IMPORTA N T: W e are manufacturer of all articles on the catalogue. If required we can supply electric motors and equipments at low tension.

COMPANY’S PROFILE Well known for its production of quality toilets, pumps, lights, horns, switches and other accessories for leisure boats, MATROMARINE ’s factory is located in ISOLA DEL CANTONE, a small village in the Liguria countryside, around 25 Km. far from Genoa. The manufacturing of our products (toilets, pumps, switches) was started in 1976 and at first was entirely run by the Amato’s family. Today the company is producing not only toilets and pumps, but can boast of a range of over 100 articles for pleasure crafts, many of which are bearing the mark and the approval of R.I.NA.,...

MATROMARINE PRODUCTS HYDRO VACUUM TOILETS Designed in accordance with the new rules on the matter of waste discharge in harbours, this water vacuum toilet has a low water consumption (about 2.5-3 litres), thus increasing the autonomy of the holding tank. Offered in three different options, for a better comfort and to allow fittings in narrow spaces, the water vacuum toilet can use automatic water system or deck pumps already installed on board for water inlet. It is fitted with an electronic switch to regulate automatically the water inlet and outlet at 2 different stages. Firstly, the bowl...

HYDRO VACUUM TOILETS MATROMARINE PRODUCTS Designed in accordance with the new rules on the matter of waste discharge in harbours, this water vacuum toilet has a low water consumption (about 2.5-3 litres), thus increasing the autonomy of the holding tank. Offered in three different options, for a better comfort and to allow fittings in narrow spaces, the water vacuum toilet can use automatic water system or deck pumps already installed on board for water inlet. It is fitted with an electronic switch to regulate automatically the water inlet and outlet at 2 different stages.Firstly, the bowl...

MATROMARINE PRODUCTS ELEGANT ELECTRIC TOILETS A new designed bowl made of vitreous china makes this toilet very comfortable and at the same time smarter and nicer to be seen, just like a home toilet. All metal parts and screws are in stainless steel. The base is in anti-crash material and the pump body is in brass. It can be installed either above or below the sea level. A special macerator pump allows the expulsion up to 1.50 m in height. Complete of white plastic or wooden seat and cover. CD. 6500002812 12V. CD. 6500002824 24V. 325 475 380 NEW MODEL 2005 The extremely compact shape of its...

MATROMARINE PRODUCTS COMPACT ELECTRIC TOILETS A special white vitreous china bowl allows a perfect cleaning and an internal space as a normal WC, with usual external dimensions of marine toilets. All metal parts and screws are in stainless steel. The base is in anti-crash material and the body pump is in brass. It can be installed either above or below the sea level. A special macerator pump allows the expulsion up to 1.50 m in height. CD. 6500000712 12V. with wooden seat CD. 6500000724 24V. with wooden seat CD. 6700000712 12V. with plastic seat CD. 6700000724 24V. with plastic seat Amp....

MATROMARINE PRODUCTS MANUAL TOILETS 99 This toilet may be supplied in the standard and large bowl versions and is equipped with a new conceiving of manual toilet pump offering the following qualities: thanks to the proper buttonhole-shaped fixing holes on the base it is possible to replace the toilet without having to bore new holes (easy substitution with toilet PAR, RM, and many others) to do so; all mouldings are made of a kind of plastic material, fully resistant against uric acids as well as against the chemical agents contained in the detergents which are normally employed to keep the...

MATROMARINE PRODUCTS MANUAL TOILETS A special white vitreous china bowl allows a perfect cleaning and an internal space as a normal WC, with external dimensions of marine toilets. All metal parts and screws are in stainless steel. The base is in anti-crash material and the body pump is in brass. This toilet can be installed either above or below the sea level. Supplied complete of white plastic or wooden seat and cover. CD. 6700000700 manual toilet equipped with plastic seat CD. 6500000700 manual toilet equipped with wooden seat DIMENSIONS: 445 x 420 x 332 mm. COMFORT MODEL: This china bowl...

MATROMARINE PRODUCTS VENTED LOOPS Indispensable component for inlet and discharge pipes of manual and electric toilets installed below the waterline. Manual and electric marine toilets flushed with sea or river water require connections through the hull below water level. If the toilet is installed below the boat waterline, the possibility of flooding the hull through an open seacock must be prevented, not only for the discharge pipe, but also for the inlet pipe. If no precautions are taken, a toilet below the waterline is at risk of flooding at all times when the discharge or inlet seacock...

WASTE SYSTEM TANK We manufactured a selection of Waste Tank Systems including macerator, Y Valve, Gas Tank Vent, Actived Carbon Filter and Control Panel, to check the level in the Tank CD: 9300000526 Kit for waste water for manual toilets 26 lt. CD: 9400000547 Kit for waste water (rectangular) 47 lt. CD: 9300000550 Kit for waste water (rounded shape) 50 lt. CD: 9400000578 Kit for waste water (rectangular) 78 lt. CD: 9300000575 Kit for waste water (rounded shape) 75 lt. CD: 9400005128 Kit for waste water (rectangular) 128 lt. POLYTHENE WASTE TANKS: Complete with 4 dead female unions 3/4"...

MACERATOR AND MAXI MACERATOR PUMPS MATROMARINE PRODUCTS Toilet waste macerator pump, 20 min. rated, can discharge tanks up to 900 litres. - bronze macerator and rubber impeller discharge pump - self priming up to 0.6 mt. vertical lift. - 43 LPM output at 3 mt. total head - macerates and discharges water and waste mixtures. CAPACITY: 43 lt./ min. DIMENSIONS: 240 x 130 x 90 mm PORT CONNECTIONS: Inlet: 38/53 mm – Outlet: 25 mm CD. 5500000912 Amp draw: 12A. - Voltage: 12V. CD. 5500000824 Amp draw: 6A. - Voltage: 24V. Toilet waste macerator pump, 45 min. rated, can discharge tanks up to 2100...
