2011 Full Line Catalog Marine Antennas 1

5225-XP Galaxy XP 8' VHF 6dB Gain Collinear-Phased 5/8 Wave Elements For the toughest of the tough jobs, Shakespeare introduces the extra edge of silver plated elements on world-renowned, world class, Galaxy marine VHF antennas. The new 5225-XP is a maximum range antenna built in a Shakespeare extra tough fiberglass radome. It’s designed to withstand the wind forces and high speeds when used on hard-tops, T-tops, and radar arches. The silver plating adds extended performance for extra reliable communications. The antenna’s legendary Galaxy high-gloss finish assures that it's welcome aboard....

® Galaxy Eliminator Series ® ® 8' VHF 6dB Gain They grate on your nerves, those shrill squawks and squeaks, whistles and tones that sporadically erupt from even squelched marine VHF radios. Pure noise to most folks, “Intermod” and “Out-of-Band Interference” are what experts call it. And sorry to say, the closer you get to busy seaports, harbors or shipping channels, the more Galaxy Eliminator 5225-FLT likely you are to experience this interference. To reduce the effects, Mariners have traditionally used externally mounted notch and band-pass filters. Unfortunately, these bulky filters are...

Galaxy® VHF Antennas 5400-XT LITTLE GIANT TM 5401-XT LITTLE GIANT TM 5415 4' VHF 3dB Gain 4' VHF 3dB Gain 2' VHF 3dB Gain Shakespeare Galaxy Antennas have long been revered Center-Fed 1/2 Wave Coaxial Sleeve Center-Fed 1/2 Wave Coaxial Sleeve Low Profile End-Fed 1/2 Wave An outstanding, 4' antenna of heavy-duty construction for general purpose communications. It’s at home on T-tops, hard-tops and other positions aloft, where its small size can deliver maximum range. •Brass and copper elements to maximize range •High-gloss, non-yellowing polyurethane finish •Stainless steel ferrule with...

5399 5230 HS-2774-1 8' VHF 6dB Gain 9'6" VHF 6dB Gain 14' VHF 8dB Gain 6'5" Broadband VHF Collinear-Phased 5/8 Wave Elements Galaxy VHF 5225-XT Extra-Tough Collinear-Phased 5/8 Wave with Two Coaxial Chokes to Suppress Cable Radiation 5/8 Wave Over 1/2 Wave Dipole 136 -174 MHz Broadband The ultra-performer, Shakespeare’s Style 5230 is the most effective 8dB antenna system available anywhere, thanks to its increased signal capture area. •Brass and copper elements for maximum range and efficiency •High-gloss, non-yellowing polyurethane finish •Stainless steel ferrule with standard 1"-14 thread...

Galaxy® HF/SSB Antennas Galaxy® VHF Sailboat Antennas At last, legendary Galaxy performance is available in two new sailboat antennas For long-range communication, HF/SSB literally bounces a signal off the earth's ionosphere to "skip" around the globe. that are specially designed for easy masthead mounting. They feature our Shakespeare's quality Galaxy Antennas deliver the high performance your transceiver needs to do the job. Galaxy good exclusive solderless connector system for easy removal and reinstallation. looks, and supreme performance. Attractive, convenient, and sailboat friendly,...

Galaxy® Specialty Antennas Shakespeare's Galaxy Loran C, DGPS, CB and Wi-Fi antennas make your boating easier and more fun. With looks that match our other Galaxy Specialty Galaxy antennas, these specialty antennas rule! 5223-XT 5248 8' CB Unity Gain 2' Wi-Fi Antenna 8dB Gain Continuous-Load, End-Fed 1/2 Wave You are not alone, especially if you have a Wi-Fi enabled computer system onboard. This sturdy Shakespeare Galaxy antenna of 2' overall length brings the wonder of Wi-Fi to the marine environment. It features an N-type connector and a special sleeve-collar ferrule design that...

5412-S 5237-XT 4' Dual Band Cellular 3dB Gain 2' Dual Band Cellular 3dB Gain 8' Dual Band Cellular 3dB Gain 800/900 MHz and 1800/1900 MHz Cellular Galaxy Cellular 5410-XT LITTLE GIANT TM 800/900 MHz and 1800/1900 MHz Cellular 800/900 MHz and 1800/1900 MHz Cellular This compact, extra sturdy antenna covers the digital, analog and PCS cellular bands. For quality and reliability, the antenna is hand-finished and its connections hand-soldered. Use one of Shakespeare’s CPA Series adapters to connect your portable cell phone. •Brass and copper elements to maximize range •High-gloss, non-yellowing...

Galaxy Satellite Radio Antennas ® SM-30 SM-30 and SM-32 Surface Mount Kits service subscription required, available separately. For more information on the services visit www.sirius.com. For Galaxy SRA-40 and SRA-25 Satellite Antennas Tiny as it is, it delivers plenty: weather, news, music, sports, and entertainment from Sirius Satellite Radio. The versatile SRA-25 accommodates a variety of mounting methods, with or without running its cable through the mounting surface. It comes with a 25-foot cable. The SM-30 and SM-32 provide a convenient way to mount a Shakespeare Galaxy SRA-40 or...

Galaxy® Extension Masts Stainless Steel Constructed with high-quality white Shakespeare fiberglass, and finished to match Galaxy antennas. This 112" ⁄ diameter extension mast can be used to increase height of an antenna and thus improve effective range, or to boost placement of an antenna above on-board obstructions. •Stainless steel upper and lower ferrules with standard 1"-14 thread •High-gloss, non-yellowing polyurethane finish •Mount: A Style 409-R or 410-R Mounting Kit is required •One section, actual length 95" Heavy-duty stainless steel extension masts with standard 1"-14 thread with...

Centennial® Antenna Series Developed to celebrate our first hundred years, Shakespeare Centennial antennas pack some of our most desired high-end features into affordable, mid-range, 8-foot antennas. Features include brass and copper elements, chrome plated brass ferrules, and a smooth, high-gloss finish that won't turn yellow in the sun. Great performance and great value. Centennial Series Centennial Series Antennas are not recommended for mounting on hard-tops. ® 24
