Cabrinha Kites
Switchblade 2

Switchblade 2

Product catalog summary

Introduction
This document is a user manual for the Switchblade kite, providing comprehensive instructions on kite operation, steering, launching, landing, relaunching, tuning, and repairs. It emphasizes safety and proper technique to ensure effective and secure kite flying.

Protective Equipment and Kite Inspection
Before each session, ensure all protective equipment, such as helmets, is in good condition. Regularly inspect the kite and control system for any damage like punctures or abrasions, and check fly lines for wear or knots that could weaken them.

Rigging and Setup
Avoid rigging on abrasive surfaces like asphalt or gravel to prevent equipment damage, which is not covered under warranty. Use sand or grass instead. Secure the kite with sandbags, not rocks, to avoid damage.

Between Sessions
Do not leave an inflated kite unattended or exposed to wind and sunlight for long periods. Secure it with sand to prevent fluttering and damage.

Proper Storage
Wash and dry the kite thoroughly before storing it in a clean, dry, cool place. Avoid placing heavy objects on it and do not leave it inflated in extreme temperatures.

Beach Etiquette
Follow local rules and regulations, and be considerate of other beach users. Secure your kite properly and avoid touching others' equipment without permission.

Kite Overview
The Switchblade 2 kite features a 4-line body, bridle, steering line attachment points, and a SPRINT inflation system for quick setup. It includes various components like pulleys, airlock valves, and line connectors.

SPRINT Inflation System
This system allows for quick inflation through a single point, maintaining even pressure across the kite. It includes features to isolate air in struts to prevent total deflation if damaged.

Inflation Basics
Ensure the kite is secured with sand during inflation. Use the supplied pump and adapter, and check that all air clips are open. Proper inflation is crucial for performance and safety.

Securing and Deflating the Kite
Secure the kite with sandbags and avoid leaving it exposed to wind. Deflate by unscrewing the release valve and ensure no debris enters the bladder.

Attaching Control Lines
Connect control lines using larks head knots, ensuring secure attachment to the kite's bridles. Follow the manual for specific instructions.

Area of Operation and Kite Positions
Understand the power zones of kiteboarding to avoid accidents. Avoid keeping the kite in the neutral position on land to prevent lofting.

Specifications and Safety Precautions
The manual highlights the power zones of the kite, advising caution when flying in areas where the kite has the most power. It stresses the importance of learning kite handling skills on land before moving to water and always keeping an eye on the kite.

Steering Techniques
Key points for steering include using slow, deliberate movements and avoiding abrupt motions. The manual provides step-by-step instructions for steering the kite left and right, emphasizing the importance of maintaining control and being prepared to change direction.

Planning and Executing a Launch
Proper launch planning involves selecting a spacious area and setting up the kite at an angle to the wind. The manual warns against launching directly downwind due to the risk of excessive power. It provides a detailed procedure for launching with a partner, including safety checks and communication signals.

Landing Procedures
Landing instructions focus on ensuring a clear area and using a partner to safely bring the kite down. The manual advises against landing near people or obstacles and provides steps for a controlled landing.

Relaunching the Kite
For relaunching, the manual stresses the importance of proper inflation and provides guidance on steering the kite onto its side for relaunch. It advises patience and careful handling, especially in light wind conditions.

Tuning the Kite
Tuning involves adjusting the tension of the steering and depower lines to optimize performance. The manual warns against over-sheeting, which can hinder the kite's efficiency and power.

Repair Instructions
The document includes repair procedures for minor and major tears, as well as strut bladder repairs. It provides step-by-step instructions for using repair tape and handling bladder repairs, emphasizing cleanliness and careful handling.

Repairing Strut Bladders
1. Identify the location of the hole. If on a seam, use glue; if on a flat area, use a patch.
2. Inflate the bladder to check for leaks, submerge in water to locate holes, and mark them.
3. Dry the area, apply glue or patch, and let it dry for 20 minutes.
4. Reinsert the bladder into the sleeve using flying lines to guide it.
5. Inflate partially to ensure proper fit and reattach air distribution tubes.

