S a f e . S i m p l e . – year after year. F l e x i b l e

Steel pontoons page 7 Fingers Floating breakwaters page 9 page 6 Auxiliary equipment Protected with Combi Coat ® page 14 Gangways page 10

Bad weather. Good Weather. Big or small. Always a safe harbour with our marinas. Ørsta Marina Systems AS is Scandinavias leading manufacturer and supplier of complete, floating marina systems. We have more than 25 years experience in the Norwegian Market. We are also an emerging actor in the European market, with deliveries to important markets as Sweden, Iceland, the Orkney Islands, the Shetland Islands, Germany and Gran Canaria. Our module-based steel concept with ­replaceable parts, silent, high quality couplings, and adjustable hinges makes an Ørsta Marina flexible and easy to modify. We...

Dimensioned drawing on digitai map. Project planning Useful in presenting your planned marina. The marina Is plotted on a drawing in which the space Is used optimally. The marina can then be illustrated In an easy to comprehend, realistic manner In 3D on an image or directly onto an official digital This simplifies considerably the public planning process with respect to both Site analysis Few marinas are currently subjected to a qualified site evaluation. Carrying out such an analysis provides additional safety considerations when trying to determine the conditions for which the marina should...

A site analysis determines which forces the marina must be designed to withstand. We can ensure regular inspections and maintenance throughout the marina's entire lifetime. We offer a 5 year guarantee against manufacturing defects. 0rsta Marina Systems AS offers a 5 year guarantee against manufacturing defects on steel parts, hinges, and floats for equipment used within their areas of application (ref. table on page 18). Any compensation Is limited upwards to the Individual part's value according to our standard sales and delivery terms and conditions. The guarantee assumes regular servicing...

TECHNICAL SPECIFICATIONS: Concrete pontoons and wave breakers * Project adjustable ** Width excl. wooden fender. Wooden fender total 0,3 m. • Wide area of application • Superior buoyancy properties • Improved water and electricity installations • Coupled together using prestressed wire • Proven design • Fastening points for auxiliary equipment • Replaceable wearing parts • Combi Coat® protected steel parts A prestressed wire runs the length of the pontoon and powerful polyurethane buffers In the skirting ensure that the chain of pontoons are dlrectlonally very stable. This results In an effective...

Steel pontoons Steel pontoons: shown with auxiliary equipment. TECHNICAL SPECIFICA' Steel pontoon with plastic floats Steel pontoon with concrete floats Friboard unload. Weight Friboard unload. Weight • Long service intervals • Combi Coat® protected • Silent couplings • Unsinkable, filled floats • Satisfactory flow-through of water • Tilt stable • Easy adjustment of berths • Few wearing parts - easy replacement • Proven design The pontoons can be supplied with pressure impregnated pine, steel grating, orWPC deck- ing. WPC Is an environmental friendly option witch is a composite of wood fiber...

Wooden pontoons TECHNICAL SPECIFICATIONS: Coherent construction Built in pressured impregnated pine, with concrete pontoons as buoyancy Easy maintanance C-profil rails can be mounted after- wards or follow standard delivery. Wooden pontoons are produced in pressured impregnatede pine with concrete pontoons as buoyancy. The pontoons are made of an EPS core enclosed with fiberarmed concrete. For mounting fingers, C-profil rails can easily be mounted afterwards or follows standard delivery. Wooden pontoons are made of modules and are easy adjustable for different lenghts.

Fingers: shown with auxiliary equipment. Can be supplied with a triangle plate on right side, left side or both sides. TECHNICAL SPECIFICATIONS: Hinges for concrete pontoons (left) and for steel pontoons (right). The fingers can be supplied with pressure impreg- nated pine, steel grating, orWPC decking. WPC Is an environmental friendly option witch Is a compos- ite of wood fiber and plastic. Plastic - filled and unslnkable. Hinges (patented) Silent, elastic rubber couplings. Can easily be moved to desired berth width. Auxiliary equipment Fender, extra mooring point, Neptune's trident and step...

• Easy to attach to land • Combi Coat® protected • Wheels with integrated bearings • Suitable for wheelchair users • Attractive design • Easily replaceable parts The gangways can be supplied with pressure impregnated pine, steel grating, orWPC deck- ing. WPC is an environmental friendly option witch is a composite of wood fiber and plastic. Auxiliary equipment End railing. Transition plate.

• Lavt vedlikeholdsbehov • Modulbasert, lett å tilpasse forskjellige lokaliteter adjustment to • Modulbased, easy • Pulverlakkert sjøvannsbestandig aliminium different locations • For For placement betongbrygge • plassering på on concrete pontoons, eller landfundamentland gangways or on • Låsbar dør • Long service intervals • Designbeskyttet • Lookable door Port • Designprotected Port The port are produced in marine corrosion resistant aliminium with powder coated finish, which secures easy maintainace and long service intervals. The port are module based and can easily be adjusted to different...

Special solutions Not two marinas are alike. Special sites and dif- ferent needs vis-à-vis use often require special solutions. We can modify our standard modules and tailor them to suit your needs. Using our advanced planning and visualisation tools we can design a marina that meets all of your requirements concerning user friendliness and safety - it pays In the long run. Floating bridge, Killingen Sjosenter, Oslo, Norway.
