AQUILA 70

Product catalog summary

Specifications
The Aquila 70 Luxury Power Catamaran is a high-end yacht measuring 21.26 meters in length and 8.2 meters in beam. It has a draft of 1.45 meters and a bridge deck clearance of 0.69 meters. The yacht's dry weight is 43,000 kg, with a fully loaded displacement of 54,577 kg. It is powered by two D13 1000hp Volvo Penta Diesel Engines and has a fuel capacity of 4,400 liters, with an optional 780 liters extra. The water tank holds 1,560 liters, and the holding tank has a 560-liter capacity. It accommodates up to 8 people in 4 cabins, with an optional 5-cabin version for 10 people, and is CE Certified for ocean travel.

Construction
The yacht is built with InfusiCore hull and deck materials, E-Glass, and Vinylester Resin infusion. Main structural bulkheads use carbon epoxy resin with solid carbon laminate. It features a custom propulsion system with bronze 5-blade propellers and an electric fly-by-wire steering system.

Features
The yacht showcases Euro yacht styling, focusing on balance and aesthetics. It includes a master cabin with a king-sized bed, two VIP cabins with queen-sized beds, and a crew or guest cabin. The yacht offers expansive outdoor spaces and luxurious interiors, including a large galley and a salon with Italian designer furniture.

Exterior
The exterior includes solid deck railings, ergonomic transom steps, and Aquila branded stainless steel auto lift cleats. The flybridge has a Portuguese bridge and optional side wing docking stations. The stern features a remote-controlled dinghy platform lift and various storage options.

Interior
The interior is furnished with ALPI wood varnished cabinetry and Italian designed furniture. The salon includes a Natuzzi Italia sectional sofa and a Denon HEOS 5.1 Surround Sound Wireless System. The galley is equipped with high-end Gagganeau appliances.

Systems
The yacht's systems include an accessible engine room, electrical systems with LED lighting, and a C-Zone Touch 5 screen at the helm. The flybridge features a Volvo Penta engine data display and dual engine throttle control.

Galley and Dining Area
The galley offers ample storage, a bar area with a stainless sink, and a touchless faucet. It includes dimmable LED lighting, synthetic flooring, and a wireless charger in the dining area.

Owner's Cabin
The full-beam owner's cabin features ALPI wood cabinetry, a Denon HEOS 5.1 surround sound system, and a king-size memory foam mattress. It includes a dressing area, a bathroom with dual sinks, and a walk-in shower.

VIP and Crew Cabins
Both cabins have ALPI wood cabinetry, Denon HEOS sound systems, and memory foam mattresses. VIP cabins have private access, while the crew cabin includes bunk beds and a separate head and shower area.

Navigation Station
Equipped with a C-Zone digital control screen, aircon controls, generator control panel, and optional features like underwater LED lights and dual Volvo Penta Glass Cockpit screens.

Pantry and Laundry
Includes space for an optional washer/dryer, hard surface countertops, and ample storage with shelving.

Engine Room
Features an anti-vibration thrust bearing system, watertight door access, and a custom marine exhaust system. It includes two Kohler generators, a Webasto aircon system, and comprehensive electrical systems.

Electrical Systems
The yacht is equipped with a C-Zone digital switching system, Iso Boost transformers, and a comprehensive battery setup for various functions.

Catalog excerpts

Specifications Propulsion Construction Features Interior Layout EXTERIOR — Hull and Deck Features — Cockpit — Stern — Flybridge INTERIOR — Salon — Galley / Dining — Owner’s Cabin — VIP Cabins — Crew / Guest Cabin — Navigation — Pantry / Laundry SYSTEMS — E

Open the catalog to page 3

Aquila 70 Luxury Power Catamaran Specifications Length overall (LOA) Waterline length (LWL) Side Elevation Beam overall Height above waterline w/ hard top (including light and radar mast) Draft including propellor (approximate - will vary depending on load) Bridge deck clearance (approximate - will vary depending on load) Light displacement Fully loaded displacement ENCLOSED FLYBRIDGE Tankage Fuel tank capacity (total) Fuel tank (optional) Water tank (standard) Holding tank (total) MAIN DECK CE Certification (internationally recognized) Cat. A (Ocean) Accommodation Cabins Heads with separate...

