Containers & Reefers

Product catalog summary

Overview: The document provides technical specifications and details for two types of reefer/container ships, namely the m/s LADY KORČULA and m/s ATLANTIC FRIGO, built by Shipyard BRODOSPLIT. These vessels are designed for transporting refrigerated goods such as frozen meat, fruit, and palletized cargo.

m/s LADY KORČULA Specifications:

Capacity: 600,000 CU.FT
Painting: Cargo holds with bitumenous, water ballast tanks with coal tar epoxy, underwater hull with coal tar epoxy + SPC, deck and exposed superstructure with epoxy.
Cargo Equipment: Includes various cargo hatches and gears, with 16 compartments and 8 independent cooling zones.
Refrigeration: R22 indirect expansion system with brine as secondary fluid.
Auxiliary Engines: Four diesel-generator sets (1,280 kW each) and one emergency generator (96 kW).
Heating Plant: Composite oil-fired boiler with a capacity of 2.3 t/h.
Classification: LR; W 100 A1, W LMC, UMS, W RMC, (CA), LI, SCM.
Dimensions: Length overall 155.25 m, breadth moulded 23.40 m, depth moulded 13.20 m.
Engine: BRODOSPLIT-MAN-B&W 7L60MC, 13,440 kW / 123 rpm.
Trial Speed: 21.6 knots at 90% SMCR.
Capacities: Cargo holds 16,713 m3, ballast tanks 2,407 m3, heavy fuel oil 1,657 m3.
Crew: 25 members.

m/s ATLANTIC FRIGO Specifications:

Capacity: 430,000 CU.FT / 250 TEU
Design: Single screw fast refrigerated vessel with four continuous decks and forecastle.
Classification: LRS; W100 A1, WLMC WRMC (-280C), UMS, HR; W100 A1-1-HL-At W M1-AUT1 R +.
Dimensions: Length overall 143.00 m, breadth moulded 22.50 m, depth moulded-main deck 13.20 m.
Engine: BRODOSPLIT-MAN-B&W 6L60MC, 8,340 kW/117 rpm.
Trial Speed: 19.5 knots at 85% MCR.
Capacities: Cargo holds 12,000 m3, containers 250 TEU, heavy fuel oil 1,320 m3.
Crew: 28 members.
Cargo Refrigeration: Freon 22 direct expansion system with individual cooler/fan assemblies.
Auxiliary Engines: Four electric generator sets (780 kW each) and one emergency diesel generator (100 kW).

Key Features:

Both vessels are equipped with advanced refrigeration systems suitable for transporting perishable goods under controlled temperatures.
They feature robust cargo handling equipment and are designed for efficient loading and unloading operations.
The ships are classified under reputable maritime standards ensuring safety and reliability in operations.

Catalog excerpts

5containers 11/9/03 12:42 Page 73 Containers & Reefers CONTAINE

Open the catalog to page 1

Reefer/Container Ship

Open the catalog to page 2

Owner / Flag: Sister vessel: m/sLADY KORCULA Lady Navigation Inc. / Lberia Single screw diesel engine driven Reefer / Container Vessel with bulbous bow, transom stern and long forecastle. Living quarters including navigation bridge and engine room lo- cated aft. Double bottom / double side tanks and peak tanks intended for segregated ballast. Cargo space divided into four (4) holds and eight (8) refrigerating compartments with separate air cooling. Structural steel and profiles made of mild steel. Intended cargoes: frozen meat, fruit include banana, pal- letised cargo, containers. Deadweight...

Open the catalog to page 3

Reefer/Container Ship

Open the catalog to page 4

Sister ship: Fresh Water Marine Inc. / Panama Single screw fast refrigerated vessel for world trade suit- able for transport of frozen meat, fish, bananas, other trop- ical fruit cargoes and containers as well. The vessel has four (4) continuous decks and forecastle. Length overall Breadth moulded Depth moulded-main deck Draught, design / scantling Corresponding deadweight Gross tonnage Main engine: BRODOSPLIT-MAN-B&W 6L60MC Trial speed at 85% MCR and draft of 7.2 m 19.5 knots -28 "0, Cargo hatch covers and handling equipment The hatch covers an weather deck are of folding hydraulically driven...

Open the catalog to page 5

Containers & Reefers

Containers & Reefers
