Introduction

The SEACSUB ARROW speargun is a high-quality, reliable underwater elastic speargun designed for sport and professional spearfishing. It is manufactured using advanced materials and production techniques to ensure durability, precision, and ease of use. Users must read the entire manual before use and retain it for future reference.

General Warnings and Safety

Users must comply with all national and local laws regarding minimum age, permitted zones, transport, and behavior.
Improper use can cause serious or fatal injuries to the user and others.
Repairs and maintenance must be performed only by authorized SEACSUB service centers.
New users should practice in shallow, safe conditions to become familiar with the speargun.
Never load the speargun in crowded or public areas; always load underwater with others at a safe distance.
Never point the speargun at people, even if the safety catch is engaged.
The safety catch is an additional precaution and not a fail-safe system.
Use internationally recognized signaling buoys to indicate presence in water.
Always unload the speargun after use before returning to shore.

Technical Specifications

Available lengths: 45, 55, 65, and 75 cm
Spear shaft lengths: 60, 70, 85, and 95 cm
Elastic bands (sandows) diameters: 14, 16, 18, and 20 mm
Spear shaft: 7 mm diameter harmonic steel with M7 threading and line guide
Elastic bands: Pair of 16 mm diameter bands mounted on the head
Safety catch: Red, located above the handle
Line release mechanism: Red
Barrel: Lightweight, anti-reflective treated alloy
Handle: Ergonomic design
Trigger mechanism: Stainless steel and high-resistance nylon to reduce friction
Accessories included: Carrying case, polyester nylon line (200 cm), single-flipper M7 spear tip

Assembly Instructions

Before first use, attach the 200 cm nylon line securely to the spear shaft's line guide using a slip knot or equivalent. Insert the spear shaft through the head and lock it into the trigger mechanism until an audible "click" confirms engagement. Route the line along the barrel to the line release device, loop it back to the head, and secure it with a knot. Adjust line tension to ensure it lies taut and properly secured.

Loading Procedure

Wear gloves for safety during loading.
Grip the elastic bands near the spear tip with the pinky fingers.
For the first notch loading, rest the handle against the abdomen or weight belt for support.
For the second notch or maximum power loading, rest the handle against the sternum center for better leverage.
Ensure the spear tip notch is properly engaged before slowly releasing the bands to avoid accidental discharge.
Engage the safety catch after loading and before transport.

Firing Instructions

Disengage the safety catch before firing.
Treat the speargun as a weapon and exercise maximum caution at all times.

Ten Important Safety Recommendations

Comply with all applicable laws regarding use, transport, and minimum age.
Never load the speargun in crowded or public areas such as beaches, rocks, or boats.
Load only underwater, keeping others at a safe distance.
Never point the speargun at people, even if on safety.
Consider the safety catch as an additional safety measure, not the primary one.
Securely position the speargun against the body before loading.
Use recognized signaling buoys to indicate your presence in water.
Never shoot near other divers or swimmers.
Do not use the speargun if any components show wear or damage; seek authorized maintenance.
Never use the speargun outside water to avoid damage and danger.

End of Day Procedure

Unload the speargun before returning to shore by reinserting the safety catch, holding the elastic bands above the spear tip, carefully disengaging the notch, and guiding the bands back to the head.

Care and Maintenance

Rinse the speargun with fresh water after every dive, including freshwater dives; demineralized water is recommended.
Flush saltwater residues from the trigger mechanism.
Dry the speargun thoroughly in shade, avoiding direct sunlight.
Periodically lubricate the trigger mechanism with silicone oil.
Avoid storing the speargun with heavy or sharp objects that could cause damage.
Avoid contact with oils, solvents, or gasoline.
If unused for over a month, rinse and dry thoroughly before storing in a cool, ventilated place.
After intense use or long inactivity, have the speargun inspected by an authorized service center.
Regularly check wear on key components: heads, elastics, shafts, spear tips, trigger mechanism, and pins.
Use only original replacement parts to maintain performance and safety.

Warranty Certificate and Conditions

SEACSUB provides a 2-year warranty from the date of purchase from an authorized dealer. The warranty covers defects due to unsuitable materials, design, manufacturing, assembly errors, or incorrect usage instructions. It is valid only for the first purchaser and is non-transferable without SEACSUB authorization. Unauthorized repairs or modifications void the warranty.

Warranty claims require returning the defective product through the original authorized dealer or another authorized dealer with prior approval, accompanied by proof of purchase (receipt or invoice). SEACSUB will refuse service if the product lacks proper documentation, shows damage from external causes, misuse, or use beyond intended purposes.

If SEACSUB refuses repair, the product will be returned at the owner's expense unless the owner requests and agrees to pay for the intervention costs within 15 working days.

Contact Information

For further information or technical support, contact SEACSUB at [email protected].

Catalog excerpts

Arbalète spearguns Fusiles Elásticos de buceo 16040 San Colombano Certenoli (GE), Italy

Open the catalog to page 2

Dieci importanti raccomandazioni utili a prevenire e allontanare il rischio

Open the catalog to page 3

Congratulazioni per aver scelto la qualità e l'affidabilità di un prodotto SEACSUB. L'attrezzatura da lei acquistata è stata realiz- zata con materiali selezionati e collaudati. Lo sviluppo e la continua ricerca ci permettono di essere in continua evoluzione . Processi innovativi di produzione, continui test e prove reali di funzionalità sviluppati nei nostri centri di ricerca garantiscono l'affidabilità che con- traddistingue tutti i prodotti SEACSUB. Leggere l'intero manuale d'uso prima di utilizza- Il manuale d'uso deve essere conservato per tutto il periodo di vita del prodotto! Avvertenze...

