Contra Bow Kite

Product catalog summary

Proper Kite Care and Storage

Minimize wind exposure by placing sand between struts and near the trailing edge.
Avoid prolonged sunlight exposure; store in shaded areas when not in use.
Wash with fresh water and dry thoroughly before storing in a clean, dry, cool place.
Do not store the kite wet or with sand and foreign objects.
Avoid placing heavy objects on the kite bag and do not leave the kite inflated in extreme temperatures.
Wash the control system with fresh water periodically and store it dry.

Beach Etiquette and Safety

Follow all instructions and local regulations when kiteboarding.
Do not touch others' equipment without permission.
Secure kites with sand or sandbags; never leave an inflated kite unattended.
Set up gear in spacious areas and be considerate of other beach users.
Be ready to assist other kiteboarders.

Kite Overview and Setup

The kite features a 4-line body, bridle, steering and depower line attachment points, and a SPRINT inflation system.
The SPRINT system allows quick inflation through a single point, maintaining pressure even if a strut is damaged.
Proper inflation is crucial for performance; avoid under or over-inflation.
Secure the kite with sand and avoid using sharp objects.

Inflation and Deflation Procedures

Inflate the kite with the leading edge facing the wind, using the supplied pump leash.
Ensure all air clips are open for even inflation.
Deflate by unscrewing the release valve and unclipping air clips at each strut.
Clear valves of debris before storing the kite.

Control System Attachment

Connect control lines to the kite using larks head knots, ensuring secure attachment.
Refer to the control system manual for compatibility and setup details.

Kiteboarding Basics

Understand the area of operation and maintain a safe distance from others.
Avoid keeping the kite in the neutral position on land to prevent lofting.
Recognize the power zones and avoid flying the kite in the power zone when learning.
Generate power by steering the kite from low to high positions.

Steering Techniques

Practice steering with a trainer kite on land before moving to water.
Keep eyes on the kite and steer slowly to avoid abrupt motions.

Steering the Kite

To steer the kite left, hold the control bar with both hands and pull it slightly with your left hand. This will bend your left arm and extend your right arm. Pull slowly to control the kite's power. To steer right, do the opposite with your right hand. Always be ready to steer in the opposite direction if needed.

Planning Your Launch

Choose a launch area with at least 100 meters of space on all sides. Set up the kite at an angle off the wind, not straight downwind, to reduce power during launch. Your partner should hold the kite while you stand 30 meters away at the control bar. Launch slowly and at an angle.

Launching with a Partner

Ensure your Quick Release System is set up correctly. Check all equipment and lines before launching. Your partner should hold the kite at 100° off the wind and release it upon your signal. Avoid abrupt motions and steer the kite slowly to maintain control.

Landing a Kite to Your Partner

Instruct your partner on proper landing techniques. Approach the shore slowly, keeping the kite low. Your partner should grab the kite at the leading edge strut and avoid touching the bridles or flying lines.

Relaunching

Ensure the kite is properly inflated. If the kite lands on its face, steer it onto its side to relaunch. Pull the rear leader line to lift the wingtip and guide the kite to the edge of the wind window before steering it back into the sky.

Tuning the Kite

Proper tuning enhances performance. Adjust the steering and de-power lines for optimal tension. Avoid over-sheeting, which can slow the kite or cause it to fly backwards. Use the Centerline Adjustment Strap (CAS) to fine-tune the kite's power.

Repairing Tears and Strut Bladders

For minor tears, use kite repair tape on both sides of the tear. For strut bladder repairs, ensure the kite is clean and dry. Follow detailed steps to remove, repair, and reinsert the bladder, ensuring it is properly inflated and secured.

Leading Edge Bladder Repair Procedure

Access the bladder by unzipping the center access pocket and undoing Velcro closures.
Separate the Airlock Valve Assembly and disassemble the SPRINT valves.
Use flying lines to secure the bladder ends and gently remove the bladder from the sleeve.
Inflate the bladder, submerge in water to locate leaks, and mark any holes found.
Repair holes using glue or patches, depending on the location of the hole.
Reinsert the bladder into the sleeve using flying lines to guide it back into place.
Reassemble valves and ensure the bladder is properly positioned and inflated.

Glossary of Kiteboarding Terms

Trainer Kite: A small kite used for practice on land.
Inflatable Kite: A kite with inflatable tubes for buoyancy and relaunching.
Leading Edge (LE): The front inflated tube of the kite.
Struts: Fabric tubes housing inflatable bladders for structure.
Airlock: A two-part valve for inflation and deflation.
SPRINT: Single Point Rapid Inflation Technology.
Control Bar: Device used to steer the kite.
Power Zone: Area where the kite has the most power and pull.
Neutral Position: Position above the rider's head where the kite has the least power.
Wind Terms: Definitions for wind directions like onshore, offshore, and sideshore.

Catalog excerpts

DO NOT USE THIS PRODUCT UNLESS YOU HAVE READ AND UNDERSTAND THESE WARNINGS, CAUTIONS, AND INSTRUCTIONS WHICH ARE FOR YOUR SECURITY AND PROTECTION. THIS INFORMATION MAY BE SUBJECT TO CHANGE AT ANYTIME. FOR CURRENT UPDATES, PLEASE VISIT OUR WEBSITE AT: WWW.CABRINHAKITES.COM IF YOU ARE BELOW THE AGE OF 18, YOU SHOULD HAVE YOUR PARENT OR GUARDIAN READ THESE WARNINGS, CAUTIONS AND INSTRUCTIONS AND SHOULD NOT USE THIS PRODUCT UNLESS YOU ARE UNDER THE PROPER GUIDANCE AND SUPERVISION OF SUCH A PERSON. The use of this product exposes the user to many unavoidable and unexpected risks, dangers and hazards....

