MPD-MULTI PUMP DRIVE The MPD STELLADRIVE is an innovative module that fits between an engine and a transmission to drive a multiple hydraulic pumps or any other suitable implement. The MPD mounts directly to the engine SAE housing and flywheel and uses an integrated flexible coupling to dampen torsional vibrations and compensate for misalignment. The output is a SAE dummy flywheel and housing that connects to any SAE driven equipment such as marine gears, PTOs like Transfluid’s HFO/HFR (oil/air actuated PTO), KPTO (fluid coupling) and PF-PTO (PTO with RBD rubber coupling) or any other SAE transmission...

Dimensions are subject to alteration without notice * deduct 20 kg for each head ** @ max. speed *** not SAE standard

SPD - DUAL PUMP DRIVE The SPD is an innovative modular split power drive designed to be mounted on industrial engines with SAE flywheels and housings. The input is a rugged Rubber Block Drive flywheel coupling. This elastic coupling absorbs radial and angular misalignments as well as dampens torsional vibrations. The SPD output is a dual pad SAE A or B pump tower as well as SAE flywheel and flywheel housing. To allow for easy installation the pump tower can be mounted in 12 possible positions over 360 degrees. The output flywheel can accept transmissions, pumps, compressors and PTO’s. Input elastic...

TECHNICAL DATA * @ 3000 rpm Dimensions are subject to alteration without notice

Head extension for MPD18 and 22 only DIMENSIONS *from main shaft axis When there is interference between the pumps mounted on the MPD and the driven device, the head extension kit is the perfect solution. This kit mounts on any head and provides an extra 164 mm of clearance for MPD18 and 190 mm for MPD22. Additionally, the extension kit reverses the rotation of MPD head making it useful where engine rotation is required. Dimensions are subject to alteration without notice

Head PTO for in-line and pulley mounting TECHNICAL DATA SU free standing (without pilot bearing) TECHNICAL DATA Dimensions are subject to alteration without notice

INSTALLATION EXAMPLES MPD with HFO OIL ACTUATED PTO SPD with HFR OIL/AIR ACTUATED PTO MPD with KPTO VARIABLE FILL FLUID COUPLING MPD with RANGERMATIC POWER SHIFT TRANSMISSION MPD with INPUT and OUTPUT CARDAN SHAFT (FOOT MOUNTING) MPD with MARINE GEAR TRANSFLUID BEIJING TRADE CO. LTD Beijing Ph.: +86.10.60442301-2 [email protected] TRANSFLUID FRANCE s.a.r.l. 38110 Rochetoirin Ph.: +33.9.75635310 [email protected] NORTH EUROPE TRANSFLUID B.V. (Bellmarine) NL-3812 RB, Amersfoort Ph. +31 (0)85 4868530 [email protected] TRANSFLUID UK LTD London Ph. +44.7445501066 [email protected]...
