Emergency Shutdown Link

Emergency Shutdown Link
3Pages

Catalog excerpts

TRELLEBORG MARINE SYSTEMS • Emergency Shut Down (ESD) link for ship to shore & ship to ship applications • Used in LPG, liquid chemical and oil transfer applications • Suitable for use in SIL2 environment under IEC 61508 • Ensures galvanic isolation between ship and shore • ‘First-up’ indication for ESD location • Suitable for Ex ia llB hazardous area applications • From the world leaders in ship to shore safety link systems SmartPort by Trelleborg is a technology platform that connects disparate, data-driven assets, giving stakeholders a holistic view of operations to power communication and decision making.

Open the catalog to page 1

Emergency Shutdown Link The transfer of hazardous liquids in a marine environment necessitates the use of linked Emergency Shut Down (ESD) systems. In order that these systems can interact reliably and rapidly, Trelleborg Marine Systems has developed its Trelleborg SeaTechnik™ Emergency Shutdown Link (ESL) system. The ESL offers a reliable link between the two interconnected ESD systems involved in the transfer, enabling rapid and controlled shutdown of the transfer operation in emergency situations. Complementing our world leading range of other ESD link products and systems, the ESL is...

Open the catalog to page 2

Standard Ship Side: Control Unit Ship Side Box Port Ship Side Box Starboard Umbilical Cable and Reel Pendant Ship Test Unit Standard Shore Side: • Control Unit (ESL-8166) Additional components required: • Fixed cable for ship and shore Service & Support Trelleborg Marine Systems has been designing, manufacturing and supporting leading edge marine energy management and safety systems for over 20 years. With the head office located in Northwest UK, a team of experienced service engineers and performance analysts/specialists provides installation, commissioning and in-service support...
