique patented double-locking plunger locks in two directions for the ultimate in flog-free operation. UNLOCKED POSITION J-Lock opens only when the knob is rotated so that its notch is aligned with the body’s tab. Top view of J-Lock Shackle LOCKED POSITION The notch in the knob is turned away from the tab on the body and seated on the keyway shown below. Keyway prevents knob from rotating. Side View of Keyway “Knob” type pull pin...
