Seawind 950 Standard Specification

Product catalog summary

Specifications:
The Seawind 950 is a luxury yacht with an overall length of 9.5 meters (31 feet), a beam of 5.8 meters (19 feet), and a draft of 0.85 meters (2’7”). It has a displacement of 4.5 tons (7165 lbs) and is equipped with single helm cable steering. The yacht is powered by two 9.9hp Yamaha high thrust outboards, with a fuel capacity of 150 liters (40 US gallons) and a fresh water capacity of 250 liters (66 US gallons).

Standard Specifications and Equipment:

General: The yacht is designed to meet luxury world standards, using high-quality equipment throughout.
Exterior/Laminate: Features a gelcoat finish with a non-slip surface and a vinyl ester resin hull laminate.
Hardtop: Includes a fiberglass hardtop with toughened glass windows.
Mast/Boom/Sails: Equipped with a clear anodized mast and boom, single spreader rig, and various halyards and reefing lines.
Deck Equipment: Includes multiple hatches, mooring cleats, and a manual bilge pump.
Centre Cockpit: Features a dining table that converts into a double bed and upholstered cushions.
Forward Beam, Catwalk, and Trampolines: Includes a painted forward beam and a foam-sandwich fiberglass catwalk.
Aft Beam and Deck: Features an anodized aft beam and a mainsail sheet system.
Rudder System: Includes a stainless steel steering wheel with cable-linked steering.
Interior Finish: European Beech trim with high gloss finishes and carpeted cabin soles.
Galley: Equipped with a 2-burner LPG stove, stainless steel sink, and ample storage.
Sleeping Cabins: Includes solid doors, upholstered mattresses, and lined cabins.
Head: Features a manual toilet, sullage tank, and fresh water shower.
Lighting/Electrical System: Custom electrical switch panel, heavy-duty batteries, and individual cabin lighting.
Plumbing/Fresh Water Tanks: Fiberglass freshwater tank with a Jabsco pump and bronze fittings.
Navigation Equipment: Includes steering compasses and Raymarine Tridata for log, speed, and depth.
Engines: Twin Yamaha 9.9hp engines with remote electric start and dual controls.
Anchoring/Mooring: Primary anchor system with a manual winch and mooring lines.
Antifouling/Striping: Epoxy barrier coat with decorative striping.

Disclaimer: Specifications are subject to change at Seawind Catamaran’s discretion.

Catalog excerpts

SEAWIND 950 SPECIFICATIONS Overall Length 9.5 m / 31ft Beam 5.8 m / 19ft Draft 0.85 m / 2’7” Displacement 4.5 Ton / 7165lbs Steering Single Helm Cable Steering Motors 2 x 9.9hp Yamaha High Thrust Outboards Fuel 150 litres / 40 US Gallons Fresh Water 250 litres / 66 US Gallons

Open the catalog to page 1

Seawind 950 Specifications May 2011 STANDARD SPECIFICATIONS AND EQUIPMENT. (ADDENDUM 1) 1. GENERAL: The overall finish of the Seawind 950 will be consistent with a luxury world-standard yacht of this size and type. Only very high quality equipment is used throughout The overall aim is for a level of construction, workmanship, equipment, fitout and style comparable to the best boats available in the market at this price range. 2. EXTERIOR/LAMINATE: Finish: Gelcoat finish with moulded-in non-slip surface on deck areas. Hull Laminate: Vinyl Ester resin is used in manufacture of the hulls for the...

Open the catalog to page 2

Seawind 950 Specifications • • May 2011 1 x Anchor roller under deck. Permanent stowage position for 35lb Plough (CQR type) anchor. (cheeks 75mm high). Catwalk in foam-sandwich fibreglass. Supported by aluminium frame 100mm x 50mm. 8. AFT BEAM AND DECK: • Anodised aft beam. • Mainsail traveller track, traveller car and 3:1 traveller controls. • 8 to 1 Mainsail sheet system - Ronstan blocks. 9. RUDDER SYSTEM: • 1 X 26” stainless steel steering wheels. • Cable linked steering. 10. INTERIOR FINISH: • European Beech trim interior. • Cabin top lined with frontrunner carpet and vinyl. • Common area...

Open the catalog to page 3

Seawind 950 Specifications May 2011 14. LIGHTING/ELECTRICAL SYSTEM: • Custom made electrical switch panel with circuit breakers. • Tinned wire used throughout. • 2 x heavy duty 120 AH batteries. • 230amp heavy duty isolation switch. • All cabins with individual lighting. • Galley/saloon area - 2 x fluoro lights. • Diffused lights over aft deck - 2 lights. • Centre cockpit lighting. 15. PLUMBING / FRESH WATER TANKS: • Fibreglass freshwater tank. 250 litres total. External filler at mast base. • “Whale” system colour-coded piping throughout. • Jabsco fresh water pump with filters. • Bronze through-hull...

Open the catalog to page 4
