FV 250.2
4Pages

HOT WATER SANITIZING POT AND PAN WASHER Special Features: • High capacity - Wheeled stainless steel basket has clearances of 50-1/2” W x 26” D (1280 x 670mm). Supplied sheet pan insert holds 11 sheet pans per cycle. One additional insert is optional for a full capacity of 22 sheet pans per cycle. Auto Safe temperature control system - Guarantees 180°F (82°C) sanitizing final rinse temperature, regardless of incoming water temperature MIKE 2 electronic control system - advanced micro-computer technology for service diagnostics and end-user machine settings. Includes one-touch operation, one-touch selection of three different cycle lengths, automatic temperature monitoring with digital display, and advanced service diagnostics Active Plus filtration system - Double filtration of wash water removes food soil, improves washing efficiency and saves detergent while easing cleaning chores Soft Start wash pump - Protects fragile ware from chipping or breaking Aqua-Stop - Automatically stops machine operation and turns off the water fill if internal leaking is detected Built-in booster heater with power rinse pump - Guarantees constant final rinse pressure and temperature for consistent, outstanding results Standard Features: Built-in liquid detergent and rinse aid pumps Flanged, bolt-down feet External vent fan control Drain water tempering kit Additional sheet pan insert (holds 11 pans) - increases machine capacity to 22 sheet pans per cycle Power vent option (indirect connection). If a direct vent connection is required, contact MEIKO at sales@meiko.us for assistance. Capacity 15 cycles per hour Water consumption 2.55 gallons (9.65 liters) per cycle Oscillating wash arms for complete ware coverage Double-wall construction keeps heat inside the machine, reducing energy consumption and heat loss into the dishroom environment Variable programmed time cycles - 4, 6 and 8 minutes Fully automatic - automatic fill, automatic start, and automatic reset Pumped drain for both floor and wall drain applications Machine shutdown activates an automatic rinse of the wash chamber to ease cleaning Stainless steel non-clogging wash and rinse arms Sloping wash tank directs food soil into large, easilyremoved pan strainers Front mounted controls with digital temperature displays Two 3 Hp (2.2 kW) wash pumps 304 and 316L stainless steel construction for corrosion resistance Type A air gap system eliminates need for vacuum breaker Wheeled stainless steel wire basket with removable sheet pan insert This dishwasher is compliant with the Reduction of Lead in Drinking Water Act (2011) amendment to the Safe Drinking Water Act (SDWA). MEIKO • 1349 Heil Quaker Blvd. •

Dimensions - without power vent option 58-5/8" [1490mm] 48-7/8" [1240mm] All dimensions from floor +/- 1/2" (13mm) due to adjustable feet. 34" [860mm] vertical clearance [inside basket] 33-3/8" [847mm] Electrical terminal block Strain relief provided at lower rear of machine. Adequate slack in the wiring should be provided to allow the machine to be moved for servicing. 50-1/2" [1280mm] horizontal clearance [inside basket] Fresh water connection 3/4" female garden hose supply connection is provided. If using supplied external Y-strainer, female garden hose adapter may be removed to provide...

Drain tube (optional, by others) Machine vent (supplied) The powered machine vent is intended ONLY to extract air from the machine into the vent shroud. It does NOT replace the facility’s exhaust system. 1” [25mm] condensation channel strongly recommended Vent shroud (by others) Dimensions - with power vent option Gap permits room air to enter vent If using a condensate drain tube (supplied by others), tube may ONLY penetrate the exterior panel of the machine, and NOT the wash chamber. All dimensions from floor +/- 1/2" (13mm) due to adjustable feet. 34" [860mm] vertical clearance [inside...

Technical Specifications FV 250.2 Item Number ___________________ Unit will be an NSF and ETL-listed MEIKO FV 250.2 hot water sanitizing pot and pan washer. Operating voltage will be: _______ 208-230 V / 60 Hz / 3 Ph _______ 460 V / 60 Hz / 3 Ph Unit will have front mounted microcomputer controls, a 240 second total time cycle, and utilize 2.55 gallons (9.65 liters) fresh rinse water per cycle. Unit will utilize a fresh water pumped rinse for constant pressure and temperature every cycle. Unit will have oscillating wash arms to ensure complete coverage of ware as well as enhanced...
