SHURflo prioritizes strong relationships with customers, employees, and suppliers, emphasizing respect, partnership, teamwork, and customer feedback. The company is dedicated to delivering high-quality marine products and ensuring customer satisfaction.
With over 30 years of experience, SHURflo is known for innovative designs, high-performance materials, and superior construction in marine products. It offers robust warranty programs and was the first U.S. marine pump company to achieve ISO-9001 certification.
SHURflo integrates new technologies to enhance performance, focusing on low amp draw, high flow, ease of installation, and maintenance-free designs.
- ULTRAflo Dual Head Pump: Designed for high flow with smooth operation and minimal amp draw.
- Macerator Pump: Suitable for sanitation waste and fish box evacuations, featuring a high-quality motor and splash-proof design.
- Pump/Accumulator Combo: Offers a self-priming, fully-automatic system for consistent water pressure and reduced cycling.
- Aqua King™ Pumps: Available in various models for different applications, providing reliable water delivery with varying flow rates and pressures.
SHURflo provides specialty pumps like refrigeration circulation pumps and pressure regulators for specific marine applications. Accessories such as in-line filters and strainers enhance pump performance and longevity.
SHURflo's marine products enhance the boating experience by providing reliable, high-performance solutions that are easy to install and maintain. The company's commitment to quality and customer satisfaction is evident in its product offerings and support services.
The document details SHURflo marine products, including in-line filters, pump systems, accumulator tanks, and fittings, designed for marine environments, RVs, and homes, addressing water filtration and pumping needs.
Multiple models of in-line filters are listed, specifying chlorine reduction capabilities, flow rates, pressure limits, and fitting sizes. Filters come in sizes like 2x6”, 2x10”, and 2.5x11”, with fittings such as FPT, John Guest, and barb ends. Some models include KDF media for enhanced filtration.
SHURflo offers filter housings with and without bypass valves, compatible with various replacement cartridges designed to reduce contaminants like chlorine, lead, cysts, and VOCs, with capacities from 500 to 11,000 gallons.
A 30 oz sports bottle with a high-grade ionic adsorption microfiltration system is available, capable of reducing contaminants such as lead and chlorine, refillable up to 800 times.
Details on pump systems like the ULTRAflo Dual Head Pump and accumulator combos are provided, designed for high flow and low pressure applications, featuring self-priming, corrosion resistance, and the ability to run dry without damage.
SHURflo accumulator tanks reduce cycling pulsation and pressure spikes, extending pump life. They are NSF certified and handle pressures from 20 to 125 PSI.
A variety of fittings, including straight, elbow, and tee fittings, made from materials like polypropylene and nylon, are compatible with SHURflo pumps and accessories.
SHURflo provides repair kits for maintaining pump performance and reliability, available for various models, including the Aqua King and ULTRAflo series.
General installation notes emphasize proper ventilation and ignition protection. Recommended pump position is motor up/pump head down to prevent water damage. Mount pumps on a solid surface to reduce noise and vibration. Use SHURflo fittings, which are hand-tightened, eliminating the need for expensive brass or stainless fittings. A safety sea-cock is required for installations using a thru-hull water source. Diaphragm pumps should be placed above the waterline as per ABYC guidelines. Pumps are self-priming and can be mounted up to 30 feet horizontally from water supplies. Rubber mounting feet minimize noise and vibration; use proper fasteners. Each pump should be individually fused. Minimum tubing size is 3/8” I.D., but 3/4” I.D. is recommended for maximum flow. Waterguard™ filters should be replaced every 6-12 months or when taste/odor issues arise.
Use flexible hoses to reduce noise and ensure proper pump function. Wire size requirements vary based on distance from the battery to the pump. For bilge pumps, attach the base to the hull using stainless steel screws and use smooth bore hoses for optimal performance.
Single Fixture Systems: Mount the pumphead 4” or less above the water tank bottom. Washdown Systems: Use marine-approved reinforced hose and a Guardian™ raw water strainer. Shower Sump Systems: Employ a sump tray with adequate strainer capability. Livewell Systems: Use marine-approved reinforced hose and a Guardian™ strainer between the thru-hull fitting and pump inlet.
SHURflo Headquarters in Santa Ana, California, and SHURflo Europe, Middle East, Africa in Crawley, UK.
Catalog excerpts
First in Fluid Innovation
Open the catalog to page 1
We put a lot into our products, so you get a lot out. Quality After more than three decades in the business, we know that producing quality products is the surest way to happier customers and a leading reputation. We wouldn’t change that for anything. And it shows. Innovative designs. High-performance materials. Superior construction and durability all add up to quality products that Pro BlasterTM more marine customers choose over any other in the industry. Performance At SHURflo, our ongoing goal isn’t just performance, it’s outperformance. And we achieve this goal by implementing new technologies....
Open the catalog to page 2
MARINE New Products It’s all about convenience. Making your boating experience as comfortable as if you were at home. SHURflo’s newest products are designed to do just that. For example, take our Waterguard filtration products. A full line of exceptional, NSF listed products that deliver clean, great tasting water. Installation is easy and operation is flawless. ULTRAflo Dual Head Pump The SHURflo ULTRAflo Dual Head Pump is designed to give the ultimate in pumping capabilities; smooth high flow, minimal amp draw and easy electrical and plumbing connections. The ULTRAflo Dual Head Pump is optimal...