Open the catalog to page 3

continued from previous page.. • Kitesurfing is a HAZARDOUS activity and the use of Kitesurfing equipment involves the risk of serious personal injury to any part of the user's body or death. • Injuries are an INHERENT RISK of kitesurfing and the participation in kitesurfing implies the user's ac- ceptance and express assumption of those risks. • Children should always be under adult supervision, • It is strongly recommended that beginners take lessons, • ALWAYS inspect your equipment for signs of wear and tear each time before use, particularly all lines, canopy, bladders, screws and fittings....

Open the catalog to page 4

4 Wind, Water, & Weather Conditions / Wind Range Chart 5 Know Your Ability Level / Kiteboarding Location KITE OVERVIEW & CONTROL SYSTEM 10 Sprint Inflation System 12 Tips for Securing Your Kite 16 Attaching Control Lines 17 Area of Operation / Kite Positions, Zones & Power 20 Planning Your Launch USER MANUAL Launching & Landing with a Partner Repairs - Tears / Struts Bladders Repairs - Leading Edge Bladders

Open the catalog to page 5

THANK YOU for purchasing a Cabrinha kite and welcome to the sport of kiteboarding. As you may know, the excitement of Kiteboarding is attracting people of all ages from all corners of the globe. It's one of the most dynamic and fastest growing sports in the world. CAUTION ■ It can also be overwhelming if not approached in an educated man- ner. That's why we have supplied this extensive user's manual. It will help to educate you about your new kite and about the ways in which to use it. It contains information regarding the setup, care and maintenance of your Contra kite. For information about...

Open the catalog to page 6

MPORTANT INFORMATION IMPORTANT INFORMATION KITEBüARDING is an extremely diverse sport, with many disciplines and ability levels. As with all sports, there are certain inherent risks. The following contains key points to remember when operating your Cabrinha kite. Be familiar with the set up and use of the supplied security systems: OVERRIDE and the Harness Loop Quick Release Make sure your Powerlock CS3 is rigged and used according to the supplied instructions. Make sure your kite is compatible with the Powerlock CS3, Always use your Cabrinha kite with a security system, NEVER permanently attach...

Open the catalog to page 7

IMPORTANT INFO R M A T I O N WIND, WATER, & WEATHER CONDITIONS / WIND RANGE CHART WIND, WATER, AND WEATHER CONDITIONS • Do not underestimate the power of the wind. • Be aware of unpredictable and changing weather conditions. • Avoid “offshore” or “onshore” wind conditions. • Avoid strong, gusty wind. • Be careful of wave conditions, especially when learning. • Be educated about tides and rip currents. • Be mindful of your ability level. Do not kiteboard if conditions are beyond your ability level. • Be educated about air and water temperatures and wear appropriate protection against the elements....

Open the catalog to page 8

MPORTANT INFORMATION KNOW YOUR ABILITY LEVEL / KITEBOARDING LOCATION KNOW YOUR ABILITY LEVEL • Do not attempt kiteboarding without appropriate instruction, • Launch, land, and ride together with a partner or have some- • Make sure you are in good physical condition before using this product. • Practice flying a small, traction kite or a "trainer kite" before flying this kite. • The more time spent on the "trainer kite", the faster you will • Make sure you are a proficient swimmer before using this product in or near the water. • Make sure the wind and water conditions are within your ability...

Open the catalog to page 9

MPORTANT INFORMATION KITE CARE Due to the often extreme nature of kiteboarding, a thorough approach should be taken when caring for your kite and all its as- sociated rigging, as well as your protective gear. PREPARING FOR YOUR SESSION • Thoroughly check your protective equipment (helmet, etc.) to make sure it is in working order and in good condition, • A frequent inspection of the kite and the control system should be made in order to identify punctures, tears, or abrasions in the canopy, struts, or security systems. It is also necessary to check the fly lines for wear and for unwanted knots,...

Open the catalog to page 10

BEAGH ETIQUETTE BEACH ETIQUETTE Here are some basic things to consider when sharing beaches and water accesses with other users: • Follow the instructions outlined in this manual, • Follow the instructions and rules and regulations posted at the beaches you use, • Check with local kiteboarding associations and shops prior to launching in a new area. There may be local rules and regula- tions to follow which are not posted. • Utilize common sense, • Do not touch other people's gear, unless instructed to do so by the owner. Picking up their bars, kites, etc. may disrupt a setup ritual they have....

Open the catalog to page 11

KITE OVERVIEW CONTRA KITE OVERVIEW - POWERLOCK CS3 3. Steering (Rear) Line Attachment Point 4. Depower (Front) Line Attachment Point 6. Multi-Segmented Dacron Leading Edge 7. True Match 3-D Battens 8. Airlock High Volume Valve (KS6ALVA) 9. SPRINT Single point inflation valves 10. SPRINT Air distribution tubes (KS6STC0LA) 12. Front Flying Line (KS6RFL-) 13. Rear Flying Lines (KS6RFL-) 14. Line Connectors (FRONT/REAR) (KS6REC0ST) 12. Front Leader Lines 14. Centerline Adjustment Strap (KS60VUPKT) 20. Depower Main Line (KS6SQCLDL) 27. Harness Loop Quick Release 28. Harness Loop w/ Security Pin (KS6HL-...
