SMART VALVE
™
& SMART VALVE ROV
™
Please use Smart Valve ™ order form for ordering instructions and to notevalve names for engraved panel.
SMART VALVE ™
The Smart Valve ™ provides the safety and assurance of a visual display panelshowing which seacock is open or closed-without having to go below and pull up
floorboards to make a visual inspection. Sensors, factory installed, on any new single port, Marelon Integrated
Boat plumbing System flange mounted valve use state-of-the-art sensing technology to monitor the valve’s
handle for boat position. Display
panels for boats use red and green
Marine led lights to indicate which valve is open (green LED) or closed (red LED). Simple two wire lead from each valve makes installation easy.
Power is supplied directly to the panel only. Panels are offered in 4, 8 and 12 valve combinations with valve use names (i.e. "Head Intake") engraved on each panel.
Part No.
Model
9301504 valve/panel9301518 valve/panel93015212 valve/panel Please specify 12v or 24v systems For OEM valve installations only Typical Smart Valve Installation Smart Valve Panel
SMART VALVEROV ™ FORESPAR
® HAS TAKEN SEACOCK CONTROL TO A NEW LEVEL.
With the success of the Smart Valve ™, the next logical step was to make
boat valves remote controlled. Forespar
® can now offerthe Smart Valve ROV ™ (Remote Operated Valves) to
boat buildings wishing to offer their customers the added convenience ofoperating their seacocks from the helm (or wherever you wish to mount the control panel) all without the need to go below, get on your knees and reach into the bilge to open or close the valve(s). Powerful sealed motors open or close the valve(s) with a push of a button. Any valve suitable for Smart Valve ™ sensors can bemade (at the factory) to be remote operated. Four wires (two for the sensors, two for the motor) are lead to the Smart ValveROV ™panel that is custom engraved and has the red and green LED
indicator for boat lights for boats. As with the Smart Valve ™, power is supplieddirectly to the control panel only. ROV panels come in 4 & 8 valve sizes only. Forespar
® can also supply Smart Valve ROV ™ Systems that can be used with the new, state-of-the-art power distribution & systems integration "CAN-BUS" type systems. Please use Smart Valve ROV ™ order form for ordering instructions and to notevalve names for engraved panel.
Part No.
Model
9301451/2"- 3/4" valves9301461" – 1-1/4" valves9301471-1/2" – 2" valves For OEM valve installations only
Please specify 12v or 24v systems 2
