2019 CONTAINER SOCKETS
16Pages

Everytime six inches water under your keel Our container sockets are named by famous ships. Just like these ships always have enough water under their keel, our container sockets are absolutely reliable. In use worldwide, in all weathers, at all times of the day. Now we’re just waiting for the keel laying of an innovative ship, which could be proud to carry the name Snappy. We are curious … Alterations and technical developments reserved

Power TowerContainer Socket with Snap-In-Technology and Non-Metallic Flange T Technical Data Name & No. Spare Parts on Request Available in any RAL colour. Additional available with LED indicator.

Power Panel karl-dose.de/Power Panel Container Socket Technical Data NEW in our container socket range space saving multi-level configuration up to 96 gangs on 2m2 only freedom in plug-in positioning management already during design/construction phase flexible planning of storing position on board to cover seasonal peak volume easy upgrade of extra power thermal capacity: best efficiency due to limited space on board special ergonomic 30° angle for safety and smooth operation new safety lock by flap bayonet cap approved safety with patented IP 67 Snap-In-Technology with LED indicator based...

Snappy Container Socket with Snap-In-Technology and Non-Metallic Flange Alterations and technical developments reserved.

SnappyContainer Socket with Snap-In-Technology and Non-Metallic Flange Snap-In Technology 1. insert plug CSI 2. turn plug 90 degrees and secure bayonet Technical Data Name & No. IP 67 stainless steel housing, plastic flange, cable gland brass 3P+PE 32A 400 - 440V 50/60 Hz flange without external elements switch fastening uses unique snap-in technology no interior actuating linkage with circuit breaker in 10 kA and 25 kA version powdercoated RAL 7006 (beige gray) cable gland: M24x1,5 up to M72x2 optional Available in any RAL colour. Available with brass flange. Additional available with LED...

Snappy Container Socket with Snap-In-Technology and Non-Metallic Flange

SnappyContainer Socket with Snap-In-Technology and Non-Metallic Flange CSI

Power Selector karl-dose.de/Power Selector Container Socket Extension with Snap-In-Technology and Non-Metallic Flange Power Selector CSI322K ergo in our container socket range Maße ohne Toleranzangabe nach DIN ISO 2768-mittel Rohteiltoleranzen DIN 1687-GTA 17 Power Selector CSI322K ergo • extension for container sockets • IP 67 • stainless steel housing and -mounting brackets plastic flange • 3P+PE • 32A • 380V, 400V - 440V • 50/60 Hz • flange without external elements • switch fastening with snap-in technology • no interior actuating linkage • short-circuit breaking capacities 10 kA •...

Artemis karl-dose.de/Artemis CEE-Socket and Plug 32A Artemis 2005/L Technical Data Name & No. When ordering, please state position of earth contact (o'clock position) or operation voltage. Monitoring-socket, available with brass cap, supplement charge. Polished products available for a extra charge.

Technical Data Name & No. • CEE-socket 16A • IP 56 • brass casing and cover, plastic bayonet cap, steatite socket interior • 3P+PE • max. 500V AC • cable gland: M24x1,5 • undetachable cover screws M6 • CEE-coupling 16A • IP 56 • plastic casing • 3P+PE • max. 500V AC • CEE-plug 16A • IP 56 • plastic casing, steatite plug interior • 3P+PE • max. 500V AC • cable gland: M30x2 with threaded bushing • CEE-plug 16A • IP 56 • brass plug sleeve and bayonet ring, steatite plug interior • 3P+PE • max. 500V AC • cable gland: M30x2 with threaded bushing steatite socket interior 16A 3P+PE steatite plug...

Langora CEE-Socket and Plug 16A 2P+PE Technical Data Name & No. When ordering, please state position of earth contact (o’clock position) or operation voltage.

Archon 2050 CEE-Socket and Plug 63A Technical Data Archon 2050/D Name & No. When ordering, please state position of earth contact (o’clock position) or operation voltage.

karl-dose.de CS-FK When ordering these spare parts, please state hull no. and name of the ship.

Spare Parts Container Sockets:

Earth Contactinformation karl-dose.de CEE Sockets and Plugs CEE sockets and plugs for refrigerated containers are made to CEE Publication 17/2, DIN 49462/63, IEC Publication 309 and ISO 1496. This international specification features an identification groove to suit the earth contact bush on the socket and a matching lug relative to the earth contact pin on the plug thus ensuring that only plugs that are identical in respect of power, voltage and frequency rating with the socket, can be plugged into the socket. The position of the earth contact bush is shown as a clock hand...

Degrees of Protection acc. to DIN EN 60529 IP-Code Degree of Protection Against Solid Foreign Objects First Code Number example IP 54 first code number 5 = dust-protected second code number 4 = protected against splashing water Attention: code citation without engagement
