C10-W (M) Wall fixture IP 20 • Good glare control in corridor • Efficient lighting of floor area • Easy installation Application For lighting in corridors or spaces where fixture has to be mounted to wall. Design Minimalistic classic design for modern light sources. Housing Steel housing with V0-classified plastic end caps. Finish Powder coated white RAL9016. Diffuser Opalic plastic diffuser. Reflector (Optic) No reflector available. Variant with uplight available on request. Electric Electronic ballast Mounting To be mounted directly to wall. Cable entry Two holes Ø20 mm at the back, and two knockouts Ø20 mm at upper side. Termination One 3-way push in terminal block, 2 x 2.5 mm². Lamp base G5 Light source T16 (T5) Ta=40°C Product Part-No. L C Weight Lamp Lamp HF C10506028 mm 574 mm 490 kg 1,0 Code T16(T5) Base G5 C10-W-(M) 114 830 CO C10506027 574 490 1,0 T16(T5) G5 C10-W-(M) 114-E3/S 830 CO C10506029 874 790 1,3 T16(T5) G5 C10-W-(M) 128 830 CO C10506031 1174 1090 1,3 T16(T5) G5 C10-W-(M) 128-E3/S 830 CO C10506033 1174 1090 1,8 T16(T5) G5 C10-W-(M) 114 CO 40

GLOBAL MARINE & OFFSHORE LIGHTING SOLUTIONS Spare Parts Grommet Terminal block Ballast Cable clip End cap Reflector Light tube Diffuser Lamp holder 88 40 L 20 C C10 W C10 WU Measurements are in mm www.glamox.com 41
