TECHNOLOGY FOR SUSTAINABLE FISHERIES

SUSTAINABLE FISHERIES After 2nd World War Simrad introduced the first Sonar to the fishing world. Since then, the ways and means of fishing have evolved to become technology based. And at the forefront of this evolution, you'll find Simrad. To lead in this technological change is to shape the world of fishing and through ideas and innovations Simrad has done just that.

51M RAD GNSURGS FULL CONTROL WITH THG FULL PICTURE... Flexible complete vessel solutions With a complete hydro acoustic package from Simrad you benefit from having equipment onboard that has been designed to operate together. Integration of all the fish finding electronics improves the overall performance during all phases of fish finding, The Simrad global service and support network gives you peace of mind, knowing that wherever you land in the world Tailor made equipment for all types of fishing vessels Coastal fishing vessels Rugged and reliable equipment ensures maximum fishing time...

With the full circle beam stabilisation, you will always maintain a clear picture of the targets even in rough seas. The combination of horizontal and vertical beams displays the school of fish from above and from the side at the same time. Great emphasis has been placed in giving the best possible overview in the search and catch situation. In addition, full screen echo presentation, resizable windows, off center, zoom and dual operation are standard functions on all sonar models.

sonars SX90 Low frequency, long range sonar 90° tilt SH80 High definition sonar 60° tilt SX90/SH80 Hull Units

TRACKS TARGETS OTHERS CANT SGG! User selectable frequencies between 20 -30 kHz give longer range and prevent interference from other vessels. The SX90 is a low frequency, high-definition; long range Sonar that utilizes two high-end computers to process data from the transducer. The SX90 is specially designed for vessels where range is criteria No.1. With the large data capacity in the dual computer signal processor there are several unique possibilities for beam forming. Three different vertical beam widths, single or dual vertical view and 180° tiltable vertical view are available. At 30...

Numbers of markers with exact latitude/longitude positioning. Separate gain and range selection for horizontal and vertical presentation. Selection of "Full Screen" or "Menu" p ­ resentation. Easy selection of your trawl or purse seine symbol. Storage of your echo picture for later evaluation. Roller ball for easy and fast c ­ ursor ­positioning. Enlarging the echoes for more detailed information. Optimizing the most interesting echo view. Target tracking of three individual targets. New Simrad SX90 low frequency sonar Off center presentation Full screen presentation ”Two sonars in one”...

THG PGRFGCT CATCH MACHINES Simrad high definition sonars detect weak and scattered targets under difficult conditions. This is a perfect catching machine, ideal for mackerel and tuna detection and evaluation. The combination of horizontal and vertical beams, display the school of fish from above and from the side at the same time. This gives you vital school data, without having to go over the target. Full beam stabilization maintains a clear picture of the target in rough seas and the multi frequency rejects interference from other vessels. All our sonars have dual mode, so you do actually...

5IMRAD 5H80 -116 KHZ HIGH DEFINITION SONAR Purse seine data The seine indicator shows the time from when the net was shot, the length of shot net, and the total net length. Also the net sinking is shown graphically. With a Simrad PI system connected, the correct net depth and sink rate will be shown in relation to the school The yellow purse seine symbol is set around the school. The seine dimensions are entered into the sonar for up to three different purse seines. When using the PI system and depth sensors, each mark will have depth and sink rate values indicated on the screen next to...

SHSO Hull unit any Simrad sonar and gives you vita nformation about fishing gear performance on your sonar screen PI system with echo- sounder display advanced Simrad

TAK€S FISHFINDING TO THE NEXT LÊV6L Professional mariners around the world rely on Simrad electronics to deliver a safer and more profitable time at sea. The new professional range of Simrad echosounders offers a choice of models from 15" to 23" displays in bright TFT colors. High power, advanced receiver technology and effective Simrad transducers ensure a detailed, clear and positive graphic depiction of the seabed and of single fish.

Single beam Split beam

CHOose size AND species Simrad's extensive experience in hydro acoustics has allowed the development of the world's most advanced echosounders for professional fishermen. The ES60 series has been designed with high performance at any depth a priority. It is easier to use than many less sophisticated instruments and offers flexible installation options with a variety of display sizes to fit any bridge arrangement. By choosing various modules, a customized system can be built to the owners need.

A RELIABLE GCHOSOUNDGR RANGE FOR ANY SIZG OF VGSSGL ES60 with single beam single frequency. than one echo sounder, it is actually several hundred echosounders. This is because you can configure starting with one frequency (at your choice) and a single beam echo- sounder to a multipple frequency split beam system. Picture shown left displays a one frequency system with the clarity and resolution only operation makes the ES60 very easy figure the screen the way you want with rezising the different windows to suit your needs. The most common dual frequ- and range set induvidually. You can ency...

The ES60 is the third generation split beam echosounder from Simrad. With the split beam you can determine the size of the fish before you catch it. This is vital for sustainable and profittable fishery. The picture to the right shows split beam system. The biomass in- formation tells you the density of the fish concentration, the so called "fuel split beam system fish sizes shown on the screen, here the majority of the fish is larger than 25cm. The fish plot at the bottom is widely used to detect fish close to the bottom where the depth varies. Sometimes ghost echoes are displayed in the...
