Setting the standardfor

Marine-Grade Amplifiers

Poly-Planar Marine amplifiers are waterproof (IP65) units designed for harsh marine environments. These amplifiers can be used as stand alone units or as part of an expansion system.

ME-400 Amplifier

The ME-400 is a high power4channel (Bridgeable) marine amplifier designed to powerthe most demanding systems. Features include:

• MOSFET Switches and power supply for low noise and reliability

• Adjustable level input, high and low passfilters

• Variable bass boost circuit

• Integral protection forthermal overload, short and reverse polarity

• Gold plated connections for corrosion resistance

plafi^ar

MZ-10Q DSP Amplifier

The MZ-100isa4 channel 100 watt amp that uses digital signal processing. This unique feature allows multiple EQ settings as well as system integration with the RD-44 and MRD-70. Features include:

• 8 preset equalization settingsfor application configuration

• 4 channel output can power up to 4 speakers and 1 subwoofer

• DIN cable inputs for connection to RD44 direct or MRD-70 system

• Separate waterproofvolume control.

• 1 Auxiliaryinput (RCA Type)

(fl DC UJ

E j

ME-5Q Expansion Amplifier

ME-50 Expansion AmplifierThe ME-50 is a compact 2-channel 50-watt audio amplifier with separate volume control. This unit is designed for adding additional speakers to an existing system or as a separate Zone amp.

Features include:

• Accepts line level or marine speaker level inputs

• Powers up to 4, 4 Ohm speakers.

• Separate waterproof Volume control (10 ft lead)

MP3-KIT A

A waterproof, entry level MP3 player based sound system kit for small craft & off road vehicles. Easily installed where space is a premium, this kit was designed for yacht tenders, flats boats, and other small craft. Also a perfect solution for Motorcycles, ATV's and Golf carts. Kit includes:

• ME-50 50 watt waterproof Amplifier with separate panel mount waterproof volume control

• IC3.5-PM Panel mount 3.5mm MP3 connector for IPod or other MP3 players

• MA-4055 5" coaxial waterproof speakers with speaker wires included.

photo courtesy Zodiac Boats

poly-planan