Repairing Leading Edge Bladders
1. Access the bladder by opening Velcro closures and zippers.
2. Remove and keep track of valve assemblies and air clips.
3. Use flying lines to guide the bladder out for repair.
4. Locate and mark leaks, apply glue or patch, and let dry.
5. Reinsert the bladder, ensuring no twists, and secure valves.
6. Partially inflate to check fit and reassemble valve components.

Glossary
Trainer Kite: A small kite for land practice.
Inflatable Kite: Kite with tubes for flotation and relaunching.
Leading Edge (LE): Front tube of the kite.
Struts: Outer fabric tubes housing inflatable bladders.
Airlock: Valve for inflation/deflation.
SPRINT: Rapid inflation technology.
Control Bar: Device for steering the kite.
Power Zone: Area where the kite has maximum power.
Neutral Position: Kite position above the rider's head, risky on land.
Wind Terms: Definitions for wind directions and conditions like onshore, offshore, gusty, etc.

Conclusion
This manual serves as a comprehensive guide for safely and effectively operating the Switchblade kite, with detailed instructions and safety precautions to enhance the user's experience.

Catalog excerpts

DO NOT USE THIS PRODUCT UNLESS YOU HAVE READ AND UNDERSTAND THESE WARNINGS, CAUTIONS, AND INSTRUCTIONS WHICH ARE FOR YOUR SECURITY AND PROTECTION. THIS INFORMATION MAY BE SUBJECT TO CHANGE AT ANY TIME. FOR CURRENT UPDATES, PLEASE VISIT OUR WEBSITE AT: WWW.CABRINHAKITES.COM IF YOU ARE BELOW THE AGE OF 18, YOU SHOULD HAVE YOUR PARENT OR GUARDIAN READ THESE WARNINGS, CAUTIONS AND INSTRUCTIONS AND SHOULD NOT USE THIS PRODUCT UNLESS YOU ARE UNDER THE PROPER GUIDANCE AND SUPERVISION OF SUCH A PERSON. The use of this product exposes the user to many unavoidable and unexpected risks, dangers and hazards....

Open the catalog to page 3

continued from previous page... RECOMMENDED KITESURFING PRACTICE: KITESURFING is an extremely diverse sport, with many disciplines and ability levels. As with all sports, there can be certain inherent risks. The following contains key security points to remember when operating your Cabrinha kite. • Kitesurng is a HAZARDOUS activity and the use of Kitesurfing equipment involves the risk of serious personal injury to any part of the user’s body or death. • Injuries are an INHERENT RISK of kitesurng and the participation in kitesurng implies the user’s acceptance and express assumption of those...

Open the catalog to page 4

INDEX 2 3 4 5 6 7 Introduction Important Information Wind, Water, & Weather Conditions / Wind Range Chart Know Your Ability Level / Kiteboarding Location Important Information Beach Etiquette KITE OVERVIEW & CONTROL SYSTEM 8 Switchblade 2 Overview SETUP 10 Sprint Inflation System 11 Inflating the Kite 12 Tips for Securing Your Kite Deflating the Kite 16 Attaching Control Lines SWITCHBLADE 2 USER MANUAL HOW TO: 17 Area of Operation / Kite Positions, Zones & Power 19 Steering 20 Planning Your Launch 21 Launching & Landing with a Partner 23 Relaunching 24 Tuning The Kite 25 27 Repairs - Tears /...

Open the catalog to page 5

I N T R O D U CTION THANK YOU for purchasing a Cabrinha kite and welcome to the sport of kiteboarding. As you may know, the excitement of Kiteboarding is attracting people of all ages from all corners of the globe. It’s one of the most dynamic and fastest growing sports in the world. CAUTION: Ithave suppliedoverwhelming ifuser’s manual. It in anhelp to educate can also be not approached educated manner. That’s why we this extensive will you about your new kite and about the ways in which to use it. It contains information regarding the setup, care and maintenance of your Switchblade kite. For...

