Introduction
The Blue Wave Marine Rigging Hardware Catalogue presents an extensive selection of fittings, including rigging screws, terminals, tangs, and accessories. Developed since 1958, the catalogue emphasizes high-quality materials that adhere to marine standards.

Product Specifications

Rod Fittings: Comprising spreader cups, stemball tangs, and terminals, these are crafted from high-polished acid-proof stainless steel for marine durability.
Rigging Screws: Designed for wire and rod, these screws are made from high-polished stainless steel, featuring MTR and MDR models with specific load capacities and adjustment capabilities.
Spreader Tipcup: Tailored for demanding boat owners, these are constructed from high-polished stainless steel with defined dimensions and load capacities.

Safety and Usage Recommendations
It is advised that the working load should not surpass one-third of the maximum breaking load. Users must select the appropriate cable diameter and ensure correct assembly.

Technical Data and Tables
The catalogue provides comprehensive tables detailing product specifications, including dimensions, load capacities, and material tolerances. Key data covers rod sizes with break loads, fitting dimensions, and material specifications.

Conclusion
Blue Wave Marine remains committed to innovation and delivering superior rigging solutions for marine use. Customer feedback is welcomed to enhance product offerings further.

Catalog excerpts

Bluewave Rod Rigging Hardware Catalogue-2

Index Page Rod fittings Spreader Tipcup Stemball tang Sleeve for carbon masts External stemball tang External eye tang MTR rigging screws MDR – Mono diagonal rigging screw Rigging screws for rod Spreader bend for rod Stemball for rod Socket for rod Stud terminal for rod Stemball terminal for rod “T” terminal for rod Eye terminal for rod Toggle terminal for rod Furler Eye Terminal for rod Welcome Welcome to the new and extended Blue Wave Marine Rigging Hardware Catalogue. We are proud to present, a more comprehensive range of fittings. New rigging screws for wire and rod, Þttings, standard and...

Open the catalog to page 2

Bluewave Rod Rigging Hardware Catalogue-13

FURLER EYE TERMINAL FOR ROD High Polished acid proof Stainless Steel The "Furler Eye Terminal" is a highly sophisticated rod eye. It enables the rigger to fit the rod eye onto the rod after the cold heading. It can also be used to replace broken or stuck fittings without having to do a time and cost consuming replacement. G A1 L1 D2 L2 ROD SIZE D1 CAT. NO. ROD MM ROD SIZE G UNF L1 L2 D1 D2 A1 FS058060 6,0 9 5/8“ 62,0 28,0 13,2 10,6 10,0 FS058064 6,4 10 5/8“ 62,0 28,0 13,2 10,6 10,0 FS034071 7,1 12 3/4“ 73,5 36,0 16,5 14,0 12,0 FS034074 7,4 15 3/4“ 73,5 36,0 16,5 14,0 12,0 FS034080 8,0 3/4“ 73,5...

Open the catalog to page 13
