TRIGGER RELEASE SHACKLES

Tylaska T5 Snap shackles are perfect for small boat applications requiring highstrength and low weight. They have a breaking strength of 5,000 lbs and weigh just 2.2 ounces in the standard bail configuration. Ideal for J-24s, Mumm 30s and similar boats.

T5

SB- Actual Size LB- Actual Size CB- Actual Size

SHACKLEABCDETHICKNESSWEIGHTWORK LOADBREAKINGRECOMMENDEDTYPE in (mm)in (mm)in (mm)in (mm)in (mm)in (mm)oz (gm)lb (kg) STRENGTH lb (kg) APPLICATIONS T5 SB
9 �
16 (14.2)
9 �
16 (14.2)
17 �
32 (13.5)
9 �
16 (14.2)2
15 �
16 (74.6).31 (7.9)2.1 (59)2,500 (1,136)5,000 (2,273)20-30’ Boats T5 LB
9 �
16 (14.2)
9 �
16 (14.2)
13 �
16 (20.6)
7 �
8 (22.2)3
5 �
16 (84.1).31 (7.9)2.6 (74)2,500 (1,136)5,000 (2,273)20-30’ Boats T5 CB
9 �
16 (14.2)
9 �
16 (14.2)
19 �
32 (15.1)
1 �
2 (12.7)3
1 �
4 (82.6).31 (7.9)2.8 (79)2,500 (1,136)5,000 (2,273)20-30’ Boats

SB - Standard Bails provide ample room for attaching a line while keeping weight andoverall shackle length to a minimum. Ideal for halyards and sheets.LB - Large Bails provide room for up to three additional shackles or a combination ofshackles and lines. Ideal for spinnaker sheets, guys or other multi-line applications.CB - Clevis Bails do not require splicing and provide moveable attachments to rings,deck fittings, furlers, rolling furlers, etc. Ideal for many uses.

Every unit is pull tested and released under several different load conditions before shipping.
