)TTEÜ
Steering
and control systems
Research
and Development
2
4
Quality
The application of CAD in development and design, the implementation of
advanced manufacturing technologies, the use of high-grade materials, skilful assembly and professional installation on site are the major foundations for the
top quality of our products. This is
impressively confirmed by the certifica­tion of our quality management system according to DIN EN ISO 9001 by
American Bureau of Shipping, Bureau Veritas, Det Norske Veritas and Germanischer Lloyd.
1 Our tailored steering and control systems have been service-proven and type-tested for decades.
2 Calculation of a speed field for rating the Twin Marine propeller
3 Vortex street of the front propeller
4 Existing Twin Propeller models are optimized and new types developed using state-of-the-art calculation methods.
5 Developed in intensive cooperation with inter­nationally renowned research institutes, the hydrodynamic design of our systems is ack­nowledged throughout the industry as trend­setting.
1 Upper gearbox
2 Power input
3 Steering gear
4 Well
5 Lower gearbox
6 Input shaft
8 Front propeller
9 Rear propeller
Well installation
Installation variants
