Hubbell Marine Products

Product catalog summary

Introduction
This document provides an overview of Hubbell's marine electrical products, emphasizing their compliance with various standards and the introduction of new products. It includes detailed specifications, features, and benefits of products designed for marine environments.

Standards and Compliance
Hubbell's marine products comply with standards such as the National Electrical Code (NEC), the Restriction of Hazardous Substances (RoHS) Directive, and ISO standards. They are designed to meet requirements for tamper-resistant and weather-resistant receptacles, ensuring safety and durability in marine environments.

Product Specifications
The document details various marine electrical products, including:

100 Amp Pin and Sleeve Devices: UL Type 4X and IP69k rated, with UV and chemical resistance.
Marine Isolation Transformers: Available in 15 kVA and 25 kVA models, protecting equipment from voltage fluctuations.
USB Charger Receptacles: Featuring USB Type-C connection for faster charging, available in tamper-resistant and weather-resistant versions.
Ground Fault Receptacles: Designed for harsh environments, offering corrosion resistance and meeting NEC requirements.

New Products
Hubbell introduces new products such as:

Weather Resistant and Extra Heavy Duty Corrosion Resistant Ground Fault Receptacles: Designed for demanding environments with nickel-plated contacts and stainless steel hardware.
Stainless Steel Weatherproof and Watertight Flip Covers: Providing superior corrosion resistance, available in various mounting positions.

ELCI Interface Solutions
Hubbell offers ELCI (Equipment Leakage Circuit Interrupter) solutions to enhance safety by preventing electrical shock drowning, including adaptive shore power inlet kits.

Ship-to-Shore Devices
The document includes a selection guide for ship-to-shore devices, detailing various cable sets and adapters designed for marine use, with features like LED indicators for power status.

Conclusion
Hubbell's marine electrical products are designed to meet the rigorous demands of marine environments, ensuring safety, reliability, and compliance with international standards. The introduction of new products and features demonstrates Hubbell's commitment to innovation and quality in the marine industry.

Additional Product Details
The document provides detailed specifications for 30 Amp and 50 Amp, 125 Volt Twist-Lock® devices, designed for ship-to-shore power connections. It includes:

30A 125V Cable Sets: Available in yellow and white, with lengths of 25 ft, 35 ft, and 50 ft, featuring a vinyl jacket and molded-on devices.
Bulk Cable: Offered in 250 ft and 280 ft lengths, PVC jacketed with jute fillers for flexibility.
Shore Power Inlets: Available in stainless steel and non-metallic designs, with easy-to-wire terminations and watertight when closed.

Features and Benefits
Products are made with materials like stainless steel and nickel-plated brass for corrosion resistance, include features like LED indicators for power status, and have ergonomic designs with easy-to-wire terminals.

Accessories
Replacement parts such as non-metallic sealing rings and protective covers are available to maintain and enhance the functionality of the cable sets and inlets.

Applications
These products are ideal for marine environments, providing reliable power connections for boats and other marine vessels.

Weatherproofing and Accessories
Includes Seal-Tite® covers and Valox® lift covers for weatherproofing plugs and receptacles, with stainless steel wall plates and neoprene gaskets for enhanced durability.

Key Features and Benefits
High performance details in cable sets ensure reliability and ease of use, with products designed to meet stringent UL and CSA standards.

Definitions

Equipment Leakage Circuit Interrupter (ELCI): A device that detects ground fault leakage and disconnects conductors at a preset threshold.
Ground Fault Circuit Interrupter (GFCI): Protects personnel by de-energizing circuits when ground current exceeds a set value.
Watertight: Enclosures that prevent water entry under specific test conditions.
Weatherproof: Enclosures that withstand weather exposure without operational interference.

Ground Fault Protection - AC Systems
ELCI or Type A RCD must be installed near the shore power connection with a trip level of 30mA and a maximum trip time of 100ms. GFCI devices must comply with UL 943 and UL 498 standards.

Switches
Switches must have voltage and current ratings suitable for the system and load type, with branch circuit switches opening all ungrounded conductors simultaneously.

Plugs and Receptacles
Receptacles should be installed in dry locations or be weatherproof/watertight if exposed to rain or flooding, meeting UL 514A or 514C standards.

Shore Power
Power inlets must be male connectors and weatherproof or watertight as required, with shore power cables flexible and suitable for outdoor use.

Product Listings
The document lists various product codes such as C5LA, USB20AC5W, VCGP100, and others, each associated with a specific page number, likely corresponding to different marine electrical products or components.

Company Information
Hubbell Incorporated is based in Delaware, with contact information provided for customer service. The document notes that specifications are subject to change and includes trademark information.

Additional Resources
The document references a website for further information on Hubbell Marine products, suggesting that more detailed specifications and product details can be found online.

Catalog excerpts

Marine Products

Open the catalog to page 1

Regarding the Cover Photo - We would like to thank Captain Dave Carraro and long-time mate Sandro Maniaci of the FV-Tuna.com from the series Wicked Tuna on National Geographic Channel. It was a pleasure working with Captain Dave and Sandro, as well as the good people at S.W. Boatworks and Kramp Electronics with the installation of Hubbell Marine Shore Power Products, Hubbell/Burndy Wire Terminals and Hubbell Lighting Products. Marine Electrical Products Marine Electrical Products

Open the catalog to page 2

Marine Products NEC® Receptacle Code Compliance and General Information Tamper-Resistant Duplex Receptacles Weather Resistant Duplex Receptacles Comply with NEC® 406.12 Comply with NEC® 210.52 Comply with NEC® 406.9 All 125V, 15A and 20A receptacles shall be listed tamper-resistant receptacles per NEC® Article 406.12, “TamperResistant Receptacles in Dwelling Units”. All 125V and 250V, 15A and 20A receptacles shall be listed as weather resistant type per NEC® Article 406.9, “Receptacles in Damp and Wet Locations”. Weather Resistant These symbols appear in this catalog for easy identiﬁcation. What...

