Sonar - 1

R 10.4" COLOR LCD DISPLAY SEARCHLIGHT SONAR Model CH-270 q High definition 10.4" color LCD display q Cross Section Scan for instant observation in the vertical plane q Instant selection of eight modes for effective fishing and navigation q Target Lock function automatically tracks targeted fish school q User-friendly customizable menu q Audible target detection frees operator from continuous watch (optional loudspeaker required) q Motion Sensor ensures clear images in rough seas (optional) q BlackBox configuration available q Multi language menu; English, Spanish, Danish, Portuguese, French, Norwegian, Italian, Swedish and Thai q Intuitive depth and range readouts with two-axis index line q Low-profile hull unit for space saving installation (select from 250 or 350 mm travel) q Small 147 mm ID hull tube used Catalogue No. E-397 R The future today with FURUNO's electronics technology. FURUNO ELECTRIC CO., LTD. 9-52 Ashihara-cho, Nishinomiya City, Japan Telephone: +81 (0)798 65-2111 Telefax: +81 (0)798 65-4200, 66-4622 URL:www.furuno.co.jp TRADE MARK REGISTERED MARCA REGISTRADA

Open the catalog to page 1
Sonar - 2

A remarkable Compact hull unit that reliably scans all around the vessel in a specified sector, bearing and tilt angle Vertical Scan Sector or Full Circle Scan The CH-270 is a new sophisticated searchlight sonar designed for small fishing vessels or pleasure craft. Individual fish, fish schools and underwater objects are displayed on a 10.4" color LCD. The echograms are displayed in 8 or 16 colors according to received echo strength; the strongest echoes are red, the weakest are blue. One echo can be displayed in white so that a specific echo level is highlighted. The background color is...

Open the catalog to page 2
Sonar - 3

Combination of FULL/HALF CIRCLE with VERTICAL SCAN FULL CIRCLE SCAN The full circle scan helps to detect fish schools at any bearing, all around the vessel. Combination of FULL CIRCLE with VERTICAL SCAN VERTICAL SCAN The vertical scan paints the bottom profile within a user-specified vertical plane. The cursor indicator reads slant range and soundome tilt. Combination of HALF CIRCLE with VERTICAL SCAN A unique feature of this sonar is the mode integrating the two images shown to the left. This sonar image also can be switched to a Half Circle with Vertical scan. FULL CIRCLE with...

Open the catalog to page 3
Sonar - 4

SPECIFICATIONS OF CH-270 1. Range scales and Time to Range train (the default setting at full circle scan mode) 1 Meters 2 3 4 5 6 7 8 9 10 11 12 13 14 15 20 80 40 120 60 200 80 300 100 400 120 500 160 600 200 700 250 800 300 1000 400 1200 500 1500 600 2000 800 2500 Feet Fathoms 10 20 30 40 60 80 100 120 140 160 200 250 300 400 500 P/B Unit 10 40 10 20 30 40 60 80 100 120 140 160 200 250 300 400 600 11 11 11 11 11 11 11 13/14 14/17 22/33 26/41 30/49 38/65 Time to train full circle (s) (Fast scan/Normal scan) 16/21 18/25 Maximum scale depends on the display modes. 1600 m (full circle scan),...
