| | | Deck Line Pedestals | |
| | | | | | | | | | | | II • I * | | « | | | | | | | | | | ',, li lui &uf! | | | | | | | | | | | | | | | | | | | |
| | | Liteway Lighting Post | | |
| | | You may require an alternative to our standard pedestals and this Is where the Deck Line Range comes Into It's own. Low level and with directional Illumination via a PL9 lamp, the main pedestal can incorporate up to four socket outlets. Manufactured from 2.0mm aluminium around a 3.0mm aluminium chassis the complete unit Is then electro-statically oven baked In marine blue as shown but Is also available In a variety of colours. This unit can also be utilised as a controller housing further swltchgear to supply satellite connection units at adjacent berths. Controller Dimensions | | |
| | | |
| | | Install lighting around your marina with this low cost post and Illuminated globe. This unit Is available In both 304 and 316 Grades of Stainless Steel. The diameter of the post Is 60mm and heights of either 1000mm or 1500mm are available. A12W low consumption lamp is supplied and the post is designed to be root mounted but base flange versions are available upon request. As an even lower cost alternative, a f Ibreglass root mounted post can be supplied. | | |
| | | Stainless Steel Pedestals | | |
| | | |
| | | Manufactured from 1.0mm 316 Grade Stainless Steel, this pedestal range incorporates all the benefits of our PVC internal chassis and base plate with a tough stainless steel skin suitable for marine environments. All the usual configurations are available including water, TV and three phase options. The product can also be offered In 304 Grade Stainless Steel for less harsh environments. | | |
| | | |
| | | |
| | | |
| | | | | | | | | | | H | D | w | | | | 400mm | 240mm | 380mm | | | | Satellite Dimensions | | | | H | D | w | | | | 155mm | 100mm | 105mm | | | | | | | | | | |
| | | |
| | | |
| | | Power Distribution Panels Mains Panels are constructed to individual site requirements utilising all necessary main network protection devices and supplementary circuit protective equipment In either polyester enclosures or floor mounted specialist kit systems where electrical and mechanical characteristics determine a larger panel Is required Specialist advice from our Engineering Department is particularly advisable with regard to this type of equipment to enable marina operators to ^^^^^^t^^^ obtain the correct equipment applicable to the electrical requirements of \ the Installation. | | |
| | | |
| | | Service Utility Pillar Your boatyard or canal location may require the most durable and vandal resistant connection pillar possible. You can have ultimate control of access to the socket outlets and swltchgear by means of the lockable door. Up to four 16A 2 Pin + Earth Socket Outlets are located on the aluminium chassis with the swltchgear behind a reset flap. The pillar Is manufactured from 5.0mm S235 hollow section with a 300mm mounting base. 16A supply plugs can be in place in up to four outlets and the door then locked shut. | | |
| | | Parking & Anti-Parking Posts | | |
| | | |
| | | Complementary items for your marina include our range of traffic management posts both telescopic and root mounted. All posts are available In either 304 or 316 Grades of Stainless Steel and complement the lighting posts. | | |
| | | |
| | | Ito | | |
| | | |
| | | |
| | | I +44 (0)1790 752559 to place your order | | |
| | | +44 (0)1790 753164 to place your order | | | 3lace an order via email at sales@maricer.com | | |
| | | www.mancer.com | | |
| | | |
| | | |
| | | |
| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
