Overall details
Rig Masthead Fractional
Mast manufacturer
Boom manufacturer
Sail colour
Insignia (if required)
Sail number (if required)
Number of reefs
Battens Full 3/4 Short
Luff rope diameter
Luff sliders (Maker’s number*)
Foot rope diameter
Foot slides (Maker’s number*)
*If the maker’s number is not known, indicate type
and dimensions from illustrations below
A x B x C x D (inside) x
Figure A dimensions
A Luff (from sheave
to top of
boom)
B Foot (mast to sheave)
C Leech length
D Backstay from mast at 90¢ª
Figure B dimensions
1 Top of
boom to mastgate
2 Bearing face of shackle to mast
3 Reef horn to mast (if applicable)
4 Bearing face to shackle to
boom top
Please call us on 01603 782223
if you have any problems with this form
3
2
1
4
B
C A
D
Figure B
Figure A
Mainsails
Name
Address
Postcode
Telephone email
Yacht name / class Yacht location
Signature Date
