PRODUCTS & SERVICES CATALOGUE

SEC`sof Table new content developed Fully-Automatic Twistlock family INTRODUCTION Company profile SEC About SEC CONTAINER PART - GENERAL Code of container positions Container dimensions and tolerances Allowable loads Documentation Necessary data for quotation CONTAINER PART - STOWAGE SYSTEMS on Deck: Automatic solution for the bottom layer Longitudinal container arrangement Compensation of hatch cover movements by use of sliding/elongated foundations OSHA stowage system Transversal stowage system CONTAINER PART - FIXED FITTINGS ON DECK Foundations Lashing plates D-rings CONTAINER PART - FIXED...

Twist stackers Single stackers Double stackers Tension/pressure elements Fixed & loose lifting equipment Fixed & loose securing equipment for general cargo Hatch cover lifting stopper (Panlock-A) Height adapters Reefer platforms ISO-plugs Removable railing post ISO/EURO-Adapter pieces Cellguide systems Container blind trestles Lashing bridges Cellguide stoppers Lashing stages Reefer bridges Deck stanchions Consultancy Lashpots D-rings Web lashings Trailer horses Wheel chocks Master lashings Edge controllers July 2014 © Technical alterations reserved

0.4 Shanghai SEC Machinery & Equipment July 2014 © Technical alterations reserved

Ship‘s Equipment Centre Bremen (SEC) is considered to be today‘s worldwide leading manufacturer of container lashing equipment. The basis of this leading position is the perfect combination of in house design and engineering facilities. This combined with unique know how of manufacturing and services has made Ship‘s Equipment Centre Bremen as a first class partner for yards and owners. An enthusiastic team of high skilled experts is operating out of the main office located in Bremen, Germany. A city which provides an infrastructure where the cargo securing technology has quite a history. As essential...

Company profile SEC / services Ship`s Equipment Centre Bremen GmbH & Co. KG Speicherhof 5 28217 Bremen Germany P.O.Box 101504 28015 Bremen Germany Phone: Fax: Website: E-mail: Bank: Account-No.: Guidance-No.: SWIFT-BIC: IBAN No.: Chamber of commerce: Industrie- und Handelskammer Bremen Reg. Nr.: HRB 13231 Among a variety of makers and traders in this segment Ship‘s Equipment Centre Bremen is superior with regard to the engineering facilities which are world wide leading and unique in its kind. Whether it regards the integral calculation of entire lashing bridge designs for 18000 TEU giants by...

SECKOREA A SEC BREMEN COMPANY Ship's Equipment Centre (Shanghai) Co., Ltd Ship's Equipment Centre (Korea) Co., Ltd Room 1505, 500 Guang Dong Road Shanghai 200001 / P.R. of China E-mail: [email protected] #2304, Centum Leaders Mark Bldg., U-dong, Haeundae-gu, Busan, 612-889, Korea Corporate Registration Number: 617-81-95376 E-mail: [email protected] Bank: China Merchants Bank, Shanghai Branch No 16, Zhongshan Road (E.1), Shanghai Account-No.: 096903 - 008513562002 SWIFT-BIC: CMBCC NBS 051 In the two major ship building countries SEC operates their own branch offices with highly qualified staff....

For the complex welding procedure of row materials with high tensile strength such as lashing bars Shanghai SEC has important flash butt welding machines from Germany. For almost 20 years SEC equipment is produced in our own production company in Jiading district close to Shanghai in order to ensure continuously high quality of our products. Since 2008 the fabrication is certified by LRQA according ISO 9001 Quality Assurance System and OHSAS 18000 (Occupation Health Safety Assessment) as well as ISO 14000 (Environmental Management) have been initiated end of 2014. Beside of container securing...

SEC is considered to be today's leading manufacturer of container lashing equipment. The basis of this leading position is the perfect combination of in house design and engineering facilities. This combined with unique know-how of manufacturing and services has made SEC a first class partner for yards and owners. SEC can be a partner from the very start of a container vessel construction project. In addition to the delivery of hardware, a wide variety of services can be offered to help the ship owner find a safe and cost efficient solution. Whether approached by shipyards or owners, SEC is able...

Container part 1 GENERAL Available documentation Code of container positions Container sizes Container dimensions Container corner castings Container offset dimensions Common container spaces Static and dynamic components Permissible forces on containers Typical damages on containers Necessary data for quotation July 2014 © Technical alterations reserved

Together with our quotation a detailed specification describing the proposed securing solution will be provided. This also includes sketches showing typical lashing arrangement at midship section with preliminary weight distribution and item drawings for each fitting with all relevant dimensions. Item drawings can be transmitted by telefax or by e-mail (pdf-files). When receiving an order for the delivery of fixed fittings we will always prepare offset drawings showing the arrangement of foundations, lashing plates etc. for all positions on board. In these drawings the foundations and lashing...

The container securing arrangement (CSA) is a booklet showing the application of loose lashing gear and maximum weight distribution for a certain GM case. Approval of CSA is in the responsibility of the corresponding classification society. The cargo securing manual (CSM) according IMO is a booklet which contains all kinds of useful information about securing of cargo on board such as: - A material list with all fixed and loose securing fittings on board specifying safe working load, proof load, breaking load, material grade, name of maker etc. - Item drawings for all loose and fixed securing...

In each harbour the stevedore gang has to be informed how to install the lashings. For this offering instruction boards show-ing the application of lashings and twistlocks. These instruction boards in DIN A 3 size are made of plastic with self-gluing back for easy installation at the longitudinal hatch coaming or other suitable positions. which is also available on CD ROM on request. Most components of a twistlock, turnbuckle, bridge fitting etc. can be delivered separately. On request we will provide an individual spare parts catalogue for each newbuilding. This spare parts catalogue is listing...