Open the catalog to page 4

Caratteristiche tecniche fucile ARROW

Open the catalog to page 5

fucile fino a raggiungere lo sganciasago- la, dopodiché effettueremo un passaggio attorno allo stesso per poi tornare alla testata. Adesso inseriremo l'estremità della sagola rimasta libera nell'apposita asola posta sulla testata effettuando nuo- vamente un nodo che vincoli la sagola all'asola stessa. ► Tramite il nodo stesso curate la tensione del filo in modo che lo stesso sia ben aderente al fucile e ben agganciato allo ► Il fucile adesso è pronto per l'uso fucile ARROW Leggere attentamente le istruzioni qua di segui- to riportate in quanto da esse può dipendere la vostra sicurezza e la continua...

Open the catalog to page 6

IMPIEGO DELL'ELASTICO E DELL'OGIVA ► Consigliamo di utilizzare sempre i guanti per effettuare l'operazione di caricamento ► Impugnate le gomme davanti alle ogive serrandole tra i mignoli durante l'esten- ► Per il caricamento alla prima tacca con- sigliamo di appoggiare l'impugnatura, appositamente studiata nella forma, all'al- tezza della pancia e precisamente sulla cintura dei pesi in modo da avere un punto d'appoggio importante e sicuro ► Per poter posizionare l'archetto nella seconda tacca o in alcuni casi in funzione della persona o della lunghezza del fucile, è richiesto un ulteriore appoggio...

Open the catalog to page 7

Cura e manutenzione del fucile Per mantenere ¡I vostro fucile in perfetta efficienza sono necessarie le seguenti pre- ► Dopo ciascuna immersione, comprese quelle in acque dolci tipo laghi o fiumi, il fucile deve essere risciacquato con acqua dolce corrente, l'eventuale uso d'acqua demineralizzata è consigliato. Assicurarsi inoltre di far fuoriuscire dal congegno di scatto eventuali residui d'acqua salata entrati durante l'immersione. Come ulti- ma operazione lasciatelo asciugare per un lungo periodo di tempo senza esporlo ► Lubrificare periodicamente il meccanismo di scatto con olio al silicone....

Open the catalog to page 8

- Istruzioni e avvertenze d'uso errate o 4. La garanzia si estingue automaticamente, e con effetto immediato, a seguito di intervenute riparazioni, modifiche,trasfor mazioni, adattamenti o manomissioni in genere effettuate sul prodotto finito o parti di esso non preventivamente auto- rizzate da SEACSUB e comunque effettua- 5. La garanzia dà diritto all'intervento e alla riparazione gratuita nel più breve tempo possibile, ovvero alla completa sostituzio- ne gratuita del prodotto (a scelta insinda- cabile di SEACSUB) o parti di esso dove venga riconosciuto da parte di SEACSUB difetti di funzionamento...

Open the catalog to page 9

Congratulations for selecting the quality and reliability of a SEACSUB product. The equipment you have purchased is manu- factured from high quality, tested materials. Development and constant research allow us to evolve continually. Innovative production processes, constant controls and testing under real conditions guarantee the reliability that all SEACSUB products are known for. Read this entire manual before using this equip- This manual must be retained tor as long as you General warnings ► Before using the Arrow speargun you must be familiar with all the safety regula- tions. Follow the...

Open the catalog to page 11

CHARACTERISTICS OF THE ARROW SPEARGUN

Open the catalog to page 12

Read the following instructions carefully. Your safety and the continued efficiency of your equipment depend on your having read these The Arrow speargun must always be trans- ported with care in bags and backpacks specially designed to contain underwater spear guns and avoid contact with heavy or sharp objects. Each time you transport or store your Arrow speargun, it is essential to protect the tip of the shaft with a protection tube. INSTRUCTIONS FOR CORRECT ASSEMBLY OF ► The Arrow speargun comes equipped with a 200 cm line to connect the shaft to the muzzle of the speargun. This must be Installed...

Open the catalog to page 13

► The correct positioning of the wishbone in the notch of the shaft must be carefully controlled and followed by a slow release of the slings once loading has been com- SHOOTING THE ARROW SPEARGUN Now the Arrow speargun is ready to be used, and as a final step, you must remove the safety catch that was previously inserted in order to be able to pull the trigger. It is advisable to always use extreme caution in using the underwater speargun as it is considered, for all effects and purposes, a weapon. ELEVEN IMPORTANT USEFUL RECOMMENDATIONS TO PREVENT RISK AND INJURY WHILE USING THE ARROW 1. Follow...

Open the catalog to page 14

damage to your speargun, for example, weight belts, cylinders, knives etc. ► Avoid contact with oils, solvents, or ► If you believe you will not be using the speargun for more than a month, It Is advisable to rinse every part carefully and let It dry thoroughly In the shade. Keep It perfectly dry In a cool, aerated place. ► At the end of a particularly Intense season, or following a long period of Inactivity, It is sound practice to leave the spear gun with an authorized service centre for a complete Inspection. We recommend that you contact your local Seacsub dealer to perform all maintenance...

Open the catalog to page 15

be the SEACSUB dealer from where the product was purchased. If this should be impossible, any other SEACSUB dealer subject to authorization, may be author- ized to ship the defective product. In order for the warranty to be valid, the product must be accompanied by a copy of the store receipt, Invoice, or other similar proof of purchase where the name of the authorized SEACSUB dealer and the date of purchase of the product are 7. If SEACSUB receives a product that: chase document with the abovemen- tloned characteristics - Has been subject to conditions that ranty according to point 4 above -...
