Mass Sine inverters Mass battery chargers When full batteries matter Robust technology Built to last Maximum safety the professionals’ choice: complete security

Open the catalog to page 1

Heavy duty products The Mastervolt Mass battery chargers and Mass Sine inverters have been designed for heavy use in professional and semi-professional environments. They continue to work reliably in the hottest engine rooms where the engines run on full power, and can be used around the clock where necessary. Even in the most extreme conditions the Mass battery chargers and inverters operate faultlessly and at full capacity. The sustainability and technologies that underpin the Mass concept have long been proven in practice. With an MTBF of 280,000 hours at full capacity and 24/7 use, the...

Open the catalog to page 2

easy installation, fast fitting All Mass products are designed to easily t within a system. MasterBus compatible The Mass battery charger is fully MasterBus compatible. In combination with the MasterBus Inverter Interface, it is simple to connect every Mass Sine inverter within a MasterBus network. All you need is a single cable with one connection. Your benets: fast and easy installation, plus centralised monitoring, conguration and operating of your system with, for example, a MasterView panel. Made tough by smart design The DNV-certied Mass battery chargers are very strong, designed to...

Open the catalog to page 3

Powerful selling points Mass battery chargers • Developed for use within fully approved maritime power systems. • Designed to withstand the most difcult conditions (full output by compensating cable losses up to 30 V). • Lightweight, stainless steel, anodised aluminium casing. • Coating of internal components prevents damage from damp or condensation. • Insensitive to electromagnetic effects of other devices. • Suitable for every type of battery, including Lithium Ion; delivered as standard with temperature sensor. • 3-step charging process for fast and complete loading. • Full power at...

Open the catalog to page 4

Mass battery chargers Mass 12/60-2 Mass 12/80-2 Mass 24/15-2 Mass 24/25-2 Mass 24/50-2 Article no. 40010606 40010806 40020156 40020256 40020506 Nominal input voltage 230 V (180-250 V) 230 V (180-250 V) 230 V (180-250 V) 230 V (180-250 V) 230 V (180-250 V) Nominal output voltage 12 V 12 V 24 V 24 V 24 V Total charge current + 2nd output 60 A / 3 A 80 A / 3 A 15 A / 3 A 25 A / 3 A 50 A / 3 A Charge voltage Bulk (25 °C) 14.25 V 14.25 V 28.8 V 28.8 V 28.5 V Charge voltage Absorption (25 °C) 14.25 V 14.25 V 28.5 V 28.5 V 28.5 V Charge voltage Float - wet/gel+AGM (25 °C) 13.25/13.8 V 13.25/13.8 V...

Open the catalog to page 5

Mass sine sine wave inverters Mass sine 12/800 Mass sine 12/1200 Mass sine 12/2000 Mass sine 24/800 Mass sine 24/1500 Article no. 230 V 24010800 24011200 24012000 24020800 24021500 Article no. 120 V* n.a. n.a. 25012000* n.a. n.a. Nominal battery voltage 12 V 12 V 12 V 24 V 24 V P30 power Tamb= 25 °C, cos phi 1 800 VA 1200 VA 2000 VA 800 VA 1500 VA Nom. power Tamb= 40 °C, cos phi 1 650 VA 1000 VA 1800 VA 650 VA 1200 VA Peak load 1600 VA 2400 VA 4000 VA 1600 VA 2900 VA Max. efciency 92% 92% 92% 92% 92% Dimensions, hxwxd 313x187x82 mm 340x261x144 mm 420x318x130 mm 325x220x111 mm 340x261x144 mm...
