Gangways

Product catalog summary

Overview: The document provides detailed information about Nautinox's self-supporting gangways, which are marine accessories designed for easy boarding and disembarking. These gangways are manufactured in Italy using high-quality 316L stainless steel and are available in various configurations to suit different needs.

Specifications: The gangways feature a 316L stainless steel frame and offer a choice of innovative materials for the walking surface. They are available in removable overplatform versions or built-in stern versions. The gangways are designed to combine functionality, aesthetics, and minimal bulk while maintaining practicality and strength.

Product Variants:

Passerella 123: Offers functionality and clean aesthetics with minimal bulk. Comes with a removable rectangular tube stanchion and a set of ropes for handling. An optional accessory is available for locking in intermediate positions.
Passerella 1234: A manual, retractable 4-stage gangway with a self-supporting frame, available in two widths. It features various walkable coverings and a removable self-supporting system. Weight: 30 Kg.
Passerella 12_IN: A manual, retractable 2-stage gangway designed for built-in installations. It is always ready for use and invisible when closed. Weight: 42 Kg.
3-Stage Manual Telescopic Gangway: Features a self-supporting frame, available in two widths, with various walkable coverings. Weight: 20 Kg.
4-Stage Manual Telescopic Gangway: Similar to the 3-stage version but with an additional stage. Weight: 30 Kg.

Fixing Systems: The gangways can be mounted using either a practical and quick-to-assemble anchor plate or three separate bushings for a discreet and elegant result.

Customization Options: The gangways offer a basic color range in EVA foam and synthetic teak, including dark gray, wood color, or pale gray with white or black caulking. Additional colors are available upon request, and the gangways can be supplied without covering for further customization.

Contact Information: Nautinox, Via Meucci 14, 20059 Casarile, Milano. Tel/WA: +39 0290093718, Email: [email protected]

Catalog excerpts

marine accessories

Open the catalog to page 1

Le passerelle autoportanti da sbarco Nautinox hanno struttura in acciaio inox 316L e pedane con rivestimento in materiali innovativi a scelta. Le nostre passerelle sono disponibili nella versione sopraplancia removibile o ad incasso. Telaio in acciaio inox 316L Nautinox self-supporting gangways have a 316L stainless steel frame and walking surface covered in a choice of innovative materials. Our gangways are available in a removable overplatform version or built-in the stern. 316L stainless steel frame

Open the catalog to page 2

Candeliere / Stanchion Ogni passerella viene fornita con candeliere in tubo rettangolare che può essere installato sia a destra che a sinistra ed è removibile, ed un kit di cime per la movimentazione dalla banchina. E’ disponibile un accessorio opzionale per il blocco in posizione intermedia in caso di banchine alte. Each gangway comes with a rectangular tube stanchion that can be installed either on the right or left side and is removable, along with a set of removable ropes for handling the gangway from the dock. An optional accessory is available to lock the gangway in the intermediate position...
