MULTIFUNCTION UNITS Incredible flexibility and power, packed into Navman's latest edge-cutting combo displays. The new 8120 and 8084 integrate GPS, chart plotter and sonar together with exciting video capabilities, in a sleek navigation console with hi-res crisp colour display. The addition of fuel management and radar options make these instruments amazing all-in-one datahelms. With a host of integrated features combined with user-friendly technology, this new generation of instrument is definitely the datahelm which every fisherman, cruiser or sailor is calling for. Full 12" (304 mm) SVGA...

Main features common • Smart window splits for easy with user's selection of screen • The intuitive menu walks you through the functions and allows you to program your favourite preset screen options. • SD C-Map NT Max delivers critical details and innovative features : land detail, live Nav-aids, birdseye views of ports, advanced port info, etc. • Embedded 32 MB worldwide cartography. • 50/200 kHz sonar : adjusts automatically to match the wattage of the transducer. No need for a separate sounder processor : you just need to connect the transducer you have selected to your 8120 waterproof...

: With addition of Navman radar radomes, :** With addition of optional fuel kits, :*** With addition of an AIS receiver, • Infra-Red colour video camera, high resolution night/day images, with CCD 1/3" Sony sensor. with over 10 m scope (with IR on). Splashproof video camera Connects to the 8120 or 8084 video input. Ideal to watch your engine room, take rear and side views or monitor safe docking 20 m cable with power supply video camera Comes with tripod and 30 m cable. Connects to the 8120 or 8084 video input. Ideal for underwater views and to checking Equally suitable for use on the deck,...

The AIS system (Automatic Identification System) is a network which allows automatic exchange of data such as boat position, MMSI no., length/width/course etc... through the marine VHF digital network, provided that the boat is equipped with an AIS transponder. The SOLAS convention requires that all freight and passenger vessels* sailing in AlS-nerworked waters must be equipped with the AIS Recreational boats can receive this kind of data through an AIS receiver and display the data on compatible navigation instruments, allowing a better tracking of nearby traffic. When connected to an...

DIGITAL RADAR Stemming from years of development and intensive testing, Navman is proud to introduce a radar range which offers Hie best technology available for detection Combining top performance and field-proven reliability, Navman scanners feature the most advanced digital signal technology to deliver exceptional detection of small or distant targets and update constantly the information around you. Navman digital radar means : • Superior detection and discrimination of moving targets, land contours, navigation aids (buoys, beacons) thanks to the 1 Obit high resolution processor...

RADAR SCANNERS Simply add a Navman radar option and your 8120 or 8084 datahelm becomes a powerful radar system. The radar option consists in a scanner and a processor unit. Ideal on sail or power boats, when space 'Actual range scale depends on the height of the antenna, the height and structure of the target. Processor unit When ordering a radar system, make sure both the scanner ana processor unit are ordered. _u RADAR SCANNER MOUNTING SOLUTIONS Easy and simple to install, the Scanstrut radar antenna supports and brackets are engineered from highly resistant materials combined with...

COMBOS : GPS PLOTTER & FISHFINDER The TrackFish range -Navman's ultimate innovation- combines combines all the functions which made the Tracker and Fish ranges so popular : simplicity of use, top performance, powerful output and high quality resolution display. With a C-Map NT Max compatible GPS and a dual frequency high power output fishfinder, the TrackFish are indeed all-round instruments. The TrackFishóóOO large 7" display (178 mm) provides multiple display options, with an unparalleled bright screen and high resolution. 800 X 480 pixel resolution, for a highly detailed chart and sonar...

Offers the same multi-function features and top performance as the TrackFishóóOO, in a compact 5" display ( 127 mm) with a daylight viewable TFT screen with outstanding clarity. Supplied with swivel & tilt bracket, protection cover and gasket for bulkhead mounting. The new TrackFish6507 features the same functions and performance • A high resolution VGA screen, 640 x 480 pixel. With the simple one-button "PAGE" key, you can easily change from full chart, full sounder, multiple combinations, or grogram your favourite preset screen options. User adjustable split screen ratios Plot the...

Navman TrackFish compared features

C-MAP, the world leader in electronic cartography, introduces MAX, the new standard in electronic chart. While NT+ provides pinpoint accuracy and a worldwide coverage, the new NT MAX standard goes even a step further and delivers additional functions : Advanced Port Info : photos and locations of important port services. ^^P^W NT MAX chart standard ^^^^ is compatible with All MAX compatible instruments can still C-MAP NT+ and MAX charts together with accessories are available from your Plastimo dealer. for guidance on chart selection. Land data (coastal roads, town maps, etc). Added value...

Crammed with technology ! The Tracker5607 & 5507 feature all the functions of the 5500 series combined with an ultra-bright high resolution VGA screen and a full compability with the Automatic Identification System (AIS). Main features • VGA ultra-bright screen with high resolution (640 X 480 pixels) : pixel power quadrupled compared to current QVGA GPS. • GMap Max compatible (see page 57) ; 32 MB embedded worldwide cartography eliminates the need for a GMap cartridge • High speed panning. • Extended memory can be transferred to a PC or another Tracker (3000 waypoints, 25 routes with up to...
