First choice, the base... Before you can use NorSap Modular Arm Rest Solution, you need to choose a base model. NorSap offers three solutions for the base chair; namely NorSap 1500 Offshore base, NorSap 2500 base and the NorSap 3500 base solution. Underneath the short story: A chair base with three way adjustable seating. A chair base with three way electrically adjustable seating. A chair base with eight way electrically adjustable seating. Electrically rise and lower of the column. Manually rise and lower of the back rest. Manually turn of seating. Manual seat tilt adjustment. Manual foot rest...

Modular armrests As shown on the illustrations beneath, you can get the modular armrests in various sizes.The size mentioned by the different models are the cut-out size available for placement of equipment placement. You have a play of approximately 20MIV1 on each side of the cut-out until Other solutions are described on the next page. The top covers, made in 3MIV1 aluminum plates, are adapted to fit your equipment. Lacquered in black as standard. Mounted with 4 bolts, which ensures easy and fast access for eventually replacement configurations and maintenance. If you have chosen the NorSap...

Functions NorSap can provide you with pre-designed modular arm rests in different shapes and sizes. The modular solutions can be fitted on either our NorSap 2500 base chair or the NorSap 3500 base chair. Based on your needs of controlling equipment and other equipment, you can easily find a solution that fits your place of work. On your right you see a finished solution before insertion of the actual equipment. The equipment are to be assembled by the ships or bridge builders. Each front and back part of the modular based arm rest system. The back part on the left side has the control panels...

Screen solutions By adding monitor holders mounted on the chairs seat base that turns with the operator or integrated in the arm rest. A height, angle and distance adjustable monitor holder. All cabeling goes thru the tube and arm. A height, angle and distance adjustable monitor holder with VESA mounting. Suits most com puter monitors. All cabéis go thru the tube and arm. Fits the NorSap 3500 chair. A height adjustable monitor holder. Fits most models. In addition to controller equipped arm- rests, we can add loudspeaker and micro- phone in the top of the chairs back rest. The gooseneck microphone...

Foot rest options Foot switches can also be equipped to ensure that you gain full control over all your in and out puts. Alternatively you can fit your chair with an glass infused foot rest, if your working position requires good sight straight downwards. norsap.com norsap.com norsap.com Further questions ... Make contact with NorSap for further solutions or if you have details that needs to be clarified further. NorSap AS Mjåvannsveien 35 4628 Kristiansand NORWAY web mail tel fax norsap.com [email protected] +47 38 18 52 00 +47 38 18 20 86 Page 6 of 7

Here you may add your components and requirements for your chair. Back and seat rest Side support Microphone (left/right) Heated seat Switch panel Track ball Foot rest Glass foot rest Turns w/seat Fixed height Switch panel Track ball