Open the catalog to page 4

Propulsion Engines 2X D13 1000hp Volvo Penta Diesel Engines Bronze-5 Blade 30” (760mm) with rope cutters Steering Sytem Electric Fly By Wire Steering System Prop Shaft System Stainless steel with AquaDrive CV48 Antivibration thrust bearing system Prop Shaft Custom Fairing Custom designed to reduce drag and improve efficiency Vessel Control System Under water Thrust Bearing and AquaDrive Reduces vibration, noise, and improves CV Joint performance Rudder Custom designed foil shape - Bronze Protection of Running Gear Optional PropSpeed applied to all running and Prop gear and props Construction...

Open the catalog to page 5

EXTERIOR Hull and Deck Features Solid deck railings designed with luxury oval profile in 316 stainless steel Ergonomic transom steps for easy boarding and comfortable lounging off stern Aquila branded 316 stainless steel auto lift cleats (8) Heavy duty 17” stainless steel bollard cleats (4) with anti chafe guards Opening deck hatches carefully positioned to enhance ventilation in master cabin (2 total) PVC rubrail with 316 stainless steel insert offering all around protection Foredeck seating with pop up LED lighting fixtures (2) and comfortable cushions Foredeck sun pad area with integrated...

Open the catalog to page 6

Marine waterproof 7.7” JL speakers (4) and 10” JL subwoofer (1) Manual opening overhead hatches in hard top allowing airflow to captain (2) Electrical sliding hatches mounted in hard top (2) Volvo Penta 7” Engine Data Color Display at flybridge helm Volvo Penta dual engine throttle control Electric fly by wire steering system Main access from interior steps in salon Handrails conveniently located all around flybridge for secure movement Forward flybridge access via integrated steps Tempered glass windshield Windshield wipers (3) with fresh water supply and variable speed control at helm Windows...

Open the catalog to page 7

Salon ALPI wood varnished cabinetry throughout with accented wall and ceiling coverings ALPI wood varnished accent ceiling capping Italian designed Natuzzi Italia sectional sofa from Herman collection designed by Manzoni & Tapinassi Italian designed Natuzzi Italia Couture swivel armchair designed by Manzoni & Tapinassi Italian designed Natuzzi Italia coffee table and side table from Herman collection designed by Studio Memo Italian designed Natuzzi Italia 100% eco-sustainable bamboo silk SETI rug Italian designed Natuzzi Italia adjustable bar chairs from the DOVE collection x 3 Denon HEOS 5.1...

Open the catalog to page 8

Owners Cabin (Full Beam) ALPI wood varnished cabinetry throughout with accented wall and ceiling coverings Denon HEOS 5.1 Surround Sound Wireless System Luxury carpet in main cabin area Chaise lounge seating to port of main with vanity/desk area with power socket Private access door to cabin for privacy Refrigerator/Freezer – Fridge=8cu.ft. (adjacent to cabin) A/C Vents with Aircon display controller Power sockets with double USB outlets located under bed x 2 Opening ventilation hatches in ceiling with blinds x 2 Stainless steel leather wrapped supports x 2 Designated area for 55” Ultra High...

Open the catalog to page 9

Navigation Station Pantry / Laundry C-Zone 10”’ Digital switching control screen Aircon display/controls x 4 Generator control panel Engine Fire System alarms Variable speed windshield wipers x 2 with control panel Wireless charger x 1 Single power outlet with USB charger x 1 Optional underwater LED Light controls Optional water maker control Optional VHF with Speaker Optional dual Volvo Penta Glass Cockpit screens - 2 x 22” Designated optional full-size stackable washer/dryer location Hard surface wearing countertops Dimmable overhead LED ceiling lights Leather wrapped stainless steel support...

Open the catalog to page 10

SYSTEMS Engine Room Anti-Vibration AquaDrive CV48 thrust bearing system on each shaft Watertight door access from crew quarters and starboard aft day head (main access) Stainless steel steps from cockpit hatch to each engine room (secondary access) Optional SidePower hydraulic thruster system main pump Day fuel tank in each engine room with auto fuel transfer pump from main tank (390 liter / 103 gal each) Single power outlet for AC power Manual transfer pump for transferring fuel from each main fuel tank Shore power cable master system x 2 in starboard engine room Algae X fuel conditioning system...
