Bluewater Brochure
28Pages

Welcome to KARNIC, the world of quality and perfection. C onsidering a Karnic boat is an experience on its own. Only the thought just suffices to realise the reasons that give Karnic boats their own character of excellence. The unique character that makes them one of the top brands in the industry. Karnic boats are designed using leading edge CAD-CAM technology to develop the shapes, check functionability and ergonomics, define aesthetics and ensure comfort. No less attention is paid to the inwater behaviour of each hull for which the study begins right from the very early stages of the...

KARNIC YEARS LIMITED HULL STRUCTURAL WARRANTY THE CYPRUS SPECIAL EXPORT AWARD - 2000 THE CYPRUS EXPORT AWARD FOR INDUSTRIAL PRODUCTS - 2002 Top Class Offshore Performance THE EUROPEAN UNION EXCELLENCE AWARD FOR INDUSTRIAL PRODUCTS - 2004

The KARNIC Design, Constr Before each Karnic boat reaches production stage, considerable time is spent for a detailed study, from conceptual design to advanced engineering and modeling. State of the art 3D CAD CAM software assist in carrying out these tasks. Generous flare forward ensures a dry ride in choppy seas The full scale model of each part is machined to a fraction of a millimetre using 5-axis CNC robot technology before casting the mould to begin production. High deadrise angle forward slices through the waves and gives better directionality in displacement speeds Reversed chines...

Several stages of Quality Assurance block all imperfections before each boat leaves our plant. uction and Built Excellence All our upholstery is styled and fabricated in house using heavy duty, marine grade vinyls and fabrics. Colour coded electrical wiring and coded harnesses are used on every Karnic boat. Hatches produced in double moulds give glossy gelcoat finish on both faces and marine grade plastic material is used to prepare in house components at the finest detail. Welded 316L stainless steel rails and mounts provide strength and longevity. Stainless thru-hull fittings are used as...

L I N E Top Class Offshore Performance 2 0 2050 S P E C I F I C A T I O N Length Overall . . . . . . . . . . . . . . . . 5.95 m Hull Length . . . . . . . . . . . . . . . . . . . . 5.90 m Beam . . . . . . . . . . . . . . . . . . . . . . . . . 2.45 m Draft (standard power) . . . . . . . . 0.28 m Hull Design . . . . . . . . . . . . . . . . . . . . 18° deep V Approximate Weight . . . . . . . . . . 860 kg Freeboard Forward . . . . . . . . . . . . 1.04 m Freeboard Aft . . . . . . . . . . . . . . . . . 0.85 m Cockpit Depth . . . . . . . . . . . . . . . . . 0.60 m Cabin Headroom . . . . . . . . . ....

L I N E Top Class Offshore Performance 2 0 2051 S P E C I F I C A T I O N Length Overall . . . . . . . . . . . . . . . . 6.60 m Hull Length . . . . . . . . . . . . . . . . . . . 5.80 m Beam . . . . . . . . . . . . . . . . . . .. . . . . . . 2.45 m Draft (standard power) . . . . . .. . . 0.28 m Hull Design . . . . . . . . . . . . . . . . . . . . 18° deep V Approximate Weight . . . . . . . . . .. 825 kg Freeboard Forward . . . . . . . . . . .. 1.10 m Freeboard Aft . . . . . . . . . . . . . . . . .. 0.85 m Cockpit Depth . . . . . . . . . . . . . . . . . 0.60 m Console Headroom . . . . . . . ....

Standard Layout: Adjustable swivel helm and companion seats. Optional freshwater system with transom Weekender Package: Twin helm seat with convertible front-to-back backrest, under seat storage, single burner stove and sink with cutting board. Freshwater system and transom shower are included.

L I N E Top Class Offshore Performance 2 2 2260 Standard Layout: Adjustable swivel helm and companion seats. Optional freshwater system with transom shower. Weekender Package: Twin helm seat with convertible front-to-back backrest, under seat storage, single burner stove and sink with cutting board. Freshwater system and transom shower are included. S P E C I F I C A T I O N Length Overall . . . . . . . . . . . . . . . . 7.32 m Hull Length . . . . . . . . . . . . . . . . . . . . 6.30 m Beam . . . . . . . . . . . . . . . . . . . . . . . . .. 2.45 m Draft (standard power) . . . . . . . .....

L I N E Top Class Offshore Performance 2 2 2265 S P E C I F I C A T I O N Length Overall . . . . . . . . . . . . . . . . 7.32 m Hull Length . . . . . . . . . . . . . . . . . . . . 6.30 m Beam . . . . . . . . . . . . . . . . . . . . . . . . .. 2.45 m Draft (standard power) . . . . . . . .. 0.33 m Hull Design . . . . . . . . . . . . . . . . . . . . 18° deep V Approximate Weight . . . . . . . . . .. 1190 kg Freeboard Forward . . . . . . . . . . . . 1.15 m Freeboard Aft . . . . . . . . . . . . . . . . .. 0.85 m Cockpit Depth . . . . . . . . . . . . . . . . . 0.6 4 m Cabin Headroom . . . . . . ....

L I N E 2 4 2450 & 2460 S P E C I F I C A T I O N Length Overall . . . . . . . . . Hull Length . . . . . . . . . . . . . Beam . . . . . . . . . . . . . . . . . . Draft (standard power) . Hull Design . . . . . . . . . . . . Approximate Weight . . . Freeboard Forward . . . . Freeboard Aft . . . . . . . . . . Cockpit Depth . . . . . . . . . . Cabin Headroom . . . . . . . Fuel Capacity . . . . . . . . . . Water Capacity . . . . . . . . Engine Type . . . . . . . . . . . 8.20 m 6.99 m 2.59 m 0.42 m 20° deep V 1640 kg 1.30 m 0.90 m 0.72 m 1.80 m 300 litres 50 litres 2450: Twin Outboard 2460:...

Top Class Offshore Performance Model 2450, twin outboard: Walkaround, mid-cabin layout with Armstrong® bracket for twin outboard motor installation Model 2460, single sterndrive: Walkaround, mid-cabin layout with single sterndrive motor installation. 19

L I N E 2 6 S P E C I F I C A T I O N Length Overall . . . . . . . . . . . Hull Length . . . . . . . . . . . . . . Beam . . . . . . . . . . . . . . . . . . . Draft (standard power) . . . Hull Design . . . . . . . . . . . . . . Approximate Weight . . . . . Freeboard Forward . . . . . . Freeboard Aft . . . . . . . . . . . . Cockpit Depth . . . . . . . . . . . Cabin Headroom . . . . . . . . Fuel Capacity . . . . . . . . . . . . Water Capacity . . . . . . . . . . Engine Type . . . . . . . . . . . . . 8.70 m 7.49 m 2.59 m 0.43 m 20° deep V 1860 kg 1.30 m 0.90 m 0.70 m 1.85 m 350 litres 50 litres...
