What Clients Say Erwin - Germany "All materials and accessories arrived at my home very well packaged. The description was very detailed and helpful... At the moment we are still in the North Sea, as the water here is still very cold I don't expect full performance yet. What I can now say, however, is that the water produced is around 180 ppm and we are more than satisfied with it." Jürgen - Portugal "As an alternative to some established manufacturers, we can recommend Ocean Spring Watermakers, where, in addition to good advice and quality, you also have the advantage of having a German-speaking...

Ocean- Spring Watermakers models 5 Ocean- Spring Watermakers dimensions 8

Ocean-Spring Watermakers About us My name is Julian, the head behind Ocean-Spring Watermakers. As a mechanical engineer and passionate sailor, my thoughts always revolve around the technology on board. On my first big sailing trip, a year-long round of the Atlantic, I repeatedly had problems with my watermaker on board. Troubleshooting why fresh water was no longer coming out of the device was sometimes time-consuming due to the lack of displays. Manufacturer- specific special parts were always necessary, which could only be obtained from appropriate service partners. Annoyed by the influence...

Our modular Watermakers are systems made of high-quality components such as the piston pump with stainless steel pump body from Cat Pumps, magnetic feed pumps from market leaders or Dupont Filmtec membranes. The robust design promises many years of worry-free operation and easy maintenance. If necessary, spare parts can be procured anywhere in the world, ensuring maximum independence over many years. All system use only of the shelf industrial components and no custom electronics. Simple and robust, yet convinient to operate. By standard our systems are available either with 230V 50Hz AC motors...

• Magnetic feed pump - Leak-free, efficient & suitable for continuous operation. • High pressure pump from the market leader Cat Pumps. ■ Made from SS316 and with ceramic plungers • Control panel is a standard in our watermakers. ■ Either in SS316 or black aluminium compound • All cables come with connectors - Plug & Play Installation! ■ 5m of cable from Junction box to control panel and to feed pump • Only standard industrial electronic components making our watermakers simple, rugged and easy to fix anywhere. • Compact membrane units for short & long standard size membranes. • Complete kit...

• Membrane Connection straight or 90° elbow fitting • Control Panel in SS316 (Silver) or in Carbon ■ Instead of manual operated ball valve you operate the flushing from the panel, ■ Flush is performed automatical for set time and repeated every 7 days. ■ TDS Controller instead of monitor at control panel ■ Continoous monitoring of water quality and automatic switching between waste/ tank with a solenoid valve. ■ Only with panel in carbon

Ocean-Spring Watermakers Dimensions HP-Pump AC models m 0m 25

Ocean-Spring Watermakers Dimensions Feed pump AC 80/130

Single membrane housing 1170 mm Including product water connection Double membrane housing 1170 mm (690 mm for 2521) Including product water connection Triple membrane housing 1170 mm Including product water connection

Ocean-Spring Watermakers Dimensions Height of membrane housings Active carbon filter for flushing water (with autoflush option) 145 mm Active Carbon filter for Flushing water with Autoflush option

Coarse filter/ strainer Filter housing double & single (DC60 & AC65/110)

Ocean-Spring Watermakers Dimensions 120 mm Junction box Control panel with autoflush Control panel with Autoflush

Control panel with AUTO TDS Control panel side view

Ocean-Spring Watermakers Accessories for desalination systems Membrane cleaner Acidic Cleaner MC1 for regular maintenance of your membrane, Removing scale buildup restoring the membrane performance and reducing bad odors. Acidic cleaner MC1 Alcalic Cleaner MC2 for keeping biological growth on your membranes in check. Reducing bad odors and also able to remove slight oil contamination. Filters Fine Filters for your feed water and active carbon filters for the flushing water. Our filters offer high filtration efficiencies protecting your Watermaker in the best possible way. Crank case oil Originial...

Ocean-Spring Watermakers Accessories for desalination systems Spares Seal and valve kits for ours High pressure pumps: • Seal kit • Inlet valve kit • Outlet valve kit Seal kit Tank connection equipment and fittings We offer various fittings to connect your product water to your tanks. Just contactus for further consultation. Tank connector

What Clients Say Jens - Germany "I just installed it, everything is great. ..only top industrial components that you can get anywhere…zero electronics. Accessibility, support with questions, communication, everything was great.." Jonathan - Greece "Hi Julian, I’m very pleased with it and also with the help and service you provided!" Jason - Sardinia "Hi Julian, we are very pleased with the Ocean-Spring Unit you supplied. It was easy to install and simple to operate. Thank you for your dedicated support thoughout. Jason“ Peter - Vietnam "The concept of a simple and rugged watermaker that we can...

Ocean-Spring Watermakers Contact Ocean-Spring Watermakers e.K. Gartenstr. 95/3 73430 Aalen Germany HRA 728642, Amtsgericht Ulm Business owner: Julian Schlichtenmayer E-Mail: [email protected] Phone: +49 1515 0531832 Web: www.os-watermakers.com