Open the catalog to page 4

Marine Products 30, 50, 100 & 200 Amp Cable Sets and Devices Product Page Ship-to-Shore Selection Guide 4 ELCI Interface Solutions 7 Ship-to-Shore Cable Sets and Devices Internationally Rated Adapter Selection Guide 28 Molded Straight and Y Adapters 29 Marine Isolation Transformers Telephone and Cable TV Devices 32 Product Page 15A Twist-Lock® and Straight Blade Devices 36 20A Twist-Lock® and Straight Blade Devices 38 GFCI and Portable Ground Fault Circuit Interrupters 42 Switches and Weatherproof Switch Plates 44 Communication Frames and Connectors 46 Boatyard Accessory Items Non-Metallic While-In-Use...

Open the catalog to page 5

Marine Products New Marine Products Hubbell Marine 100 Amp Pin & Sleeve The Best Just Got Better. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 20 Hubbell Marine was the first to offer 100 amp marine grade devices that are considered second to none. Hubbell developed the standard for 100 amp pin and sleeve devices with the National Electric Code and the American Boat and Yacht Council. 100 Amp Pin and Sleeve Devices Improved Features: • UL Type 4X and IP69k Rated • Compact and durable cap hinge is fully shrouded and protected • VO flammability rating • UV stabilized,...

Open the catalog to page 6

Marine Products New Marine Products USB Charger Receptacles with Type-C Charge Faster with Hubbell . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 41 The smaller size USB Type-C connection will replace the traditional larger Type A connection Now, with 5 amps of fast charging power Available in standard tamper-resistant version and in weather resistant versions USB Type-C connection is: • Smaller, 24 pin configuration • More robust for reliable connection • Quicker, simply plug in your cord New Hubbell Weather Resistant and Extra Heavy Duty Corrosion...

Open the catalog to page 7

Marine Products Ship-to-Shore Selection Chart - Boatside Ship-to-Shore Selection Chart - Boatside 30A 125V AC 2 Pole 3 Wire Portable Telephone and Cable TV Devices Marine Electrical Products Marine Electrical Products

Open the catalog to page 8

Marine Products Ship-to-Shore Selection Chart - Dockside Ship-to-Shore Selection Chart - Dockside YC310250 - 280' (85.3m) Yellow cable only. WC310280 - 280' (85.3m) White cable only. YC306250 - 250' (76.2m) Yellow cable only. YC406250 - 250' (76.2m) Yellow cable only. - 125' (38.0m) One-ended cable set for winches. - 100' (30.4m) One-ended cable set for winches. - 75' (22.8m) One-ended cable set for winches. - 50' (15.2m) Extension cord. CW125IT5 - 125' (38.0m) One-ended cable set for winches. CW100IT5 - 100' (30.4m) One-ended cable set for winches. CS50EXT5 - 50' (15.2m) Extension cord. Marine...

Open the catalog to page 9

Marine Products ELCI Interface Solutions 30 Amp and 50 Amp ELCI Interface Solutions ABYC Code Requirements Hubbell Marine Electrical continues its tradition of innovation by developing a simple, flexible method of adapting a variety of ELCI Sensors and Breakers to our traditional Stainless Steel and Non-Metallic Shore Power Inlet Housings. Effective July 31, 2012, ABYC, E-11.11.1 requires that “An Equipment Leakage Circuit Interrupter (ELCI) shall be installed with or in addition to the main shore power disconnect circuit breaker(s) or at the additional over current protection as required by...

Open the catalog to page 10

Marine Products ELCI Interface Solutions 30 Amp and 50 Amp ELCI Interface Solutions Hubbell ELCI Adapter Kits for North Shore Safety, Ltd® PGFM Series (ELCI Marine) Sensing Module and Sensata Technologies® ELCI Breakers Description Power Inlet Catalog Number 30 Amp, 125 Volt Non-Metallic Inlet (HBL303NM) and (2) Non-Metallic Inlet Housings, Adapter Plates and Hardware. 30 Amp, 125 Volt Non-Metallic Inlet (HBL303NM) and (1) Non-Metallic Inlet Housing that adapts to North Shore Safety’s Sensor only (no circuit breaker inlet housing), Adapter Plate and Hardware. 30 Amp, 125 Volt Stainless Steel...

Open the catalog to page 11

Marine Products 30 Amp, 125 Volt Cable Set 2 Pole, 3 Wire Cable sets only. 30A Ship-to-Shore Devices 30 Amp Cable Sets • • • • Bright, durable, LED (green) indicates “Power-ON” High intensity LED is visible—even in bright sunlight Totally molded design for superior waterproofing and durability Exclusive copper crimp barrel terminations for tighter connections and longer life • Marine UL and cUL Listed Note: Cable sets must be fully extended before using. Housing Design • New improved ergonomic styling • Line-up notches to indicate: Locked - Unlocked • Arrow indicating lock or unlock position...

Open the catalog to page 12

Marine Products 30 Amp, 125 Volt Twist-Lock® Devices 2 Pole, 3 Wire Cable sets only. 30A Ship-to-Shore Devices 30 Amp Cable Sets and Bulk Cable Our 30A 125V cable set is packed with high performance details from end to end that make a real difference. Completely factory pre-wired with molded-on devices. Designed to coil easily and lay flat. SUITABILITY (Boatside) 30A 125V Cable Sets and Bulk Cable Description Catalog Number Yellow 50 ft. (15.2m) vinyl jacketed shore power cable set. #10 AWG is factory pre-wired with molded-on devices. Connector end has non-metallic threaded sealing ring which...

Open the catalog to page 13