Open the catalog to page 6

I M P O R T A N T I NFORMATION IMPORTANT INFORMATION KITEBOARDING is an extremely diverse sport, with many disciplines and ability levels. As with all sports, there are certain inherent risks. The following contains key points to remember when operating your Cabrinha kite. • Be familiar with the set up and use of the supplied security systems: OVERRIDE and the Harness Loop Quick Release systems. • Make sure your control system is rigged and used according to the supplied instructions. • Make sure your kite is compatible with the control system. • Always use your Cabrinha kite with a security...

Open the catalog to page 7

IMPORTANT INF O R M A T I O N WIND, WATER, & WEATHER CONDITIONS / WIND RANGE CHART WIND, WATER, AND WEATHER CONDITIONS • Do not underestimate the power of the wind. • Be aware of unpredictable and changing weather conditions. • Avoid “offshore” or “onshore” wind conditions. • Avoid strong, gusty wind. • Be careful of wave conditions, especially when learning. • Be educated about tides and rip currents. • Be mindful of your ability level. Do not kiteboard if conditions are beyond your ability level. • Be educated about air and water temperatures and wear appropriate protection against the elements....

Open the catalog to page 8

IMPORTANT IN F O R M A T I O N KNOW YOUR ABILITY LEVEL / KITEBOARDING LOCATION KNOW YOUR ABILITY LEVEL KITEBOARDING LOCATION • Do not attempt kiteboarding without appropriate instruction. • Do not kite alone. • Launch, land, and ride together with a partner or have someone on shore who can keep an eye on you. • Make sure you are in good physical condition before using this product. • Practice ying a small, traction kite or a “trainer kite” before ying this kite. • The more time spent on the “trainer kite”, the faster you will learn. • Make sure you are a procient swimmer before using this product...

Open the catalog to page 9

I M P O R T A N T I N FORMATION KITE CARE Due to the often extreme nature of kiteboarding, a thorough approach should be taken when caring for your kite and all its associated rigging, as well as your protective gear. PREPARING FOR YOUR SESSION • Thoroughly check your protective equipment (helmet, etc.) to make sure it is in working order and in good condition. • A frequent inspection of the kite and the control system should be made in order to identify punctures, tears, or abrasions in the canopy, struts, or security systems. It is also necessary to check the y lines for wear and for unwanted...

Open the catalog to page 10

B E A C H E TIQUETTE BEACH ETIQUETTE Here are some basic things to consider when sharing beaches and water accesses with other users: SAFETY • Follow the instructions outlined in this manual. • Follow the instructions and rules and regulations posted at the areas you use. • Check with local kiteboarding associations and shops prior to launching in a new area. There may be local rules and regulations to follow which are not posted. • Utilize common sense. • Do not touch other people’s gear, unless instructed to do so by the owner. Picking up their bars, kites, etc. may disrupt a setup ritual they...

Open the catalog to page 11

KITE OVE R V I E W Switchblade 2 SWITCHBLADE 2 OVERVIEW - POWERDRIVE 121 1. 4-Line Kite Body 2. Bridle 3. Steering (Rear) Line Attachment Point 4. Depower (Front) Line Attachment Point 5. Pulleys (KS6SEBP) 6. Multi-Segmented Dacron Leading Edge 7. True Match 3-D Battens 8. Airlock High Volume Valve (KS6ALVA) 9. SPRINT Single point ination valves 10. SPRINT Air distribution tubes (KS6STCOLA) 11. SPRINT Air clips (KS6PINCHC) 12. Front Flying Line (KS6RFL) 13. Rear Flying Lines (KS6RFL) 14. Line Connectors (FRONT/REAR) (KS6RECOST) 15. Front Leader Lines 16. Flagging Ring 17. Centerline Adjustment...
