Ro Ro-Pax Ferry

Product catalog summary

Hull Data:
- Length overall (Loa): 180.00 m
- Length between perpendiculars (Lpp): 167.50 m
- Breadth (B): 30.50 m
- Depth (D): 15.80 m
- Draft (T): 6.70 / 7.50 m
- Deadweight: 7600 / 11300 t
- Gross Tonnage (GT): 41300
- Contract speed: 23.90 knots
- Main engine: 4 x Wartsila 8L 46F MCR
- Rated output: 38,400 kW
- RPM: 600
- Crew: 56 persons

Classification and Regulations:
- Class position: I +Hull, +MACH, Ro-Ro Passenger Ship, Unrestricted navigation, +AUT-UMS, +AUT-PORT, AVM-DPS, SYS-NEQ-1, MON-SHAFT, COMF, COMF-NOISE-1, COMF-VIB-1, +REF-STORE, CLEANSHIP, +ALP, INWATERSURVEY, SDS
- Flag: France
- Rules and regulations: French national regulations, Division 190 “Accessibilité” SOLAS 2009, Stockholm Agreement, MARPOL Annex VI – Tier 2

General Plan of the Ship:
- Main deck level with stern load ramp, driving length: 1119 m
- Lower garage for commercial vehicles, driving length: 304 m
- Upper deck truck, driving lane length: 1061 m
- Area for dangerous cargo on open deck at stern, separated gastight
- Deck car, driving length: 1123 m
- Deck passenger cabin
- Deck of public space
- Deck crew with steering
- Helicopter platform

Equipping Superstructure After Launching:
- Cabin types: A2, A4, B4, Senior officers
- Cabins for commander and governor of the machine
- Bar

Contact Information:
- Brodosplit Shipyard Ltd., Put Supavla 21, P.O. Box 517, HR-21000 Split, Croatia
- Tel: +385 21 391 699, 392 204
- Fax: +385 21381 203, 382 526
- Website: www.brodosplit.hr

Catalog excerpts

Ro-Pax Ferry & Cargo Ship

Open the catalog to page 1

HULL DATA Length between perpendiculars, Lpp 167,50 m Conract speed Main engine Engine type Rated output

Open the catalog to page 2

Class of ship, flag, rules and regulations • Class position: I +Hull, +MACH, Ro-Ro Passenger Ship, Unrestricted navigation, +AUT-UMS, +AUT-PORT, AVM-DPS, SYS-NEQ-1, MON-SHAFT, COMF, COMF-NOISE-1, COMF-VIB-1, +REF-STORE, CLEANSHIP, +ALP, INWATERSURVEY, SDS • Flag: France • Rules and regulations: French national regulations, Division 190 “Accessibilité” SOLAS 2009 Stockholm Agreement MARPOL Annex VI – Tier 2

Open the catalog to page 3

General plan of the ship: Main deck level with the stern load ramp, driving the length of Lower garage for commercial vehicles, driving the length of the The upper deck truck, driving lane length 1061 m Area for dangerous cargo on the open deck on the stern section separated from the garage door gastight Deck car, driving the length of the strip 1123 m Deck passenger cabin Deck of public space Deck crew with the steering Helicopter platform
