jlfun

M5-55 Compact Box Subwoofer

The MS-55 subwoofer is a compact, high efficiency bass enclosure optimized for marine applications. It's small size enables it to be easily mounted below seats, under the gunwale area, behind the instrument panel, or any convenient location. The MS-55 is a self contained bass unit requiring no cutting of panels or holes in the boat interior. It produces solid, deep bass extending down to 40Hz and is the perfect addition to any audio system.

Features:

• Dual Voicecoil, high-excursion, 5.25" woofer

• Highdensity, UVstableenclosure

• Water resistant

• Bass-reflex, high-efficiency acoustic design

• Side vented output ports

• Compact size and molded-in mounts provide for convenient installation nearlyanywhere.

• Acoustically matched for use with Poly-Planar ME-51, MZ-100 and ME-400 amplifiers or can be used with any amplifier

25 - 100 watts. Specifications:

• Power Handling.........100 Watt RMS

• Speaker Impedance......4 ohm x 2 inputs

• Frequency Range........40 Hz- 300 Hz

• Weight................8.5 lb (3.8g)

• Dimensions.............Width - 8.85" (225mm)

Length - 11.8" (300mm) Height-4.75" (120mm)

MS-551 includes ME-51 Amplifier

MS-S5Q Panel Mount Subwoofer

The MS-250 is a powered 10" subwoofer capable of delivering a true 50 watts RMS of bass power to compliment any serious audio system. Easy to install, the amplifier may be conveniently mounted remotely or directly onto the back of the speaker. Since it has its own amp, it won't drain power from the primary system. (For Subwoofer without amplifier, order MS-150).

Compact Box Speakers - MA-3030

MA-3Q13 Speakers

• 3" Cone

• 60 watt. Flush Mount, Midrange Speaker

• WhiteorMetallicGray

• Low Magnetic Field

• Waterproof construction throughout.

• Powder coated aluminum grill.

• Mounting Hardware & Speaker Wire Included

• QuickConnectTerminals

See pages 14-15 for specifications.

3-1/2"

• CompletelyWaterproof

• Powder coated stainless bracket

• Gold-plated Binding Posts

• Powder coated aluminum grill.

• Mounting hardware and speaker wire included.

• 3" 60 watt, 2-way box speaker

• Available in White or Metallic Gray

poly-planan
