OFFSHORE APPLICATIONS WeatherStation® Multisensor – Ultrasonic Instrument for Offshore Weather Monitoring Available Model: 200WX-IPX7 Weather impacts every aspect of o perations on offshore platforms, ships, and in ports. Rapid changes in weather and sea conditions make monitoring of both meteorological and oceanographic parameters a critical part of nsuring e safety, while also maintaining perational o efficiency. Reliable environmental monitoring is c ritical for various offshore needs. The n umerous sensors ontained in the c c ompact size of the 200WX is an attractive feature for nstallations where space is i limited, such as on buoys, USVs, and ASVs. Having worked with many autonomous vehicle and buoy manufacturers, we have further developed the 200WX to be robust—meeting the operational c hallenges of the harsh ocean environment. The WeatherStation WX Series products offer a truly best-in-class solution at a better price than any other weather monitoring ystem s on the arket oday, enabling individuals and m t p rofessionals to make informed decisions based on real-time site-specific weather information. Wind Barometric Speed & Pressure Direction Actual Size FEATURES The 200WX-IPX7 WeatherStation instrument accurately measures current weather conditions, including: • heoretical wind speed and direction T • Air temperature and calculated wind chill • Barometric pressure • GPS position, speed over ground, course over ground • Three-axis solid state compass with dynamic stabilization • Three-axis rate gyro for rate-of-turn • Best-in-class <1° pitch and roll accuracy • IPX7 waterproof rating • Current d

Open the catalog to page 1

SPECIFICATIONS Wind Speed Range: 0 to 40 m/s Accuracy: 5% at 10 m/s at 4 angles Resolution: 0.1 m/s Calculations: User configurable damping Wind Direction Range: 0° to 359.9° Accuracy: ±3° at 10 m/s Resolution: 0.1° Calculations: User configurable damping Air Temperature Range: -40° to 80°C (-40 to 176°F) Accuracy: ±1.1°C at 20°C Resolution: 0.1°C Barometric Pressure Range: 300 to 1100 hPa Accuracy: ±0.5 hPa at 25°C (or better) Resolution: 0.1 hPa Three-axis Compass Range: 0 to 359.9° Accuracy: 1° static heading accuracy; 2° ynamic heading accuracy d Resolution: 0.1° Pitch and Roll...

Open the catalog to page 2
