MANUFACTURER OF HIGH QUALITY MARINE WATERMAKERS . Schenker watermakers Our history Established in 1998, Schenker is a leading Provide high quality and innovative manufacturer of high quality products that meet our customer needs. watermakers based on our patented Provide excellent service and on-going Energy Recovery System. The company support through our network of prides itself on its continuous investment international representatives. in research and development, providing Provide enerǕɵƺǔˡƬǣƺȇt, simple and its customers with unsurpassed technical reliable solutions for making water. Schenker...

Why choose a Schenker watermakers? Power consumption is reduced by up to 80% compared with conventional watermakers. For example just 240 Watts is required to produce 60 litres of fresh water. 80% LESS POWER CONSUMPTION Schenker watermakers produce pure fresh water. No need to carry onboard supplies of plastic bottled water thereby reducing our reliance on plastic and protecting our oceans. Thanks to their high ƺǔˡƬǣƺȇcy, Schenker watermakers can be powered directly from service batteries without the need to run the engine or generator. DIRECT SERVICE BATTERIES POWER SUPPLY Schenker watermakers...

Which model of new generation Schenker watermakers should I choose? Schenker watermakers are avƏǣǼƏƫǼƺǣȇˡɮƺȅȒƳƺǼɀtypes: Zen, Qube, Wiki, Smart and Modular. All units incorporate Schenker’s power saving Energy Recovery System and high quality materials. The new Zen and Qube, with their clean look, compact design and minimal exterȇƏǼˡttings, are a perfect choice where onboard space is limited or you want the latest in watermaker design. Alternatively the more traditional Smart design, with its single long membrane and separate components, will appeal if more onboard space is available. Finally...

SMALL , LARGE OR XLARGE What size of watermaker should i choose? We all have varying water needs aboard, ranging from 30 to 50 litres per day per person. Your ideal watermaker should provide the daily fresh water needs of the boat in about three to four hours. For example, a yacht with 5 persons onboard may need about 200 litres per day. This could be produced by a Zen 50 watermaker in four hours. Should i choose a dc or ac watermaker? All Schenker watermakers arƺˡtted with an Energy Recovery System, reducing the power consumption by up to 80% compared with conventional watermakers . The 30 and...

Our watermakers Wiki, a compact, portable, energy-ƺǔˡƬǣƺȇt, Italian-designed watermaker. It doesn’t require installation and can be put into operation in a few minutes, by connecting the pipes through practical quick-coupling ˡttings. 12-24 VDC, low power (110W), easy setup. Quiet, small, lightًƺǔˡƬǣƺȇt, affordable. Can be installed horizontally or upright. Very compactًˡtting the smallest of spaces. RANGE 30 - 50 - 100 - 150 litres/hour The ZEN Twin is based on two independent watermakers, offers the possibility to operate both or just one machine. RANGE 200 - 300 litres/hour Production may...

Lighter. Extreme. Reliable. The ZEN 30 RACE is designed for racing boat, delivering proven ZEN performance in applications where every gram matters. The lightest solution for producing fresh water on a racing boat. 30 l/h, 12-24 VDC, 110W. Super-compact watermakers with a contemporary and essential design. Qube is equipped with an extremely quiet and reliable brushless electric motor. RANGE 30 - 65 - 100 - 150 litres/hour Light, single membrane. The ideal solution for those who prefer a simple and essential system. A very compact unit. Choice of output range to satisfy all needs. RANGE 60 - 100...

Power Supply OCEAN ROWING BOATS INFLATABLE BOAT

Power Supply Weight Membranes OCEAN ROWING BOATS INFLATABLE BOAT

35/45 FEET 30/40 FEET 30/40 FEET ' SAILBOAT CATAMARAN POWERBOAT

Power Supply Weight Membranes

Power Supply Weight Membranes

TWIN 200 lit/h Gal/h 53 Weight Membranes Power Supply

TWIN 300 lit/h Gal/h 79 Power Supply

Power Supply 110 Watt OCEAN ROWING BOATS RACE BOATS

Power Supply OCEAN ROWING BOATS INFLATABLE BOAT

Power Supply

Power Supply Weight Membranes

Power Supply Weight Membranes

Power Supply

Power Supply

Power Supply Weight Membranes

Power Supply Weight Membranes

Power Supply Weight Membranes

Power Supply Consumption Weight Membranes

Power Supply Weight Membranes

Power Supply AC single or three phase

300 lit/h Gal/h 79 Main pump inside NVERTER TECHNOLOGY Power Supply AC single or three phase

Main pump inside INVERTER TECHNOLOGY Power Supply

Functions: • Start/stop • Hours counter • Pressure meter • Hours counter • Assisted maintenance • Salinity monitoring (optional) • Flow meter (optional) • Pressure meter (optional) • Chartplotter interface (optional) • Control from tank level switches

Typical installation Plumb to pressure side of boat fresh water system Pressurized fresh water valve Fresh water outlet Swan neck upwater-Discharge

Feed pumps

zen 100 | twin 200 | smart 80 | smart 100 | modular 100

qube 65 | qube 100 brushless motor

brushless motor

Connettivity Chartplotter Interface The Schenker MFD interface allows you to control watermakers ers equipped with a TOUCH control panel directly from the main n chartplotters available on the market, compatible with HTML5 L5 applications (SIMRAD, B&G, LOWRANCE, GARMIN, RAYMARINE) NE) 3 Control panel TOUCH Computer box Interface system Chartplotter (not included)

Fresh water treatments Schenker UV purification system m Schenker UV is based on a latest-generation ɖǼɎȸƏɮǣȒǼƺɎn0(ǼƏȅȵًƬȒȅƫǣȇƺƳɯǣɎǝƏȵƏǣȸȒǔˡǼɎƺȸɀِ ȸɀِ ǣȇǕ ÁǝƺǼƏȅȵƏƬɎǣɮƏɎƺɀȒȇǼɵƳɖȸǣȇǕɯƏɎƺȸˢȒɯًȅǣȇǣȅǣɿǣȇǕ .9% power consumption. It reduces bacterial load by 99.9% ٢ǔȒȸƏˢȒɯȸƏɎƺȒǔ‫׎׏‬ǼǣɎƺȸɀٖȅǣȇ٣ِÁǝƺˡǼɎƺȸɀƺǼǣȅǣȇƏɎƺ ualities. sediments and improve the water's organoleptic qualities. Power supply available: 12 and 24 V.

Pick&Drink - Microfiltration ¨ǣƬǸƏȇƳ(ȸǣȇǸǣɀƏƬȒȅȵǼƺɎƺǸǣɎɎȒˡǼɎƺȸɎǝƺɯƏɎƺȸǔȸȒȅ the tank, increasing the quality of the water. The kit ƬȒȇɀǣɀɎɀȒǔƏȵƏǣȸȒǔȵȸƺ‫ٮ‬ƏɀɀƺȅƫǼƺƳȅǣƬȸȒˡǼɎƺȸɀƏȇƳƏ dispenser. The system can be easily connected to the pressurized freshwater system of the boat. High quality of fresh water always available from the dispenser. Flow rate: 3 l/min Temperature: 3-30°C Working pressure: 1-7 bar Sink faucet Sink hose Wall-mounted water intake Sampling valve Hose PE 8X6 JG PP housings group !
