ELME TOOL CHANGER 717 THE EQUIPMENT FOR CONNECTING TOOLS Standard supply includes: . Reach Stacker Interface . Mounting arrangement to fit the boom head . Mechanical pile slope (MPS) . Powered pile slope (PPS) available as an option . Four vertical pendular ISO twistlocks . Hydraulic sideshift . Hydraulic rotation . Solenoid valves for all hydraulic functions Electrical and mechanical twistlock protection and indication system . Lift interrupt signal . LED-indication lights The ELME Tool Changer 717 is the equipment with well-proven design for connecting various tools under a reach stacker. The ELME Tool Changer 717 is designed for connecting tools, e.g. coil and lifting hook, slab handler and top lift spreader model 716. The tool changer can be connected to any type of tool with four standard twistlock pockets and a standard foot print of 2 500 x 760 mm. ELME Tool Changer 717 is equipped with a MultiFaster hydraulic connector for easy, quick and reliable switch between different tools. This enables smooth handling of many types of loads. TWISTLOCK SYSTEM The twistlock system is manufactured in a rugged design and is well-proven since many years. ELME Tool Changer 717 has hardened ISO quick exchange pendular twistlocks – hydraulically activated and mechanical interlocking against faulty locking and unlocking. SIDESHIFT AND ROTATION SYSTEM Sideshift is executed by one hydraulic cylinder. Rotation is done by a slewing ring with double transmissions for turning and brakes for holding.

©April 2021 ELME Spreader AB ELME TOOL CHANGER 717 ELME Tool Changer 717 with ELME Slab Handler 718. TECHNICAL SPECIFICATIONS Type of lifting system Reach stacker 50 tonnes ± 10 % eccentric load* < 42 sec. between endpoints (calculated speed at 20° C) Mechanical pile slope (MPS) Hydraulics, operating pressure up to Hydraulics, flow Electric – control voltage ELME Tool Changer 717 is equipped with a MultiFaster hydraulic connector for easy, quick and reliable switch between different tools. Black grey RAL 7021 *Extended capacity to 65 tonnes is available as option. All specifications are subject...
