PROPULSION AND MANOEUVRING SYSTEM SCHOTTEL PUMP-JET YOUR PROPULSION EXPERTS SPJ · SCHOTTEL PUMP-JET The main or auxiliary propulsion unit even for extreme operating conditions.

MANOEUVRING SYSTEM EVEN FOR EXTREME OPERATING CONDITIONS The SCHOTTEL P ump-Jet is 9 special-purpose azimuth thruster that provides fuLL thrust in all directions. It is distin- guished by its compact and robust design and covers a power range from 50 to 3500 kW. A particular characteristic of the SPJ is its ability to operate in shallow water. Supplying full thrust at a minimum immersion of 150 to 750 mm, depending on the model involved, it can also be used on vessels with a very shallow draught. The SCHOTTEL SPJ has proved its worth as a reliable manoeuvring system, take-home device and main...

SPJ · SCHOTTEL Pump-Jet Gear box Steering motor Impeller Diffusor Housing ADVANTAGES • Fully-capable azimuth thruster • Compact design, space-saving installation with minimum displacement loss • Installation flush with the hull, therefore no increase in resistance and no risk of collision with floating debris • Ideal for operation in extremely shallow waters • Protective grid at the intake prevents damage by floating debris • Grounding possible. Hardly any risk of damage when the vessel contacts the ground • Low volume flow on the intake side and also a low intake velocity. Therefore no risk...

WHETHER AS MAIN OR AUXILIARY PROPULSION UNIT-THE SPJ KEEPS UNIT FOR EXTREME CONDITIONS As a main propulsion unit for coasters and inland vessels, the SCHOTTEL Pump-Jet gives reliable service wherever conven- tional propeller drives cannot be used due to restricted draught. With its compact design, low buoyancy loss and low suction the SPJ generates high thrust in any direction desired - even in extremely shallow waters. Like all SCHOTTEL products, it offers very smooth operation and excellent manoeuvring DOUBLE-ENDED FERRY SIER 4 X SCHOTTEL Pump-Jet Type SPJ 220 (640 kW each) 2 X SCHOTTEL Pump-Jet...

SCHOTTEL PUMP-JET Numerous armed forces around the world rely on the SCHOTTEL Pump-Jet, as excellent manoeuvrability and robust, beachable propulsion systems are essential for many military applications. With its 360° steerability and integration into the hull, the SPJ satisfies the most demanding requirements. AMPHIBIOUS BRIDGING AND FERRYING SYSTEM M3 2 X SCHOTTEL Pump-Jet Type SPJ 55 M (110 kW each) BRIDGE ERECTION AND PROPULSION BOAT AUSTRALIAN ARMY 2 X SCHOTTEL Pump-Jet Type SPJ 55 M (133 kW each) A large number of steering and monitoring systems are avail- able for SCHOTTEL Pump-Jets, in...

BEST QUALITY Customer satisfaction is of central importance to us. Over 50 engineers based at our company headquarters develop tailored solutions in close cooperation with our customers. Right from the design stage, we lay the foundation for the quality that is expected of us. Through strong investment in research and development we ensure that all our products are distinguished by efficiency reliable operation and exceptional The state-of-the-art machines and systems used in our production facilities operate with the greatest precision and make a major contribution to the constant high quality...

FERRY KÖNIGSWINTER Main Propulsion: 4 x SCHOTTEL Pump-Jet Type SPJ 57 (178 kW each) DOUBLE-ENDED FERRY CALEDONIAN MacBRAYNE Main Propulsion: 2 x SCHOTTEL Pump-Jet Type SPJ 132 (505 kW each) ANTENNA HANDLING SHIP PHAETON DOUBLE-ENDED FERRY (NAVWITH PUMP-JET) MV MAGOGONI Main Propulsion: 2 x SCHOTTEL Pump-Jet Type SPJ 57 (215 kW each) Main Propulsion: 4 x SCHOTTEL Pump-Jet Type 82 RD (300 kW each) INSHORE PATROL VESSEL NODRIZA HOTEL VESSEL VIKING LEGEND 4 x STP 200 (300 kW each) 2 x SCHOTTEL Pump-Jet Type SPJ 82 RD (290 kWeach) Auxiliary Propulsion: 2 x SCHOTTEL Pump-Jet Type SPJ 82 RD (300 kWeach)...

VESSEL'S LIFE As a SCHOTTEL customer, you benefit from individual, in-depth advice and support at all stages of a project, from planning and com- missioning through to preventive maintenance. A dense worldwide service network is ready to offer assistance and ensures the swift supply of spare parts - along with experienced SCHOTTEL technicians if required. The name of SCHOTTEL traditionally stands for quality in engineering, with over 90 years of experience in design and the precision workmanship of a family-owned enterprise. Our innovative propulsion systems are a byword for reliability and high...
