10" Monochrome CRT Boat radar / VideoPlotter10.4" Color LCD Radar / VideoPlotterMODEL 1833MODEL 1933MODEL 1943MODEL 1833CMODEL 1933CMODEL 1943C DISPLAY UNIT 1. Type 10" Green phosphor CRT 481 x 640 pixels10.4" Color TFT LCD 640 x 480 pixels 2. NavNet Interface3. Interface (NMEA 0183 format) Ethernet 10-BaseTInput: BWC, BWR, DBK, DBS, DBT, DPT, GGA, GLL, GSV, MSS, MTW, RMA, RMB, RMC, TTM, VTG, VYW, ZDA, --: any talker (menu selection) Output: AAM, APB, BOD, BWC, BWR, DBT, DPT, GGA, GLL, GTD, MSK, MTW, RMA, RMB, RMC, TLL, VHW, VTG, WPL, XTE, ZDA RADAR CHARACTERISTICS1. Display Modes Head-up, Course-up*, North-up*, True Motion** (* Heading input required ** Heading and speed input required)0.125 to 36 nm0.125 to 48 nm0.125 to 64 nm0.125 to 36 nm0.125 to 48 nm0.125 to 64 nm 2. Range Scales (nm) 15 range steps16 range steps17 range steps15 range steps16 range steps17 range steps 3. Echo Trail Interval: 15 s, 30 s, 1 min, 3 min, 6 min, 15 min, 30 min or Continuous PLOTTER CHARACTERISTICS 1. Map Scale 0.125 to 1,024 nm 2. Latitude Limits Between 85ºN and 85ºS 3. Plot Interval 1 s to 59 min 59 s or 0.01 to 9.99 nm 4. Display Modes Course plot, Nav data, Steering display, Highway 5. Presentation Modes 6. Memory Capacity TM/RM North-up, Course-up, Heading-up Up to 8,000 points for boat ship's marine track and marks1,000 waypoints 200 planned routes (max. 35 waypoints/route)Arrival/anchor watch, XTE, proximity alert, ship speed, depth*, water temperature*, fish* 7. Alarms (*Network Sounder required, temperature sensor required for water temperature alarm) Loaded from a FURUNO MiniChart, Navionics Nav-Chart, C-Map NT chart cards *Chart must be determined upon ordering. 8. Electronic Charts* Choice of two units: Furuno & Navionics or C-Map BOAT ANTENNA RADIATOR 1. Type Ø 602 mm (24")1035 mm (3.5 ft)1255 mm (4 ft)Ø 602 mm (24")1035 mm (3.5 ft)1255 mm (4 ft) RadomeOpenOpenRadomeOpenOpen24 rpm24 / 48 rpm24 / 48 rpm24 rpm24 rpm24 rpm 2. Rotation Speed * with 350 candella Display unit only3. Wind Load Relative 100 knotsRelative wind 100 kts (24 rpm)Relative 100 knotsRelative wind 100 kts (24 rpm) Relative wind 70 kts (48 rpm)Relative wind 70 kts (48 rpm)Hor: 3.9ºHor: 2.2ºHor: 1.9ºHor: 3.9ºHor: 2.2ºHor: 1.9º 4. Beamwidth Vert: 20ºVert: 22ºVert: 22ºVert: 20ºVert: 22ºVert: 22º RF TRANSCEIVER 1. Peak Output Power 4 kW4 kW6 kW4 kW4 kW6 kW 2. Frequency 3. Pulselength & PRR 9410 ±30 MHz (X-Band)0.08 ms/2100 Hz (0.125 to 1.5 nm)0.3 ms/1200 Hz (1.5 to 3 nm) 0.8 ms/600 Hz (3 to 64 nm) 4. Noise Figure 9 db6 db6 db9 db6 db6 db ENVIRONMENT
(IEC 60945 test method) Temperature -15ºC to +55ºC (Display unit) -25ºC to +70ºC (Antenna unit) IEC 529 IPX5, USCG CFR-46 (Display unit) Waterproofing IEC 529 IPX6 (Antenna unit) POWER SUPPLY 12-24 VDC12-24 VDC12-24 VDC12-24 VDC12-24 VDC12-24 VDC 55 W73/88 W73/88 W70 W90 W100 W 115/230 VAC with optional rectifier PR-62/RU-3423 Optional unit Antenna Bracket OP03-92Not AvailableOP03-92Not Available 10-Target Autoplotter ARP-11 External Buzzer OP03-136 Video Interface (NTSC/PAL) Not AvailableAvailable
