Catalog excerpts

PROMARINE brochure - 1

September 2004 PROMARINE® LIGHTWEIGHT MARINE ACCOMMODATION SOLUTIONS active in passive fire protection marine accommodation Marine Brochure 1 - 12.indd 1 20/10/04 7:37:33 am

Open the catalog to page 1
PROMARINE brochure - 2

PROMARINE® CONTENTS PROMARINE® Panels Marine Regulations Fire Protection Bulkheads Fire Protection Ceilings Fire Protection Flooring Working Characteristics Physical Properties Specialist Services Fire Rated Glass Partitions Fire Stopping Products Bulkhead Profiles Ceiling Profiles PROMARINE® lightweight marine accommodation solutions

Open the catalog to page 2
PROMARINE brochure - 3

PROMARINE® INTRODUCTION Promat UK Limited is part of Promat International, the fire protection division of the ETEX S.A. Group which employs more than 12,000 people worldwide and has a group turnover of € 1.5 billion. Promat UK Limited is responsible for the sales and marketing of marine passive fire protection products and systems to the international shipbuilding market. installed where weight of product is critical, have been successfully Both PROMARINE®-640 and PROMARINE®-450 panels comply fully with the requirements of the Marine Equipment Directive 96/98/EC (amended by Directive 98/95...

Open the catalog to page 3
PROMARINE brochure - 4

PROMARINE® PANEL RANGE PROMARINE® PANEL RANGE Used to provide decorative passive fire protection, Promat Glasgow site for over 20 years. A truly international market leader, PROMARINE®-640 has been supplied to almost every major shipyard in the world and installed on most types of sea-going vessels and offshore platforms. PROMARINE®-640 is a non-combustible autoclaved calcium silicate panel, reinforced with selected minerals and fibres calcium silicate technology. Produced to compliment PROMARINE®-640, PROMARINE®-450 offers improved heat insulation properties while weighing 30% less, at...

Open the catalog to page 4
PROMARINE brochure - 5

MARINE REGULATIONS Marine Equipment Directive 96/98/EC The Marine Equipment Directive (MED) entered into force on 1st January 1999 and covers all fire protection equipment manufactured after this date which is to be installed onto any new or existing European flagged vessel (plus Norway and Iceland flagged vessels). The Marine Equipment Directive 96/98/EC has been amended The purpose of the MED is to ensure that fire protection equipment (amongst other material and systems) must comply with the requirements of international conventions such as SOLAS (agreed by the International Maritime...

Open the catalog to page 5
PROMARINE brochure - 6

BULKHEADS - INSTALLATION INSTRUCTIONS The following installation guide is provided to answer frequently asked questions regarding the assembly of PROMARINE® fire protection bulkheads. As it is not possible to cover every eventuality on every ship, we have based this example on a 'B15' rated partition, using 19.1mm thick PROMARINE®-640 bonded both sides with 0.8mm thick high pressure laminates. Detail 1 - Top and Bottom Channels The first step on any installation is the 'marking off' of the positions of the bulkhead or partition. This is usually done with a chalk line marked on the deck....

Open the catalog to page 6
PROMARINE brochure - 7

BULKHEADS – INSTALLATION INSTRUCTIONS PC-17-G A PC-15-E Detail 1 B C 7 D Detail 2 PJ-1-A RJ-29-S Detail 3 Detail 4 PV-05 PV-06 PA-30-B PV-03 PV-04 PS-24 PA-50-B Detail 5 PROMARINE® lightweight marine accommodation solutions Marine Brochure 1 - 12.indd 7 Detail 6 PROMAT UK LIMITED 18/10/04 4:43:43 pm

Open the catalog to page 7
PROMARINE brochure - 8

CEILING - INSTALLATION INSTRUCTIONS The following installation guide is provided to answer frequently asked questions regarding the assembly of PROMARINE® fire protection ceilings. This example is based on a 'B15' rated ceiling, using 16mm thick PROMARINE®-450, bonded both sides with 0.8mm thick high pressure laminates. Maximum panel dimension is 2430mm x 1210mm. Prior to the installation of PROMARINE®-450 'B15' ceiling and, indeed, the ordering of the materials, the orientation of the ceiling grid must be decided. Several factors must be taken into account, i.e. panel wastage,...

Open the catalog to page 8
PROMARINE brochure - 10

FLOATING FLOOR - INSTALLATION INSTRUCTI PROMARINE® FLOATING FLOOR PROMARINE® Floating Floor is the system to provide A60 fire protection, while offering both thermal and sound insulation. Comprising of 2400mm x 600mm x 20mm floor panels made from PRO MAR I NE®-640, grooved on all four edges and bonded on both sides with 0.6mm thick galvanised steel. 3mm thick pre-cut splines are used to join the panels together. The panels 'float' on 50mm thick, 200kg/m3 mineral wool. PROMARINE® Floating Floor is a 'dry' system and can be walked upon immediately after laying, saving both time and the...

Open the catalog to page 10
PROMARINE brochure - 11

steel bulkhead Internal partition floating floor panels mineral wool mineral wool bulheads only) steel deck Typical floating floor arrangement shaped piece of floating floor held with staples and sealed with PROMASEAL® Silicone Sealant Fitting around bulkhead stiffeners PROMARINE® lightweight marine accommodation solutions

Open the catalog to page 11
PROMARINE brochure - 12

The Promat PROMARINE® Furniture range of non-combustible ships' furniture has been developed to meet the requirements of the latest SOLAS Fire Regulations for passenger carrying vessels. This allows accommodation areas containing furniture and furnishings of restricted fire risk to be downgraded from 'Moderate Fire Risk (Category 7)' to 'Minor Fire Risk (Category 6)'. This has the advantage of reducing the level of fire protection required between the accommodation areas and their surroundings*. 'refer to SOLAS (Consolidated Furniture range consists of • Pre-manufactured items from stock...

Open the catalog to page 12
PROMARINE brochure - 13

PROMARINE® FURNITURE RANGE All Promat PROMARINE® Furniture range is supplied 'flat packed' for ease of transport and handling. Each pack contains all the fixtures and fittings required as well as detailed assembly instructions. Promat PROMARINE® Furniture range is manufactured from our Promat PROMARINE®-450 panels, offering a considerable weight saving over combustible materials such as chipboard or MDF, while providing the comfort, practicality and function of traditional joinery products. The laminate finish provides a durable, low maintenance, easy clean surface that Furniture drawings

Open the catalog to page 13
