User manual Ningbo SHANBEI Technology Co.,Ltd

Warning: Before using this product, please refer to the important safety information in the user manual and review all warnings, limitations and disclaimers. This product is no substitute for proper training and careful seamanship. Proper installation and proper use of the equipment is the responsibility of the owner to avoid accidents, personal injury or property damage. The user of this product is solely responsible for compliance with maritime safety practices. The owner is solely responsible for installing and using the equipment in a manner that will not cause accidents, personal injury...

The WLF-1 OP is a multi-functional joystick supporting 1, 2, and 3-axis operations, with rotation ranges of 52 degrees for the X and Y axes, and 1 50 degrees for the Z axis. It is equipped with high-precision potentiometers and is specifically designed for various maritime and offshore automation control systems. Constructed from full aluminum alloy, it features zero deadband, individually adjustable damping for each axis, and a conical rubber dust cover, making it suitable for harsh operating conditions. It boasts the advantages of compact design, robust structure, and high precision. Basic...

1. Used for wiring the WLF-10P handle, as shown in Figure 1.3.

2. As shown in Figure 3.2, pass the pressure ring C through the control lever and press it onto the top of the protective sleeve, aligning it with the screw hole. 3. As shown in Figure 3.3, install screw D into the pressure plate threaded hole to ensure secure and reliable fixation.

1. Pay attention to wiring according to the drawing, do not yank and twist during use to prevent damage.

Since its production and deployment, this product has experienced minimal malfunctions. According to our statistics, post-sales issues are primarily attributed to wiring errors, which result in the inability to use the product normally. Apart from this, there have been no technical faults. If customers encounter technical problems during use, they are advised to promptly communicate and consult with our technical personnel.

6.1 Safety protection devices and precautions 1. The important position of this product has been tightened seal processing at the factory, shall not be disassembled without permission, if the seal is damaged, any product quality problems are borne by the buyer. 2. Once the product fails to operate normally, please stop using and disconnect the power supply immediately, and contact our after-sales service engineer for a solution. 6.2 Troubleshooting procedures and methods 1. In the process of use, there is an unsolvable fault problem, contact our after-sales service engineer. 2. During the warranty...

7.1 Daily maintenance and maintenance In the daily non-use state, attention should be paid to the maintenance of this product. Through maintenance, maintenance can improve the service life of the product, the specific maintenance and maintenance methods are as follows: 1. Wipe the surface of the product regularly with a dry rag to ensure that the outside of the product is clean and tidy. 1. Stop using the device when there is a problem. Contact our after-sales engineer. 2. The input voltage shall be carried out in strict accordance with the wiring instructions. Failure to operate according to...

Physical damage to the product caused by violent shaking and collision should be avoided during transportation. Room temperature, dry, cool environment. The warranty period of this product is 12 months from the date of receipt of the goods by the buyer. Based on the date of receipt of documents for express delivery or the date of receipt of invoice.

9.1 Phone number of the after-sales engineer Manufacturer: Ningbo SHANBEI Technology Co., LTD Address: A2-902, R&D Park, High-tech Zone, Ningbo Postal Code: 310001 Tel: (0574) 87182781 Fax: (0574) 87182781