Open the catalog to page 3
MARINE Product Category 1 Aqua King™ Multi-Fixture Automatic Demand Pumps SHURflo engineering at its finest. These potable water pumps are self-priming and employ three independent pumping chambers to lift water up to 8 ft [2.4m], smoothly and quietly. Built-in check valves rated to 200 PSI [13.0 BAR] prevent backflow into the tank. They can even run dry without damage. MARINE Name Model # Description Voltage Dimensions Flow Rate Amps Shut-off Inches/Millimeters OEM# / Aftermarket# GPM/LPM (Max.) Pressure MARINE Aqua King™ Premium (A) Fresh Water Pump 2095-212-234 2095-212-334 Intermittent duty...
Open the catalog to page 4
Heavy Duty & Continuous Duty Livewell Pumps The Pro Baitmaster™ is excellent for livewell or washdown applications in harsh marine environments. It is completely encapsulated by SHURCote™, a tough waterproof coating protecting it from splashed liquids. Featuring marine tough sealed shutoff switches and ignition protection, the Baitmaster™ is rated for continuous duty application. Name Model # Description Dimensions Port Size OEM# / Aftermarket# Pro Baitmaster™ Pro Baitmaster™ Flow Rate Amps Shut-off (Max.) pressure 3.75 GPM [14.0 LPM] 9.5 45 PSI [3.1 BAR] 3.75 GPM [14.0 LPM] 9.5 45 PSI [3.1 BAR]...
Open the catalog to page 5
MARINE Product Category 2 Hand Pump SHURflo’s new and improved hand pump is both durable and long-lasting. Simple to install and operate, delivering maximum SHURflo performance and quality. This exceptional leak-free hand pump fits most existing openings with little or no modification. Corrosion-resistant for long-life. MARINE Name Model # Tank Discharge Prime Maximum Inlet Ports Spout Rotation Flow 5 PSI [0.3 BAR] 6’ [1.8m] 100 PSI [7.0 BAR] Tank 3/8” Barb City Water 1/2” MSPT† 270˚ 0.4 GPM [1.5 LPM] 30 strokes per minute OEM# / Aftermarket# Water Wizard™ 150-000-00 150-001-00 MARINE Washdown...
Open the catalog to page 6
Specialty Pumps Specifically designed for refrigeration cold plate circulation, these pumps allow you to adjust water flow according to your system. Each features a positive displacement three-chamber diaphragm — self-priming to 4-ft [1.2m] vertical — and EPDM valves for proven priming ability and longer life. Name Model # Description Dimensions Flow Rate Amps OEM# / Aftermarket# Maximum Pressure A Refrigeration Circulation Pump (A) 8050-261-105 8050-261-105 12VDC- No switch. 7.25” x 4.25” x 4.40” 0.5 GPM Continuous duty motor. [184mm] x [108mm] x [112mm] [2.0 LPM] 1.7 30 PSI [2.1 BAR] Cold plate...
Open the catalog to page 7
MARINE Product Category 3 Water Systems Accessories MARINE A B Designed for safety and convenience, SHURflo accessories are built to last. From a variety of innovative debris strainers that protect your pump, to check valves and spray nozzles. Big protection from small, yet essential products. Name Model # Description Designation OEM# / Aftermarket# In-line Strainer (A) 1/2” [13mm] Barb 1/2”-14 NPS Twist-on Water Strainer (B) 170-060-20 170-060-29 Easy Assembly. Keeps debris out of pump. Easy to see when strainer needs cleaning. 50 mesh stainless steel screen 1/2” [13mm] Barb Inlet 170-061-20...
Open the catalog to page 8
Filter Housings NSF ® Hassle-free bottled water quality for only pennies per gallon. Each easy installation kit includes cartridge, wrench, mounting hardware, m/f garden hose fittings and a 12”[305mm] garden hose. A built-in bypass valve allows for easy winterizing and convenient cartridge changes (Models RV-10VIH and RV-5VIH). One year warranty. Name Model # Bypass Cartridge Replacement Filter Size OEM# / Aftermarket# Valve Included Cartridges Available and Fitting Accessories Included 5” [127mm] Housing Assembly RV-5UC RV-5UC-A No RV-5C2 RV-5C2, RV-5RVOC 5” [127mm] Housing, 3/8” [10mm] FPT...
Open the catalog to page 9
MARINE Product Category 4 The ULTRAflo Dual Head Pump The SHURflo ULTRAflo Dual Head Pump is designed to give the ultimate in pumping capabilities; smooth high flow, minimal amp draw and easy electrical and plumbing connections. Optimal for high flow needs such as dual pump installations on larger boats, high flow washdown and high flow/low pressure continuous duty. Name Model # Description Liquid 12VDC ULTRAflo Dual Head Pump Amps Flow Shut-Off Port Size Temperature OEM# / Aftermarket# (Max) Rate Pressure Inlet/Outlet 15 5.6 GPM 45 PSI 1/2” [13mm] PMT [21.0 LPM] [3.1 BAR] 3/4” [16mm] 4000-410-014...
Open the catalog to page 10
MARINE Fittings For Tubing & Hose Many optional fittings are available for use with SHURflo pumps and accessories. Models include † straight, elbow and adapters. Fittings accommodate all SHURflo pumps with 1/2”-14 MPS threads. Straight Fittings MARINE Model # Style Material Description 8-070-01 Hex swivel Polypropylene 1/2"-14 NPT (F) x 1/2" Barb 8-071-01 Hex swivel Polypropylene 1/2"-14 NPT (F) x 3/8" Barb 8-154-01 Wingnut swivel* Polypropylene 1/2"-14 NPT (F) x 5/8" Barb 8-156-01 Wingnut swivel* Polypropylene 1/2"-14 NPT (F) x 3/4" Barb 8-161-01 Wingnut swivel* Polypropylene 1/2"-14 NPT (F)...
