5, 2.5 or 1 Watt Transmit Power on Marine VHFSubmersible ( IPX7 : 3 ft for 30 min) and Rugged Construction
700 mW Loud AudioProgrammable Scan, Priority Scan, Dual Watch and Tri WatchChannel Name CapabilityUnique High Intensity Distress Signalling Strobe LightBacklit Keypad and Extra Large Display
SPECIFICATIONS User selectable transmit power output allows longer talk time. Select 2.5 or 1 watt in close to shore or inside the marina or 5 watts when you need to be heard or in an emergency situation. General
Frequency Ranges (MHz) 156 MHz - 163.275 MHz (Marine Band + WX Band) Channel Steps 25 kHzFrequency Stability ± 10 ppm (-4 ° F to +140 ° F)
The HX500S is built to last with an impact resistant poly carbonate outer shell. This meets
Emission Type 16K0G3EAntenna Impedance 50 OhmsSupply Voltage Nominal: 7.2 V DC, Negative Ground (Battery
Marine terminal)
Current Consumption 170 mA (Receive)
50 mA (Standby)
1.45 A (5 W transmit)
1.0 A (2.5 W transmit)
0.6 A (1 W transmit)
Operating Temperature -4
industry standards for water proofing of 3 feet for 30 minutes.
Be heard! With 700 mW of audio power you will have no problem hearing this radio even in the loudest conditions. Add additional audio with an external marine speaker mic or headset.Select any of the channels you would like to scan with the press of a button. Select Dual Watch to scan your selected channel and channel 16 simultaneously. This way you will not miss any of the very important calls made on channel 16. Similar to Dual Watch, Priority Scan allows scanning of more than one channel with Channel 16.
All the information you need right at your fingertips. Customizable channel naming allows you to easily change the channel name for greater ease of use and channel recognition. Be seen! This unique high intensity strobe light can be seen up to one mile away. In an emergency the unique, super bright LED distress strobe light blinks internationally recognized SOS to visually signal another vessel. This just might be that extra advantage you need if rescue from dark and stormy seas is necessary.A bright display and bold numbers takes the headache out of operating the HX500S even on the brightest day.
° F to +140 ° FCase Size (W x H x D) 2.36 x 4.09 x 1.2 w/o knob &
marine antenna
Weight (Approx.) 12.3 oz. with FNB-83, AntennaWaterproof spec IPX7
Transmitter
RF Power Output (@7.4 V) 5, 2.5 or 1 WModulation Type Variable ReactanceMaximum Deviation ± 5 kHzSpurious Emission At least 65 dB below Microphone Impedance 2 k-Ohm
Circuit Type Double-Conversion Superheterodyne Intermediate Frequencies 1st: 47.25 MHz 2nd: 450 kHz Sensitivity 0.2 uV for 12 dB SINAD Adjacent Channel Selectivity 65 dB TypicalIntermodulation 65 dB TypicalSelectivity 25 kHz (-60 dB)
?
NOAA Weather Alert
?
Includes 1400 mAh Rechargeable Ni-MH Battery and the AC
AF Output (Internal speaker) 700 mW @ 16 Ohm for 10 % THD (@7.4 V)
?
Connection for optional speaker microphone or headset
Standard Horizon reserves the right to make changes and enhancements to products at our discretion. Current specifications are therefore subject to change without notice. OPTIONAL ACCESSORIES
NC-88B/C* CMP460S Overnight Charger Noise-canceling WaterproofSpeaker/Microphone MH-57
A4B VC-24 VC-27 CD-32 Mini Speaker/Microphone VOX Headset Earpiece/Microphone Charger Cradle E-DC-6 E-DC-19A DC cable with 12 V Cigarette Lighter Plug FNB-83 VAC-10 FBA-25A 7.2 V 1400 mAh Ni-MH Battery Pack CAW230 Rapid Charger Alkaline Battery Case DC Cable; Plug and Wire Only Radio to
Vessel’s Antenna Adapter CT-111 Programming cable CE80 Programming
boat software *B for 120 VAC/C for 220 VAC
AFAMILY OF COSMETICALLY MATCHED CHOICES The HX500S is one member of the family of marine electronicsfrom STANDARD HORIZON that includes:
Marine Division of Vertex Standard US Headquarters10900 Walker Street Cypress, CA 90630
Phone: 714/827-7600Fax 800/552-6813Email: marinetech@vxstdusa.com
Web: www.standardhorizon.com
GPS FOR BOATS CHART/ FISH PLOTTERS MARINE VHF RADIOS 2006.0305NA(U) B9200516Printed in Japan
