| | | Solent Marine Ltd Specifications | | |
| | | Specialist Manufacturers of all Modular Floating Structures | | |
| | | |
| | | |
| | | | | | | | | | | | | Pontoon Spec: | | Finger Spec: | | | | | STD Live Load | 1.5-2.5 Kn/A2 | | STD Live Load | 0.75-1.0 Kn/A2 | | | | Maximum Wave Height | 500mm | | Maximum Wave Height | 500mm | | | | Basic Wind Speed | 47M/S | | Basic Wind Speed | 47M/S | | | | STD Floatation | Fibre Concrete Coated Polystyrene Blocks as STD | | STD Floatation | Fibre Concrete Coated Polystyrene Blocks as STD | | | | Rotor Moulded Plastic Floats are Optional | | Rota Moulded Plastic Floats are Optional | | | | STD Structure | Mild Steel Framework Galvanized to ISO-1461 Standards | | STD Structure | Mild Steel Framework Galvanized to ISO-1461 Standards | | | | Freeboard | 500mm as STD | | Freeboard | 500mm as STD | | | | Reserve Buoyancy | 25%MaxLoad(Approx) | | Reserve Buoyancy | 20% Max Load (Approx) | | | | Draft | 340mm STD | | Draft | 340mm STD | | | | | | | | | | | | |
| | | |
| | | STD SIZES | | |
| | | |
| | | | | | | | | | Pontoon Spec: | | | | Width | Length | | | | 2M | 6M | | | | 2M | 8M | | | | 2M | 10M | | | | 2M | 12M | | | | j.5M | 6M Q II Ü | | | | 2.5M 2.5M | 8M 10M | | | | 2.5M | 12M | | | | 3M | 6M | | | | 3M | 8M | | | | 3M | 10M | | | | 3M | 12M | | | | | | | | | | | | | | | | | | | | Finger Spec: Width Length | | | | S 0.75M | 6M | | | | 0.75M | 7M | | | | 0.75M | 8M | | | | 0.75M | 9M | | | | I 0.75M | 10M | | | | i| 1M 1M 1M ! 1M 1M | 6M \ 7M f 8M f 9M h 10M ' | | | | | | | | | |
| | | |
| | | |
| | | m ^4 SOLENT MARINE LTD the clear choice in pontoon supply... | | |
| | | |
| | | | | | | | | | | | | | | | |
