PAST PRESENT FUTURE ISSUE 4

PAST PRESENT FUTURE Every business can be defined by where they’ve come from, how they conduct themselves and where they plan to be. So it is at Marlow, where these thoughts define everything we do. We are extremely proud of our heritage – not only as a brand recognised around the world for quality, performance and innovation, but as a business with ties to the local community going back over 200 years. However, with our history and reputation comes responsibility and we are committed to maintaining the quality and service that our customers have come to expect. As to the future, we strive for...

COMPANY PROFILE MARLOW SECTORS GRAND PRIX SERIES GRAND PRIX PROJECTS CORE TECHNICAL REFERENCE GRAND PRIX CORES GRAND PRIX COVER TECHNOLOGY GRAND PRIX COVERS ACCESSORIES & CUSTOMISATIONS SUPER YACHT SERIES PROJECTS & TECHNOLOGY RUNNING RIGGING MOORING OCEANUS I mate b’i ma Fie £*am m a r< a flar, w M am a', 3 a 5 a a ma pi me w am am me me am am CLASSIC SERIES CLASSIC PROJECTS HIGH TECH CLASSICS TRADITIONAL CLASSICS CRUISER & RACER SERIES RUNNING RIGGING DEFINITIONS CRUISER RACER PRODUCTS EXCEL DINGHY SERIES SPONSORED SAILORS / TEAMS RUNNING RIGGING DEFINITIONS EXCEL DINGHY PRODUCTS EXTREME SPORTS...

COMPANY PROFILE QUALITY, INNOVATION, TECHNICAL EXCELLENCE In 1807 Thomas Burfield opened his rope factory in Hailsham, East Sussex and, over 200 years later, Marlow Ropes continue to manufacture ropes on the same site. In the mid 1950’s Burfield and Son’s was incorporated into the expanding Hawkins and Tipson Rope Group, founded by George Hawkins and Alfred Tipson in 1881. At this time, the factory in Hailsham was one of the first in the world to be manufacturing synthetic fibre ropes. These ropes were specifically made for the yachting industry under the new "Marlow" brand. These new nylon and...

GRAND PRIX SERIES GRAND PRIX SERIES On our MOD70 Trimaran, Phaedo3, we are delighted to have begun a partnership with Marlow to develop customised solutions for our running rigging requirements. Marlow has the capabilities to optimise each piece of rope to our exact needs and couple that with the great reliability of their products, its a great fit for our campaign. The Grand Prix Series uses the highest performance materials such as Dyneema® SK99, Zylon®, Technora®, Kevlar® Teflon® and Zyex®. These materials offer attributes to covers and cores such as higher strength, improved abrasion resistance,...

GRAND PRIX SERIES GRAND PRIX PROJECTSSOME OF THE BOATS SUPPLIED WITH MARLOW GRAND PRIX SERIES THROUGH OUR GRAND PRIX RIGGING PARTNERS. AMERICA'S CUP • LAND ROVER BAR • SOFTBAN K TEAM JAPAN W.S.S.R.C COWES TO DINARD W.S.S.R.C PLYMOUTH TO LA ROCHELLE W.S.S.R.C FASTNET ORIGINAL COURSE W.S.S.R.C ANTIGUA TO NEWPORT W.S.S.R.C AROUND ISLE OF WIGHT W.S.S.R.C BERMUDA TO PLYMOUTH W.S.S.R.C AROUND IRELAND 1ST CARIBBEAN 600 (MULTI HULL) MAXI • COMANCHE • WILD OATS W.S.S.R.C 24HR DISTANCE (MONO HULL) W.S.S.R.C TRANSATLANTIC (MONO HULL) 1ST SYDNEY TO HOBART 2015 1ST CARIBBEAN 600 (MONO HULL) 2016 1ST SYDNEY...

GRAND PRIX SERIES CORE TECHNICAL REFERENCE Marlow’s Grand Prix Series offers a range of core options using Dyneema®, Vectran® and Zylon® (PBO). Each material has it’s own particular strengths and weaknesses. Dyneema® offers by far the best strength to weight ratio of any material used in rope manufacture and is the material of choice for high performance cores. At Marlow we offer a range of Dyneema® cores to suit strength and handling preferences as well as budget. Dyneema® is an Ultra High Molecular Weight Polyethylene (UHMWPE) and is available in a number of different grades. All grades of...

GRAND PRIX SERIES MATERIAL ELONGATION COMPARISON GRAPHS When elongation is measured as a % of break load (fig. 4), it is shown that whilst Zylon® offers the lowest elongation followed by Dyneema® in D12 Max and then D12, there is no differential between SK78 and SK99. However, when elongation is measured at a given load (for example 4,000kg), which is more relevant to specifying rope for on board applications (fig.5), it can be seen that the advantages of SK99 over SK78 in terms of elongation are clear. This is because the rope is working at a lower percentage of the its break load. However,...

GRAND PRIX SERIES

GRAND PRIX SERIES CORES (Grand Prix Cores specified uncovered or covered with an MGP Cover detailed on page 13) Construction: 12 strand Material: Dyneema® Available in SK99 and SK78 Extras: Marlow's Super Pre-Stretch process, ArmourCoat Features: Ultimate high strength, lightweight, low elongation ropes DIAMETER (mm) SK99 BREAK LOAD (kg) SK78 BREAK LOAD (kg) WEIGHT KG/100M DIAMETER (mm) BREAK LOAD (kg) WEIGHT kg/100m M-Rig Max's top benefit is minimal creep ideal for standing rigging and steering lines. Add an MGP cover or light weight chafe cover for high wear applications such as life lines....

GRAND PRIX SERIES COVER TECHNOLOGY The interaction between core, cover and deck gear are fundamental elements of a rope's performance. The Grand Prix Series blends technical materials to impart application specific properties to the cover. The properties of different materials will have varying impact on the interaction between rope & deck gear, by blending different materials in different ratios we are able to best utilize these material properties to produce the perfect rope performance. The data on page 13 details our standard blend covers & their relative performance in terms of abrasion...

GRAND PRIX SERIES COVERS MGPPBOIOO ZULDH 24 Plait, 100% Polyester cover offers good allround performance. Cost effective option for general purpose lines subjected to relatively low heat and abrasion. 24 Plait, 100% PBO has outstanding heat & abrasion resistance properties for high load, high temperature applications. Use for runners and high load sheets where winch easing is of particular importance. Clutch & Jammer Performance Winch Drum Performance Abrasion Resistance Thermal Resistance Water Absorption Weight 24 Plait PBO & Polyester blend offers higher heat & abrasion resistance that MGP...
