Product catalog summary

Overview: The document provides detailed specifications and characteristics of various types of ropes used in military, rescue, towing, and naval applications. It includes information on materials, construction, and performance metrics such as diameter, weight, and minimum breaking load (MBL).

Specifications:

PES 8-strand braided ropes: Available in diameters of 32mm and 40mm with MBLs of 15,295 kg and 24,065 kg respectively.
Nylon Spun 8-strand braided rope: Available in diameters of 32mm and 40mm with MBLs of 7,500 kg and 8,400 kg respectively.
Rescue & Towing Ropes: Various diameters from 5mm to 16mm, featuring characteristics like low elongation at break, water resistance, and UV resistance.
Nylon Winch Rope: 8-strand braided, available in diameters from 22mm to 72mm, with high elongation at break and abrasion resistance.
HMPE Soft Shackles and Multipurpose Rope: Known for high strength, low elongation, and resistance to water and UV.
Double Braided Rope: Available in various materials and constructions, suitable for naval forces with high abrasion resistance and specific weight characteristics.

Procedures and Recommendations:

Custom lengths are available upon request for most rope types.
Ropes can be equipped with metal accessories and loops as needed.
Special ropes for helicopter descent are designed to be soft on hands and available in polyester and nylon spun materials.

Key Characteristics:

Ropes are designed to be UV and chemical resistant, with some offering floating capabilities.
Specific weight and melting temperatures are provided for different materials, indicating their suitability for various environmental conditions.
Elongation at break percentages are specified, highlighting the flexibility and durability of the ropes under stress.

Applications:

Ropes are suitable for military, rescue, towing, and naval applications, including vehicle recovery, rigging, and mooring.
HMPE ropes are noted for their strength comparable to steel wire ropes, making them ideal for heavy-duty applications.

Catalog excerpts

QUALITY. INNOVATIONS. EXPERIENCE

Open the catalog to page 1

Rescue & Towing FAST ROPE MAG FORCE WINCH ROPE PES 8-strand braided ropes Special rope for descent from helicopters Soft for handsCan be equipped with metal accessories and loops upon request Available in two materials - Polyster and Nylon Spun 0, mm Meter weight, g MBL, kg Do not absorb water Floating UV & chemical resistant *custom lenghts available upon request NYLON WINCH ROPE 8-strand braided Elonation at break: 25% Sinking UV resistant Abrasion resistant *custom lenghts available upon request

Open the catalog to page 2

Safety & Utility HMPE SOFT SHACKLES MAG STATICA 48-strand Nylon static rope (Type A) low extension energy absorbtion "available with reflect marker *custom lenghts available upon request Perfect help in towing, rigging, vehicle recovery Easy attachment & quick release Braided PES twine with parallel Nylon core Survival rope - when it is necessary to fasten, attach, secure, belt or hang HMPE MULTIPURPOSE ROPE 12-strand braided, pre-stretched & impregnated twine with clasp one or both ends Elonation at break: 2,4% Do not absorb water Floating Thin but very strong, compact rope Can be easily fixed...

Open the catalog to page 3

Naval Forces HMPE LIFTING SLING 0, mm DOUBLE BRAIDED ROPE NYLON ‘minimum internal length of loop, m **working load limit, kg (WLL) - Safety factor 7 0, mm Meter weight, g MBL, kN Characteristics Specific weight - 1,14 g/cm: Sinking Absorb humidity Good resistance to drop loads and to wear DRONE LINE Braided PES twine with HMPE core different colors available, also with reflect marker Specific weight - 1,38 g/cm3 Sinking Absorb humidity Resistance to chemically active habitat Soft and flexible when wet

Open the catalog to page 4

Naval Forces MAG FORCE HMPE DBR HMPE 12-strand pre-stretched & impreganted braided rope UV resistant Elongation at break - 5% Do not absorb water BALTIC MIX LINE 12-strand mixed Danline and HMPE braided rope Meter weight, g MBL, kN Characteristics UV resistant Elongation at break - 9% Do not absorb water Excelent abrasion resisitance

Open the catalog to page 5

Naval Forces Naval Forces BALTIC FORCE LINE Double braided rope (PES cover, HMPE core) 0, mm Meter weight, g MBL, kN Characteristics Specific weight - 1,10 g/m Sinking Metling temp. 170°/260° UV resistant TWISTED ANCHOR LINES Construction: 3-strand, 4-strand Materials: Polysteel, PP split film, Nylon, Polyester, Silver, PP multifilament

Open the catalog to page 6

Open the catalog to page 7
