ODSpot - 1

ce>e3n c3tc3 System Marine Electronics Solutions ODSpot is a range of ultra compact and extremely effective ODSpot revolutionary lightings and floodlights. They combine the reliability, the lifespan and the low power consumption of LED technology with the advantages of conventional light sources. LED lighting Floodlights ODSpot 9leds Electric and optical characteristics • Very long lifespan : 50 000h 70% lumen maintenance • Built in thermal management ensures long life and minimizes color shifting • LED Technology having the best luminous yield • Same dimensions than MR16 standard for halogen lamps (for ODSpot 3 and 6 leds) • Ultra compact design • No danger to the touch • No ultraviolet or infrared radiation • Can be used in hazardous locations • Can be used in subaquatic lighting • Outperform all conventional technologies • Full range beam angles including 19°, 44°, 44°x19° • Full range of LED colors including Cool White, Warm White, Red, Green, Amber, Blue, and more on request • The fixture body is constructed from machined aluminium with a black or natural anodized finish

Open the catalog to page 1
ODSpot - 2

Color sample for 1 LED without optic Typical lighting distribution (with neutral white leds) Medium beam 19° Efficiency 89% 4.7 Cd/lm Warm White (2700K) 80 lumen Neutral White (6500K) 120 lumen Elliptical beam 44°x19° Efficiency 84.2% 2.6 Cd/lm ODSpot 3 / 6 leds Rear side view Ø36.0 Cable output 4 x through or blind holes Ø3mm Weight : 150 g 4 x trough or blind holes Ø3.3mm Partially taped M4 Rear side view More options on request OCEAN DATA SYSTEM 3 Ter Rue Roger Salengro 56100 Lorient - France info@oceandatasystem.com www.oceandatasystem.com Design : Ocean Data System 10/2016 - Non...

Open the catalog to page 2
