Marelon Plumbing Systems Remote Operated Valv • Vented Loop Smart Valves • Ball Valves

F or espar® Overseas Agents DECKHARDWARE AUSTRALASIA PTY LIMITED Email: ¡nfo@deckhardware.com.au St. Maarten, Netherland Antilles Email: Kevln@fkg-marlne-rlgglng.com BUDGET MARINELO. (Main Office) St. Maarten, Netherland Antilles Email: sales @budmar.an BUDGET MARINE-ANTIGUA Jolly Harbour Boatyard Bolans, Antigua, West Indies Email: sales@budmar.ag BUDGET MARINE-BONAIRE Kaya Carlos A. Nlcolaas 4 Kralendljk, Bonaire, Netherlands Antilles Email: peter@budgetmarlnebonalre.com BUDGET MARINE-GRE^ Prickly Bay, St. Georges, Granada Email: budmarGD@carlbsurf.com BUDGET MARINE - ST. MARTIN L'Ile...

TABLE OF CONTENTS ABYC STANDARDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 Tank Vent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14 ANTI-VENTURI T-HULL . . . . . . . . . . . . . . . . . . . . . . . . .10 Threaded Valves . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 CARGO MATE ™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 Thru-Hull Connectors . . . . . . . . . . . . . . . . . . . . . . . . . .7 CHOCKS, LINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 Vented Loop . . . . . . . . . . . . . . . . . . . . . . ....

SMART VALVE™ The Smart Valve™ provides the safety and assurance of a visual display panel showing which seacock is open or closed-without having to go below and pull up floorboards to make a visual inspection. Sensors, factory installed, on any new single port, Marelon Integrated Plumbing System flange mounted valve use state-of-the-art sensing technology to monitor the valve's handle position. Display panels use red and green LED lights to indicate which valve is open (green LED) or closed (red LED). Simple two wire lead from each valve makes installation easy. Power is supplied directly...

OPTIONAL ELECTRONIC PANEL For Use With Smart Valves™ Or Smart Valve ROV™ Systems This optional electronic relay board can control up to four electrical devices. You can now wire your engine starter switch to this board so if the engine seacock is closed, the engine will not start until the valve is opened, either manually with the Smart Valve™ or remotely with the Smart Valve ROV™. This feature will eliminate operator errors such as turning on the macerator pump before opening the holding tank discharge seacock or starting the generator before opening the intake seacock. These costly...

MARELON® PLUMBING SYSTEMS • For Use Above And Below Waterline • Precision Molded Plumbing Systems • Complete Freedom From Corrosion • A.B.Y.C. Approved • Forespar® "93" series of valves and thru-hull fittings meet all design criteria and exceed all mechanical property requirements specified by the International Standards Organization (IS0150/188) "Small Craft-Seacocks and Thru-hull Fittings-Part 2: Non-Metallic" Marelon ® is a proprietary formulation of polymer composite compounds using DuPont® resins and additives to produce a superior marine-grade product Benefits to builders include:...

Forespar's MF 850 series of Ball Valves are precision molded in high strength Marelon ®. Their great strength, light weight, and complete freedom from corrosion and electrolysis make them the ideal valve for controlling inlet and outlet water requirements above and below the waterline. Our engineers opened and closed one of our 3/4"(19.05mm) valves 11,000 times, then submerged it in water with an air line pressurized to 40 p.s.i. connected to it. The result was an absolutely leak free condition with no evidence of wear on internal seals. All valves sold throughout the U.S.A. have N.P.T....

FLANGE MOUNTING SEACOCKS A WORD ON THREAD FORMS The American standard for tapered or parallel threads have a thread flank angle of 60°. The British standard for tapered or parallel threads have a thread flank angle of 55°. Identification can also be made by inspecting the root and crest of the threads. The truncation of the root and crest of American standard threads are flat. The truncation of the root and crest of British standard threads are round. Forespar ® offers a wide selection of extremely strong and reliable marine grade plumbing fittings. You will find each product to be...

Forespar® series of Thru-Hull Connectors are precision molded in high strength Marelon ®. Their great strength, light weight and complete freedom from corrosion and electrolysis make them the ideal Thru-Hull Connectors for use above or below the waterline. All Thru-Hull Connectors must be installed with proper bedding compound. We recommend a maximum torque setting of 20 lb/ft. for Series 250, Series 251 and Series 253 Thru-Hull Connectors. The 'S' notation in our model numbers (eg. CF 250S 1/2), indicates a Thru-Hull Connector that has been fitted with a screen. FULL THREADED/FLUSH HEAD...

TAILPIPES / HOSE CONNECTORS Our Tailpipes are also made from high-strength glass-reinforced Marelon ®. Perfect choice for joining hose lines to Forespar" Ball Valves and Seacocks. TAPERED PIPE THREADS Part Model Thread Tube Part Model Molded from high-strength Marelon Dimension 'A' indicates pipe thread size. ^ FEMALE THREADED BARBED HOSE FITTING This fitting is also made of high strength 901014 1/2"(12.7mm) FPTto 1/2"(12.7mm) HOSE BARB 905013 1-1/2"(38.1mm) FPTto 1"(24.4mm) HOSE BARB 905014 1-1/2"(38.1mm) FPTto 1-1/2"(38.1mm) HOSE BARB

VENTED LOOPS Installing one of our vented loops will ensure that fluids will not siphon from tank to tank. Vented Loops are commonly used in the marine toilet system and engine cooling system. The simple valve system incorporated in the top of the loop allows air to enter the line when not in use, yet effectively seals as water or other fluid passes through. Molded in Marelon ®, neither vent nor loop will corrode. The duckbill one way valve is designed to seal properly if particulate matter is present in fluids. The new MF-846 vent barb assembly option can be used in lieu of the standard...
