Sailing Hardware

F or espar® Overseas Agents and Dealer Literature DECKHARDWARE AUSTRALASIA Email: ¡[email protected] St. Maarten, Netherland Antilles Email: [email protected] BUDGEJJMPHNPTT.A. (Main Office) St. Maarten, Netherland Antilles Email: sales @budmar.an BUDGET MARINE-ANTIGUA Jolly Harbour Boatyard Bolans, Antigua, West Indies Email: [email protected] BUDGET MARINE-BONAIRE Kaya Carlos A. Nlcolaas 4 Kralendljk, Bonaire, Netherlands Antilles Email: [email protected] BUDGET MARINE-GRENADA Prickly Bay, St. Georges, Granada Email: [email protected] BUDGET MARINE - ST. MARTIN...

TABLE OF CONTENTS ADAPTING COLLARS, END FITTINGS (POLES) . . . . . . . . . .8 RADAR SPAR™ ALUMINUM TUBING . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 RAILFAST ® AWNING POLES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29 REACHING STRUTS . . . . . . . . . . . . . . . . . . . . . . . . . . .15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35 HARDWARE . . . . . . . . . . . . . . . . . . . . . .32-33 BOOM VANGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17-18 REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . .40 CARGO MATE ™ . ....

WHISKER POLES "I can't imagine sailing downwind without my whisker pole ". I make offshore passages for a living and I count on my Forespar® whisker pole. It's an aluminum and carbon, telescoping model that gives me great flexibility when poling out my headsail. The pole is robust, well engineered and easy to set. When the wind pipes-up I'm able to keep sailing on a deep reach and if it builds more I simply furl the sail, adjust the pole length and keep blasting along. I can't imagine sailing offshore without my Forespar® whisker pole. Sailing Writer Whisker poles are used to "wing out" the f...

LINE CONTROL™ 50/50 CARBON/ALUMINUM "COMBO" WHISKER POLES These Line Control™ Whisker poles offer just the right blend of aluminum and carbon structures to provide the racing or cruising sailor weight and cost savings. They have the strength and weight savings of carbon on the inner tube and the abrasion resistance, durability and cost savings of aluminum on the outer tube. They also feature Forespar's exclusive "Ultra" end fittings (UTS socket inboard and UTR trigger outboard) for further weight reduction "PATENTED" LINE CONTROL™ WHISKER POLES Line Control™ is a proven concept in telescoping...

SMALL TELESCOPING POLES (TWIST LOCK) Telescoping models can be adjusted to any desired length and securely locked in position with an effortless twist of the inner tube. All small poles include strong corrosion-free Lexan end fittings and a Mast Pad Eye with stainless steel screws. Outboard Ends Inboard Ends Telescopes from 53" to 93" 13 lbs. 1 " outer diameter With latch fittings on both ends Telescopes from 72" to 134"/3 lbs. 1- 1/4" outer diameter With latch fittings on both ends HEAVY DUTY TELESCOPING POLES (TWIST LOCK) These telescoping whisker poles are heavy duty two section and three...

Forespar" offers a complete and diversified line of spinnaker poles. We manufacture eight complete end styles from which we create a multitude of combinations to fit the needs of all sailors - racers or cruisers. CUSTOM POLES & KITS Forespar" offers "customized" poles built to specific dimensions, and also "kit" poles in which both ends are left loose to allow the marine dealer or yachtsman to finish the pole himself. End fittings and tubing are available separately for those who wish to assemble poles to their own specifications. DETERMINING POLE LENGTH The length of your spinnaker pole is determined...

SPINNAKER POLE END FITTINGS FORESPAR'S ULTRA SERIES™ Represents the cutting edge in spinnaker pole end fitting technology. Designed for high strength, very low weight and resistance to wear and corrosion the Ultra Series™ composite end fitting is perfect for aluminum or carbon fiber spinnaker poles and whisker poles. The Ultra Series™ is the sailor's choice for inshore and offshore racing and cruising. Available with or without triggers. Maximum LOA Boat Outboard End - 43'. Maximum LOA Boat Inboard End - 36'. All larger boats use GP Series. Length Weight 'Trip line is Spectra™ with terminal eyestrap...

STANDARD SPINNAKER POLES Our Standard Spinnaker Poles have a double bridle topping lift/foreguy system. Unless otherwise specified, all standard poles are supplied with the throat (jaw) facing upward. See price page for information regarding charges for special tubing. STANDARD SPINNAKER POLES - KIT OR CUSTOM LENGTHS (Requires a Forespar® Ring Style, Flange Style or Toggle Car See Pages 11 & 12) ULTRA Piston fitting both ends. ULTRA Piston fitting both ends. ULTRA Trigger one end/ULTRA Piston other. ULTRA Trigger fitting both ends. ULTRA Piston fitting both ends. ULTRA Trigger one end/ULTRA Piston...

ALUMINUM TUBING & SPINNAKER POLE KITS ADAPTING COLLARS For sleeving Forespar" spinnaker pole end-fittings for use on larger diameter tubing, and other applications. To compliment our medium size Whisker Poles (LC 10-18); Forespar " designed the stainless steel PE-3SF & PE-3SC Mast Pad Eyes. Measuring 2-3/4" X 2", both pad-eyes have inside ring diameters of 1-5/8". PE-3SF is for flat mast surfaces. PE-3SC is slightly bent to better accommodate a curved mast. ALUMINUM TUBING Clear anodized to military specification (triple commercial). Prime marine alloy 6063-T6. All tubing sold in stock lengths....

MAST CARS This car slide is offered both in stainless steel and hard coat anodized extruded aluminum. The toggle-pin is stainless steel in each case. Toggle assemblies available separately see replacement parts page. Our strong 1-1/2" toggle spinnaker car is for boats approx. 50' to 70' LOA. Fits the standard Schaefer 41-12 1-1/2" track. Low friction movement due to UHMW inserts. MAST WALL FOR POLES WITH OUR TS & UTS END FITTING, AND USING A FORESPAR® T-125-S CAR, 3" IS SUBTRACTED WHEN GIVEN A 'J' DIMENSION TO ESTABLISH POLE LENGTH. To allow vertical storage on the mast of larger poles up to...
